Summary of Contents for U-Line URNP115-IS01A

  • Page 1 USER GUIDE & SERVICE MANUAL Model: URNP115-IS01A...
  • Page 2 USER GUIDE & SERVICE MANUAL Click on any section below to jump directly there Table of Contents Installation Integrated Panel Dimensions Integrated Panel Installation...
  • Page 3: Product Information

    U-Line Customer Care must be contacted immediately at +1.414.354.0300. Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been altered or repaired in the field without prior written approval from U-Line, claims will not be eligible.
  • Page 4: Integrated Panel Dimensions

    USER GUIDE Integrated Panel Dimensions Integrated Panel Dimensions INTEGRATED PANEL BACK SURFACE MUST HAVE AMPLE FLAT SURFACE 3/4” TO MOUNT OVERLAY PANEL FLAT AND WITHOUT INTERFERENCE (19 mm) NOTICE 14 ⁄ ” Due to differences in surrounding cabinetry, the (379 mm) panel may not perfectly align with door.
  • Page 5: Integrated Panel Installation

    USER GUIDE Integrated Panel Installation PREPARE INTEGRATED PANEL Remove door from unit (See To Reverse the Door Swing) On a flat surface, line up the door to the integrated door panel and clamp. Remove gasket channel filler to expose side holes. Install 10 screws to secure door to panel.
