User manual
DAS1800
High Speed Modular Data
Acquisition Recorder
bkprecision.com - sefram.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sefram DAS1800 and is the answer not in the manual?

Questions and answers

Summary of Contents for BK Precision Sefram DAS1800

  • Page 1 User manual DAS1800 High Speed Modular Data Acquisition Recorder bkprecision.com - sefram.com...
  • Page 2: Safety And Symbols

    Sefram CHAPTER 1. SAFETY AND SYMBOLS Chapter 1 Safety and symbols To ensure proper use of the unit, please observe the safety and operating requirements described in this manual. Specific warning signals appear throughout this manual to draw your attention to important points. Please read the following instructions in this chapter carefully before using your Data Acquisition System.
  • Page 3: Category Rating

    Sefram CHAPTER 1. SAFETY AND SYMBOLS Before powering up the device : • Read and understand the safety and operating information in this manual. • Follow all listed safety precautions. • Operating the instrument with the wrong supply voltage voids the warranty •...
  • Page 4: Ground The Instrument

    Sefram CHAPTER 1. SAFETY AND SYMBOLS 1.0.3 Ground the instrument To minimize the risk of electric shock, the chassis of the instrument must be connected to a safety ground. The instrument is earthed via the earth conductor of the supplied power cable, which must be plugged into an approved three-conductor electrical socket.
  • Page 5: Operating Environment

    Sefram CHAPTER 1. SAFETY AND SYMBOLS 1.0.7 Operating environment The instrument is designed for use in pollution degree 2 indoor environments. The operating temperature range is 0 to 40 degrees Celsius and a relative humidity of 20% to 80%, non-condensing at an altitude < 2000 meters. Measurements taken with this instrument may be out of specification if the instrument is used in environments that may include rapid changes in temperature or humidity, sunlight, mechanical vibration and/or shock, acoustic noise, electrical noise, strong electric fields or strong magnetic fields.
  • Page 6: Particular Precautions

    Sefram CHAPTER 1. SAFETY AND SYMBOLS 1.0.8 Particular precautions To avoid electric shock, observe the following precautions when working with dangerous voltages: • Do not use this product for purposes other than those for which it is intended. • Before using the recording device, make sure that the instrument and the equipment required for its use (measuring lead, external box, accessories...) are in working order.
  • Page 7: Concerning The Exported Devices In North America

    Sefram CHAPTER 1. SAFETY AND SYMBOLS 1.0.9 Concerning the exported devices in North America This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 8: Table Of Contents

    Sefram CONTENTS Contents 1 Safety and symbols 1.0.1 Category rating ..........1.0.2 Power supply .
  • Page 9 Sefram CONTENTS 3.7 Start and stop settings ..........34 3.7.1 Manual : .
  • Page 10 Sefram CONTENTS 7.4 Network settings ..........88 7.4.1 Ethernet .
  • Page 11 Sefram LIST OF FIGURES List of Figures 2.1 General views ..........14 2.2 Supplied accessories .
  • Page 12 Sefram LIST OF FIGURES 5.1 Unit libraries ..........57 5.2 Creation of a "pound"...
  • Page 13 Sefram LIST OF TABLES List of Tables 1.1 Symbols on the device ..........1.2 Symbols in the manual .
  • Page 14: Introducing The Device

    Sefram CHAPITRE 2. INTRODUCING THE DEVICE Chapitre 2 Introducing the device Introduction SEFRAM thanks you for your confidence in us and is pleased to present the DAS1800. This new-generation multi- channel Data Acquisition System is developed and manufactured in France. Its ability to record and analyze all types of electrical signals (sensors, electrical relays, electrical networks, etc.) makes it ideal for a wide range of industrial applications (maintenance, R&D, production, etc.).
  • Page 15: Supplied Accessories

