QUICK START GUIDE
URCC115
•
15" Craft Ice Machine
30723 Rev_A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the URCC115 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for U-Line URCC115

Summary of Contents for U-Line URCC115

  • Page 1 QUICK START GUIDE URCC115 • 15” Craft Ice Machine 30723 Rev_A...
  • Page 2 U-Line Customer Care must be contacted immediately at +1.414.354.0300. Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been altered or repaired in the fi eld without prior written approval from U-Line, claims will not be eligible.

  • Page 3: Table Of Contents

    Safety and Warning Environmental Requirements Electrical Water Hookup Door Adjustments Door Swing General Installation Integrated Panel Installation Control Operation First Use Airflow & Product Loading Cleaning Warranty For more details, see the complete User Guide & Service Manual on u-line.com.

  • Page 4: Safety And Warning

    QUICK START GUIDE USER GUIDE u-line.com Safety and Warning DANGER NOTICE This unit contains R600a (Isobutane) which is a Please read all instructions before installing, flammable hydrocarbon. It is safe for regular operating, or servicing the appliance. use. Do not use sharp objects to expedite defrosting.

  • Page 5: Environmental Requirements

    USER GUIDE QUICK START GUIDE USER GUIDE Environmental Requirements Electrical This model is intended for indoor/interior applications only WARNING and is not to be used in installations that are open/ exposed to natural elements. SHOCK HAZARD — Electrical Grounding Required. Never attempt to repair or perform This unit is designed to operate between 50°F (10°C) and maintenance on the unit until the electricity has 100°F (38°C).

  • Page 6: Water Hookup

    QUICK START GUIDE Water Hookup WATER SUPPLY CAUTION Observe and follow all local building codes when installing this appliance. This ice machine must be connected to a potable cold water supply line. delivering water pressure between a minimum of 20 psi and a maximum of 120 psi. Use 1⁄4”...
  • Page 7 QUICK START GUIDE USER GUIDE u-line.com Drain Air Gap (Optional Hook-Up) DRAIN CONNECTION CAUTION The floor drain must be large enough to Waste accommodate drainage from all attached drains. Follow these guidelines when installing drain Cold Water lines to prevent water from flowing back into Water Shut-Off...

  • Page 8: Door Adjustments

    QUICK START GUIDE USER GUIDE u-line.com Door Adjustments REVERSING THE DOOR Open door. DOOR ALIGNMENT AND ADJUSTMENT Using T-25 Torx bit loosen screw #1 and remove screw Align and adjust the door if it is not level or not sealing #2 on top and bottom hinge.

  • Page 9: Door Swing

    QUICK START GUIDE USER GUIDE u-line.com Door Swing 3 ⁄ ” (79 mm) Minimum Clearance Needed 90 Door Swing Stainless steel models require 3 1⁄8” (79 mm) door clearance to accommodate the handle if installed next to a wall. Door Swing...

  • Page 10: General Installation

    QUICK START GUIDE USER GUIDE u-line.com General Installation INSTALLATION Plug in the power/electrical cord. LEVELING INFORMATION Gently push the unit into position. Be careful not Use a level to to entangle the cord or water and drain lines, if confirm the unit is applicable.

  • Page 11: Integrated Panel Installation

    11.Remove clamps from door. panel to door using Clamp clamps. A robust tape may also be NOTICE used. U-Line If panel requires additional adjustment after recommends the removing clamps, slightly loosen each screw and use of bar clamps Door/Drawer adjust panel as necessary. Tighten screws upon to secure the panel completion.

  • Page 12: Control Operation

    NOTICE loading. Discard the ice produced during the first two or U-Line recommends discarding the ice produced three hours of operation to avoid possible dirt or during the first two to three hours of operation scale that may dislodge from the water line.

  • Page 13: Ice

    QUICK START GUIDE USER GUIDE Evaporator Plate Front Grid Splash Panel Cutter Your ice machine is unique in how it forms ice with Shield fractional freezing to form a slab of ice that is clear and has less dissolved solids than the water from which it is produced.

  • Page 14: Cleaning

    Order ice machine cleaner online: in wires www.u-line.com Part # 80-55667-00 A “CLEAN” reminder will occur every 6 months to remind you that it may be time to clean your appliance. Over time mineral build up on the cold evaporator plate can occur which can adversely affect the quality of your ice.
  • Page 15 QUICK START GUIDE USER GUIDE Replace the splash shield if removed. After the cleaning cycle is completed, verify that all build-up has been removed. If not, repeat the clean cycle procedure. Pour cleaning solution slowly onto Evaporator the front edge of evaporator plate plate behind the grid cutter.

  • Page 16: Warranty

    For products installed and used for normal residential use, material cosmetic defects are included in this warranty, with coverage limited to 60 days from the date of original purchase. All service provided by U-Line under the above warranty must be performed by a U-Line factory authorized servicer, unless otherwise specified by U-Line.

This manual is also suitable for:

Urcc115-ss81a
