EDIFIER STAX SPIRIT S5 Manual

Wirel es s P lan ar Ma gn et ic Headphones
EN 1. Power ON/OFF
ON -
OFF -
Press and hold the power button to power on/off.
2. First Pairing
1. Once powered on, the headphones will automatically enter
Bluetooth pairing mode.
2. Select "EDIFIER STAX SPIRIT S5" in your device setting to connect.
3. Pairing for new device
3s
1. In ON state, press and hold the MFB for about 3 seconds to enter
Bluetooth pairing mode.
2. Select "EDIFIER STAX SPIRIT S5" in your device setting to connect.
Note: For subsequent use, the headphones will automatically connect to the device used last time.
4. Dual-device connection
①
②
3s
1. Pair device A with the headphones successfully.
2. Press and hold the MFB for 3 seconds to re-enter Bluetooth pairing
mode, and then select "EDIFIER STAX SPIRIT S5" in device B setting
to connect.
3. Select "EDIFIER STAX SPIRIT S5" again in device A setting to connect
and the dual-device connection is done.
Note: For subsequent use, the headphones will automatically reconnect to the two devices used
last time.
5. Charging
Connect the headphones to a power source via the USB-C cable for
charging.
Note: 1. Make sure the USB port is completely dry before charging.
2. When charging with a USB-C cable, the product is used as wired headphones and
Bluetooth functions are unavailable.
6. Controls
Call
●
x1
x1
x2
Music
●
x1
x1
x1
Mode
●
x1
EQ mode
x2
Note: 1. "x1" Press, "x2" Double press, " — " Press and hold;
2. Download EDIFIER ConneX App for more customizable control settings.
7. Fast Pair
Power on and enter Bluetooth pairing with an Android device close
by. Then tap the pop-up window to connect effortlessly.
Note: Fast Pair is compatible with Android OS 6.0 or higher.
8. Reset
x5
x6
1. In ON state and with no AUX or USB-C cable connection, press the
MFB 5 times to finish factory reset.
2. The headphones will automatically enter Bluetooth pairing mode if
successful.
9. Wired listening
1. Power on and connect to the headphones via AUX cable or USB-C
cable.
2. Wired listening will automatically disable Bluetooth mode.
S5
M od el : ED F200132
Manual
1s
x2
③
Bluetooth
EDIFIER STAX SPIRIT S5
Bluetooth
EDIFIER STAX SPIRIT S5
Bluetooth
EDIFIER STAX SPIRIT S5
Bluetooth
EDIFIER STAX SPIRIT S5
A
A
B
Input: 5V 2A