    Sefram CHAPITRE 2. INTRODUCING THE DEVICE 2.2.1 Supplied accessories The device is provided with : Main power cord (IEC) Carrying case Sub-D15 HD connector (x1) Sub-D25 connector (x1) 8-pin connector for external power supply output 4-pin connector (x8) (with multiplexed board) Pair of male banana plug connectors (x4) (for universal and high-voltage acquisition boards) 2.2 : Supplied accessories...
  • Page 16: Acquisition Modules

    Sefram CHAPITRE 2. INTRODUCING THE DEVICE 2.2.2 Acquisition modules When you order the device, you can choose from four different types of modules : universal, multiplexed, high- voltage or high-impedance. Each has its own technical characteristics (see technical specifications section for details).
  • Page 17: Interfaces

    Sefram CHAPITRE 2. INTRODUCING THE DEVICE 2.2.3 Interfaces The various device interfaces are shown in the following diagrams : 2.4 : View from above IGURE Symbol Description On/off push-button Ethernet port for connecting the device to a computer network (x2) (see remote control section) HDMI port for transferring the screen display to an external display (connect the HDMI cable before starting up the device)
  • Page 18: Optional Accessories

    Sefram CHAPITRE 2. INTRODUCING THE DEVICE Symbol Description Sub-D25 connector for logical channel inputs and outputs (see logical channels section) Sub-D15 connector for external synchronization (See external synchronization section) Power supply and fuse support (2 x T4AL 250 V) Chassis ground connector External power supply Protective earth terminal (battery operation) 2.2.4 Optional accessories...
  • Page 19: Interface And Ergonomic

    Sefram CHAPITRE 2. INTRODUCING THE DEVICE Interface and ergonomic 2.3.1 Touch control The product is designed for smartphone-type touch screen use. The following movements are implemented: • Single tap: performs an action • Drag & drop: moves graphic objects • 2-finger zoom •...
  • Page 20: Built-In Help

    Sefram CHAPITRE 2. INTRODUCING THE DEVICE Built-in help 2.5.1 Tool type When you long-click on a button, a tooltip displays help on the corresponding action. 2.5.2 Help window Clicking on the question mark icon opens a help window. 2.5.3 On-board user manual The user manual is embedded in the product and available from any page by clicking on the manual button in the main menu bar at the top of the page.
  • Page 21: Getting Started

    Sefram CHAPITRE 3. GETTING STARTED Chapitre 3 Getting started Installing and removing acquisition modules Module installation and removal must be carried out with the power off. When doing so, switch off the device and ensure that no cables are connected to the module inputs. Add an acquisition module : The module plugs into the device as a simple way.
  • Page 22: File Creation

    Sefram CHAPITRE 3. GETTING STARTED File creation Before starting a measurement campaign, we recommend that you organize your files in advance. To do this, go to "File Manager" in the navigation bar. Figure 3.2: File Manager "sda1" (solid drive a1) (1) corresponds to the contents of the device’s disk memory. It is also available by pressing "DISK"...
  • Page 23: Channels And Measurements

    Sefram CHAPITRE 3. GETTING STARTED Figure 3.3: File creation By default, screenshots (1) and measurement recordings (2) are at the root of the disk. Click on create a new folder, name and select it then click on "choose as working directory". Figure 3.4: File creation as working directory Channels and measurements A channel corresponds to a physical input to the device.
  • Page 24: Analog Channel Settings

    Sefram CHAPITRE 3. GETTING STARTED Analog channel settings To access acquisition board analog channel settings, use the main navigation bar by clicking on "configuration" then "channels". 3.5 : Analog channel settings IGURE On this page you can view the table containing all the parameters of the analog channels. It is possible to filter the display of channels by acquisition card present on the device (1), and to customize the display of information given in columns (2).
  • Page 25: Channel Configuration

    Sefram CHAPITRE 3. GETTING STARTED By pressing directly on a measurement in the left pane (4), you can delete it, access the channel parameters or access the recording frequency settings. 3.4.1 Channel configuration By pressing in the configure column, you open the complete page of channel parameters shown above. 3.6 : Page configuration IGURE 1.
  • Page 26: Specific Measurements

