- Page 1 USER GUIDE & SERVICE MANUAL Model: UOCR115-SS01A...
-
Page 2: Table Of Contents
USER GUIDE & SERVICE MANUAL Click on any section below to jump directly there Table of Contents Intro Product Liability Warranty Claims Safety Parts Safety and Warning Ordering Replacement Parts Disposal And Recycling System Diagnosis Guide Compressor Specifications Installation Troubleshooting Extended Environmental Requirements Defrost Electrical... - Page 3 U-Line Customer Care must be contacted immediately at +1.414.354.0300. Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been altered or repaired in the field without prior written approval from U-Line, claims will not be eligible.
-
Page 4: Safety And Warning
USER GUIDE Safety and Warning WARNING NOTICE CALIFORNIA PROPOSITION 65 Please read all instructions before installing, This product contains chemicals known to the operating, or servicing the appliance. state of California to cause cancer and birth defects or other reproductive harm. Use this appliance for its intended purpose only and follow these general precautions with those listed throughout this www.P65warnings.CA.gov... -
Page 5: Disposal And Recycling
USER GUIDE Disposal and Recycling DANGER RISK OF CHILD ENTRAPMENT. Before you throw away your old refrigerator or freezer, take off the doors and leave shelves in place so children may not easily climb inside. If the unit is being removed from service for disposal, check and obey all federal, state, and local regulations regarding the disposal and recycling of refrigeration appliances, and follow these steps completely:... -
Page 6: Environmental Requirements
USER GUIDE Environmental Requirements This unit is designed to operate between 50°F (10°C) and 100°F (38°C). Higher ambient temperatures may reduce the unit’s ability to reach low temperatures and/or reduce ice production on applicable models. For best performance, keep the unit out of direct sunlight and away from heat generating equipment. -
Page 7: Electrical
USER GUIDE Electrical WARNING SHOCK HAZARD — Electrical Grounding Required. Never attempt to repair or perform maintenance on the unit until the electricity has been disconnected. Never remove the round grounding prong from the plug and never use a two-prong grounding adapter. -
Page 8: Cutout & Product Dimensions
14 15⁄16” (379 mm) PREPARE SITE Your U-Line product has been designed for either free- standing or built-in installation. When built-in, your unit does not require additional air space for top, sides, or rear. However, the front grille must NOT be obstructed, FRONT 28”... -
Page 9: Side By Side Installation
USER GUIDE Side-by-Side Installation 3. Place bracket over holes and attach to unit with two screws removed in step 2 using a T-25 Torx driver. Two units may be installed side-by-side. Tighten screws fully. Cutout width for a side-by-side installation is the cutout 4. -
Page 10: Water Hookup
The water valve uses a standard 1/4" (6.35 mm) is under pressure at all times. Plastic may crack compression fitting. U-Line recommends using accessory or rupture with age and cause damage to your water hook up kit – part # ULAWATERHOOKUP. The kit home. - Page 11 USER GUIDE 3. Locate water valve inlet. 9. Install retaining clip. 4. Break away filler feature in bushing with flat screwdriver. Remove screwdriver 5. Thread water line through back panel hole (with bushing). 6. Locate water valve inlet and connect to valve. 7.
