[Window comparator mode]
The Flow switch turns on within a set flow range (from PL to PH). Set PL, the lower limit of the switch
operation, and PH, the upper limit of the switch operation and WH (hysteresis) following the instructions
given above.
When reversed output is selected, the main screen displays [nL] and [nH].
[Accumulated output mode]
Set each P (set value), referring to setting method of page 23.
(When reversed output is selected, the main screen displays [n]).
Refer to the switch output modes list for the relationship between the set values and operation (page 31).
 Setting of the normal/ reverse output switching and hysteresis/window comparator mode switching are performed using the
function selection mode [F 1] OUT setting.