    Sefram CHAPITRE 3. GETTING STARTED By pressing the icon shown below, you can duplicate all the parameters of the selected channel to other channels on the device. 3.7 : Copying parameters from an analog channel IGURE 3.4.2 Specific measurements Meter Measurand used to count the number of trigger signals according to a manually or automatically defined threshold.
  • Page 27: Derivative Calculation With Sine Signal

    Sefram CHAPITRE 3. GETTING STARTED 3.9 : Derivative calculation with sine signal IGURE One solution is to attenuate the noise present in the signal by applying a digital filter. The following figure shows the derivative of the same signal using a low-pass Butterworth digital filter (order 4) with cut-off frequency = 1/(6∆...
  • Page 28 Sefram CHAPITRE 3. GETTING STARTED Integral The signal is sampled at a frequency of 1 MHz, giving one sample every microsecond. The signal integral is obtai- ned by accumulating the sample values (V.µS). The integral value is obtained in V.s by dividing the accumulated value by the sampling frequency.
  • Page 29: Digital Channels Setting

    Sefram CHAPITRE 3. GETTING STARTED Digital channels setting Digital channels are accessible via the device’s 25-pin D-Sub connector. To access digital channel settings, press Configuration > Channels > Digital. The optional digital channel cable accessory allows all digital channels to be wired using standard banana plugs, giving you greater convenience when wiring your equipment.
  • Page 30: Logic Inputs (Vlog)

    Sefram CHAPITRE 3. GETTING STARTED 3.5.1 16 logic inputs (Vlog) To open all the parameters of a digital input, press the symbol from the measure colomn : The logic inputs can monitor all signals up to 24V. To increase the maximum permissible voltage, the Logic channel box option 917008000 is available.
  • Page 31: Power Supply Outputs

    Sefram CHAPITRE 3. GETTING STARTED 3.5.2 Power Supply Outputs The external power supply located on the 25-pin D-Sub connector provides a nominal voltage of 12V +/- 5% with a maximum delivered current of 200 mA (limited by resettable fuse). There are also 3 others power supply outputs (3.3V, 5V, 12V, 24V) on the rear pannel (5W maximum) : For example, the power supply can be used to power a sensor.
  • Page 32: Sampling Frequency

    Sefram CHAPITRE 3. GETTING STARTED For example, if the filename is set to "RecordFile" and the "Suffix by date" box is checked, we could have a file called: RecordFile_23-01-28_15_02_28_792.mf4 corresponding to a record from 28/01/2023 at 15:02:28.792. Caution: If the "Suffix by date" function is deactivated, you must manually change the file name for each recording, otherwise the last recording will systematically overwrite the previous one and you will lose your data.
  • Page 33: Setting Recording Frequencies

    Sefram CHAPITRE 3. GETTING STARTED 3.14 : Setting recording frequencies IGURE You can customize the information displayed using the displayed columns field (1), and filter the channel display using the Filter by name field (2). 4 different sampling frequencies can be set (3). The same measurement can be recorded at a single frequency.
  • Page 34: Start And Stop Settings

    Sefram CHAPITRE 3. GETTING STARTED The overall throughput (sum of the throughput of the 4 groups) is limited to 120MB/s. The speed of the 1st group is limited to 100MB/s, the other groups are limited to 10MB/s each. Start and stop settings To set your acquisition trigger conditions, go to Configuration >...
  • Page 35: Signal Trigger

    Sefram CHAPITRE 3. GETTING STARTED 3.7.3 Signal trigger Level : The user can program recording start and stop conditions according to the values measured on the analog and digital channels : 3.17 : Trigger on level IGURE First define the physical channel and its associated measurement to which you want to apply the trigger condi- tion (1).
  • Page 36: Edge Trigger

    Sefram CHAPITRE 3. GETTING STARTED 3.18 : Edge trigger IGURE Trigger on slope (available in a later version) 3.19 : Trigger on slope IGURE To set up a slope trigger, also define the physical channel and associated measurement to which you wish to apply the recording condition (1).
  • Page 37: Pre-Trigger