-
Page 12: Anti-Tip Bracket
USER GUIDE Anti-Tip Bracket Slide unit out so screws on top of unit are easily accessible. Remove the two screws from the opposite side of the hinge assembly using a T-25 Torx driver (see below). Place bracket over holes and attach to unit with two screws removed in step 2 using a T-25 Torx driver. -
Page 13: General Installation
USER GUIDE General Installation INSTALLATION Plug in the power/electrical cord. LEVELING INFORMATION Gently push the unit into position. Be careful not Use a level to to entangle the cord or water and drain lines, if confirm the unit is applicable. level. -
Page 14: Grille Installation
USER GUIDE Grille Installation REMOVING AND INSTALLING GRILLE WARNING Disconnect electric power to the unit before removing the grille. When using the unit, the grille must be installed. Removing the grille 1. Disconnect power to the unit. 2. Remove three screws (1). 3. -
Page 15: Door Swing
USER GUIDE Door Swing Wall 2-1/8" Min. (54 mm) 90° Door Swing Units have a zero clearance for the door to open 90°, when installed adjacent to cabinets. Stainless Steel models require 2-1/8" (54 mm) door clearance to accommodate the handle if installed next to a wall. -
Page 16: Door Adjust
USER GUIDE Door Adjustments TO REVERSE THE DOOR HINGE COVER Hinge cover included with the literature bag is optional. To install hinge cover: Press hinge cover squarely over hinge. Hinge Cover Remove arrow clips: With a putty knife or other flat tool, gently pry each arrow clip from hinge mounting holes. - Page 17 USER GUIDE Remove door by tilting forward and lifting door off bottom hinge. Retain shoulder washers; they will be Install gasket into channel, reused. beginning at one corner and pressing in firmly. Insert arrow clips into holes Press down on middle horizontal portion of gasket until it adheres to the door surface.
- Page 18 USER GUIDE First Use Initial startup requires no adjustments. NOTICE U-Line recommends discarding the ice produced during the first two to three hours of operation to avoid possible dirt or scale that may dislodge from the water line. To turn the unit on or off: Press the rocker switch located inside the door on the front panel, or behind the grille.
- Page 19 USER GUIDE CAUTION ICE MAKER OPERATION NEVER use an ice pick, knife or other sharp When the ice bucket is full, the ice making mechanism will instrument to separate cubes. Shake the ice shut off. However, the refrigeration system will continue bucket instead.
- Page 20 USER GUIDE ICE MAKER ADJUSTMENT 3. Turn the adjusting screw toward the minus (-) sign (clockwise) for smaller cubes or toward the plus (+) Ice Cube Thickness Adjustment sign (counterclockwise) for larger cubes. Interval - As Required 4. Install the ice maker assembly cover. On ice maker equipped models, adjust the cube size by changing water amount injected into the ice maker assembly as follows:...
- Page 21 USER GUIDE Airflow and Product Loading NOTICE The unit requires proper airflow to perform at its highest efficiency. Do not block the front grille at any time, or the unit will not perform as expected. Do not install the unit behind a door. Airflow and Product Loading...
-
Page 22: Cleaning
USER GUIDE Cleaning If any surface discoloring or rusting appears, clean it ® ® quickly with Bon-Ami or Barkeepers Friend Cleanser EXTERIOR CLEANING and a nonabrasive cloth. Always clean with the grain. ® Always finish with Claire Stainless Steel Polish and Vinyl Clad (Black or White) Models Cleaner or comparable product to prevent further Clean surfaces with a mild detergent and warm water... - Page 23 USER GUIDE DEFROSTING NOTICE Manual Defrost Models DO NOT clean ice bucket using a dishwasher. The This unit is a manual defrost model and will require bucket is not dishwasher safe and will be damaged. occasional defrosting. When there is build-up of 1/4" (6 mm) or more of frost, manually defrost the unit.