    Sefram CHAPITRE 3. GETTING STARTED Combination of trigger conditions It is possible to combine several conditions on several channels which, once verified, will start/stop recording. When several conditions are set, the user selects the "AND" or "OR" connector : • AND : All defined conditions must be true simultaneously for recording to start/stop. •...
  • Page 38: Post-Trigger

    Sefram CHAPITRE 3. GETTING STARTED 3.22 : Inhibit function IGURE 3.7.5 Post-trigger The user can set a time during which the device continues to record after the stop condition has been triggered. 3.23 : Post-trigger IGURE User manual...
  • Page 39: Rearm

    Sefram CHAPITRE 3. GETTING STARTED 3.7.6 Rearm The user can choose the rearm mode : • « Single shot » : Only one recording file is done • « Auto » : At the end of the recording, the device will automatically start a new record, waiting for the start condition (like if you pressed again the ’start record’...
  • Page 40: Creation Of Configuration File

    Sefram CHAPITRE 3. GETTING STARTED Figure 3.24: Creation of configuration file When a configuration file is created, it is linked to the type and location of the measurement mod- ules in the device. If the device configuration changes, the file is no longer compatible. User manual...
  • Page 41: External Sync

    Sefram CHAPITRE 3. GETTING STARTED External sync The external synchronisation channels are located on the sub-D15 connector on the device. To access the logic channel settings, press Configuration > Sync > External sync. These are trigger signals for other devices linked to the recording in progress.
  • Page 42: Chronogram Start / Stop

    Sefram CHAPITRE 3. GETTING STARTED Start / Stop The Start/Stop (pin 11 Ext sync start/stop on the connector) is a signal indicating the start of recording (manually by pressing the Start button or automatically via the reset or remote control). When the device is on stand-by or after recording has been stopped (by pressing the Stop button), the output signal is 0 V.
  • Page 43: Measurement Data Display

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY Chapitre 4 Measurement data display Real-time display To view your measurements in real time, click on the "real time" tab in the main navigation bar : 4.1 : Real-time data display IGURE To view previously configured measurements, drag and drop them into the graph area (1). You can also add or remove a measurement from the graph area by pressing and holding in the graph area.
  • Page 44: F(T) : Oscilloscope

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY 4.1.1 F(t) : Oscilloscope See “visualization and graphic analysis” chapter for details on the functionnality of the graph widget. Real time display mode 4.2 : F(t) in oscilloscope mode IGURE The real-time F(t) display has several display behaviors : •...
  • Page 45: Dmm Display

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY 4.1.2 DMM display DMM mode displays real-time measurements in digital format. In order to be human readable, the value displayed is an average. You can use the HDMI output of the device to transfer the image to an external screen. 4.3 : DMM display IGURE To display measurements in numerical format, simply press and drag the measurement over the graphic area.
  • Page 46: Dmm Average Period Setting

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY 4.4 : DMM average period setting IGURE The DMM average period can be set on 200ms or 2s. The number of samples used for the calcula- tion depends on the acquisition module speed frequency. For instance, with an universal acquisition module, it will be 1 MSa/s.
  • Page 47: Custom Display

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY 4.1.3 Custom display These two dashboards (custom 1 and custom 2) are fully configurable. They are saved in the configuration export. Up to 16 widgets can be displayed simultaneously. Widgets can be of different types. •...
  • Page 48: Visualization And Graphical Analysis

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY Visualization and graphical analysis The user interface for viewing F(t), or analyzing a recording on the device or on a PC (via DASpro software) is similar. To display the measurement, drag-and-drop it into the graph area (1), and adjust the desired scale using the various touch gestures : 4.6 : Min and max settings for X and Y axes IGURE...
  • Page 49: Zooming In And Out On X And Y Axes