-
Page 24: Cleaning Condenser
USER GUIDE Cleaning Condenser INTERVAL - EVERY SIX MONTHS To maintain operational efficiency, keep the front grille free of dust and lint, and clean the condenser when necessary. Depending on environmental conditions, more or less frequent cleaning may be necessary. WARNING Disconnect electric power to the unit before cleaning the condenser. -
Page 25: Extended Non-Use
USER GUIDE Extended Non-Use For questions regarding winterization, please call VACATION/HOLIDAY, PROLONGED SHUTDOWN U-Line at 414.354.0300. The following steps are recommended for periods of extended non-use: CAUTION Remove all consumable content from the unit. Damage caused by freezing temperatures is not covered by the warranty. -
Page 26: Troubleshooting
• Condenser Fan: Air moving through a condenser may BEFORE CALLING FOR SERVICE be heard. If you think your U-Line product is malfunctioning, read • Running Water: As your unit continues to produce the CONTROL OPERATION section to clearly understand ice you will hear water flowing into the collection the function of the control. -
Page 27: Wire Diagram
USER GUIDE Wire Diagram Wire Diagram... -
Page 28: Product Liability
The part that caused the damage must be returned to U-Line in its entirety. The part must be clearly labeled with the serial number of the unit it was removed from, the date, and the servicer who removed the part. -
Page 29: Warranty Claims
Claims must be submitted online at • Final billing - Remodel www.U‑LineService.com Warranty parts will be shipped at no charge after U-Line • 60 day submittal deadline from date of completed confirms warranty status. Please provide the model, serial service number, part number and part description. -
Page 30: Parts
USER GUIDE Parts UOCR115-SS01A BACK PANEL 80-55392-00 BRAIDED WATER SUPPLY KIT* ULAWATERHOOKUP COMPRESSOR ELECTRICALS ONLY 80-54377-00 COMPRESSOR W/ELECTRICALS 80-54376-00 CONDENSER ASSEMBLY 80-54293-00 CONDENSER FAN BLADE 80-54379-00 CONDENSER FAN MOTOR 80-54378-00 CONTROL ASSEMBLY W/KNOB 80-54381-00 CONTROL KNOB 80-54382-00 DOOR ASSEMBLY 80-55549-00... -
Page 31: Ordering Replacement Parts
Warranty parts will be shipped at no charge after U-Line confirms warranty status. Please provide the model, serial number, part number and part description. Some parts will require color or voltage information. -
Page 32: System Diagnosis Guide
USER GUIDE u-line.com System Diagnosis Guide REGRIGERATION SYSTEM DIAGNOSIS GUIDE System Suction Suction Compressor Condenser Capillary Evaporator Wattage Condition Pressure Line Discharge Tube Normal Normal Slightly Very hot Very hot Warm Cold Normal below room temperature Overcharge Higher than Very cold... -
Page 33: Compressor Specifications
USER GUIDE Compressor Specifications DANGER Electrocution can cause death or serious injury. OVERLOAD PROTECTOR Burns from hot or cold surfaces can cause serious injury. Take precautions when servicing this unit. Disconnect the power source. STARTING RELAY Do not stand in standing water when working RELAY COVER ULIN_0576_AW around electrical appliances. -
Page 34: Troubleshooting Extended
USER GUIDE Troubleshooting - Extended SPECIFIC ERRORS & ISSUES CAUTION Never attempt to repair or perform maintenance on the unit until the main electrical power has been disconnected from the unit. TROUBLESHOOTING GUIDE Concern Potential Causes Suggested Remedy Will not eject ice Control setting too cold. - Page 35 USER GUIDE Concern Potential Causes Suggested Remedy Not freezing Power cord not plugged in. Plug in power cord. (compressor On/Off switch in off position. Turn switch to on position. and fans not On/Off switch inoperable (open). Replace On/Off switch. operating). Hold switch inoperable (open).
- Page 36 USER GUIDE ICE MAKER DIAGNOSIS FLOW CHART DOES THE UNIT REFRIGERATE? Sealed System Leak Low Voltage Electrical Failure Voltage Drop Compressor Failure Fan Wiring Motor Failure Defrost System Failure DOES THE UNIT HARVEST ICE IF THE EJECTOR BLADES ARE MOVED BY HAND OR WITH A WRENCH ? Temperature Control Failure Water Adjustment...
- Page 37 USER GUIDE ICE MAKER OPERATING CYCLES Freeze Cycle • Temperature control terminals 2 and 3 are closed. • Power to the condenser. • Power to the condenser fan. black black black SWITCH ground MOTOR brown WATER white VALVE COMP. OVER START LOAD black...
- Page 38 USER GUIDE Harvest-1 Cycle • Temperature control terminals 2 and 3 are open - 2 and 1 close. • No power to the compressor or condenser fan. • If bin arm is down, power goes through bin arm switch to the ice maker motor.
- Page 39 USER GUIDE HARVEST-2 CYCLE • Ice maker ejector blades reach approximately 2:00 position and cam depresses the hold switch. Power goes through the hold switch to the ice maker motor and mold heater. • Ejector blades stall on ice and ice maker motor pulsates until mold heater warms and ice releases.
- Page 40 USER GUIDE WATER FILL CYCLE • Ice maker ejector blades reach approximately 10:00 position and cam depresses the water fill switch. • Power to the water valve. Ice maker mold fills. black black black SWITCH ground MOTOR brown WATER white VALVE COMP.
- Page 41 USER GUIDE TEMPERATURE CONTROL SPECIFICATIONS Double Throw Ice Maker Thermostat Numbers 4548, AR-19-12, 2636, 2690, 2691, 2717, 2783, 2782-S, 2763-S, 2780, 80-26005-02 These temperature controls are double throw, single pole controls. The sensing tube is inserted into the ice maker mold and senses mold temperature.
- Page 42 USER GUIDE LIMIT SWITCH SPECIFICATIONS • Normally closed Bi-metal switch • Open temperature: 104°F • Close temperature: 83°F The function of this switch is to open in the event of an overheating condition. This bi-metal thermostat is normally closed and does not initiate the ice harvest cycle.
- Page 43 USER GUIDE REPLACING ICE MAKER ASSEMBLY (CO29F 8. Remove ice maker assembly. ONLY) 1. Unplug the unit from the main power source. 9. Place new ice maker assembly into position and secure with three screws (5). 2. Disconnect ice maker wire harness at plug (1). 10.Reconnect wire harness at plug.
- Page 44 USER GUIDE REPLACING ICE MAKER ASSEMBLY (ALL MODELS 17.Mount the back panel. EXCEPT CO29F) 1. Remove back panel. 18.Plug in unit and test. 2. Disconnect all wires at bell connectors (5 wires-Models 220 Volt Conversion List BI95, BI98 or SP18; or Plug-Models). All models listed in this manual are equipped to run on 110/115 volt.
-
Page 45: Defrost
USER GUIDE Defrost This unit requires manual defrost, periodically. Inspect the interior walls for frost build up every 3 - 4 weeks. Defrost your unit when 1/4” of frost builds up on the interior walls. Frost will build up faster in humid environments and when the door is opened frequently. -
Page 46: Replace Ice Maker
USER GUIDE USER GUIDE u-line.com SAFETY • INSTALLATION & INTEGRATION • OPERATING INSTRUCTIONS • MAINTENANCE • SERVICE Replace Ice Maker INSTALL ICE MAKER 1. If ice maker sits on evaporator (as shown) be sure to The new ice maker assembly you have received will have apply the included Alumilastic paste. - Page 47 For products installed and used for normal residential use, material cosmetic defects are included in this warranty, with coverage limited to 60 days from the date of original purchase. All service provided by U-Line under the above warranty must be performed by a U-Line factory authorized servicer, unless otherwise specified by U-Line.
Need help?
Do you have a question about the UOCR115-SS01A and is the answer not in the manual?
Questions and answers
Electric diagram
The electric diagram for the U-Line UOCR115-SS01A includes the following components and connections:
- ON/OFF switch (black wire)
- FAN (black wire)
- MOTOR (black wire, ground)
- WATER VALVE (brown and white wires)
- COMPRESSOR OVERLOAD and START RELAY (black wire)
- RELAY LOAD (black wire)
- HOLD SWITCH (blue wire)
- LIMIT SWITCH (yellow wire)
- ICE MAKER (black and orange wires)
- MOLD HEATER (orange wire)
Control terminals:
- When terminals 2 and 3 are open, 2 and 1 close.
- Bin arm position affects power to the ice maker motor:
- Arm down: power flows through bin arm switch.
- Arm up: ice maker does not harvest.
During the HARVEST-2 cycle:
- Ejector blades move to approximately the 2:00 position.
- Cam depresses the hold switch.
- Power flows through the hold switch to the ice maker motor and mold heater.
- Motor pulsates until the heater warms and releases the ice.