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY 4.7 : Zooming in and out on X and Y axes IGURE By moving the thumb and forefinger closer or further apart on the Y ordinate axis (amplitude), it’s possible to zoom in and out between the defined limits (1). The same applies to the X-axis, to change the time base (2). On a computer or if a mouse is connected to the device, use the mouse wheel to perform this function, positioning the cursor on the desired axis.
  • Page 50: Mathematical Calculations

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY Symbol Description Selects the measurements to be displayed in the graphics area Allows you to set display parameters : division of the graphics area into several screens, choice of colors, background image, etc. Shows/hides vertical and horizontal cursors Displays/hides full name of displayed measurement(s) with access to display parameters Displays/hides predefined mathematical calculations in real time...
  • Page 51: Calculation Settings

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY Click on the "Measurements" window to open the calculation settings manager. 4.10 : Calculation settings IGURE 1. Window display management 2. Channel and calculation type selection 3. Add" button to display the calculation selected in (2) 4.
  • Page 52: Type Of Calculation

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY 4.3.2 Type of calculation 20 different mathematical calculations are offered, divided into 3 categories : • Amplitude : minimum, maximum, peak-to-peak, low, high, amplitude, over oscillations • Time : frequency, period, rise and fall times, positive and negative widths, positive and negative duty cycles •...
  • Page 53 Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY Negative M in overshoot Amplitude Frequency Average frequency P eriod Average duration of a complete cycle calculated N Duration f ull period Period over as many periods as possible T1 = 10% Amplitude T2 = 90% Amplitude Rise time Rise time = T2 T1 T1 = 90% Amplitude...
  • Page 54: Analyzing A Record

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY Calculation over the entire RM S = (V ) graphical window RMS cycle RM S = (V ) Analyzing a Record To open a saved measurement file, go to “Drive” from the main navigation bar. 4.11 : Saved file list IGURE By pressing “Data”...
  • Page 55: File Transfer

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY File transfer 4.5.1 File retrieval via USB key Plug a USB key into one of the device’s ports. To retrieve a file from the device’s hard disk and transfer it to your computer, go to "File Manager" from the main navigation bar. Press "DISK" to access the entire contents of the device’s internal memory.
  • Page 56: File Transfer Via Ftp Protocol

    Sefram CHAPITRE 4. MEASUREMENT DATA DISPLAY 4.5.2 File transfer via FTP protocol If you want to retrieve files from the device remotely, connect it to a computer network via the Ethernet port or Wi-Fi option. For more information, see remote control section. Then go to Configuration >...
  • Page 57: Advanced Features

    Sefram CHAPITRE 5. ADVANCED FEATURES Chapitre 5 Advanced features Units library The units of measurement are managed from a database accessible from Configuration > Channels > Units library. 5.1 : Unit libraries IGURE By default, most of the most commonly used units of measurement are already built into the device. To add a unit, press "Create a unit"...
  • Page 58: Creation Of A "Pound" Unit

    Sefram CHAPITRE 5. ADVANCED FEATURES 5.2 : Creation of a "pound" unit IGURE Define the name of the unit (1) and the associated symbol (2). Choose the corresponding physical quantity from the drop-down list (3). In our case, the pound is a mass. Finally, define the conversion function (4). The conversion function is a calculation applied to the reference unit of the international system, which in the case of mass is the kg.
  • Page 59: Sensors Library

    Sefram CHAPITRE 5. ADVANCED FEATURES Sensors library Each measurement is associated with a sensor. To access the sensor library, go to Configuration > Channel > Sensors library A table listing all sensors and their parameters is shown on this page. 5.3 : Sensors library table IGURE You can search for sensors already in the library by name (1) or filter the information given by column for each...
  • Page 60: Ma Sensor Settings

    Sefram CHAPITRE 5. ADVANCED FEATURES 5.4 : 4-20 mA sensor settings IGURE Set sensor type to "4-20mA with shunt" (1). Enter the unit of the sensor physical input (2). Enter the associated information in the various fields (3). If the unit is not available in the drop-down list, you can add it manually. The min and max fields correspond to the display range of the measured variable (4).
  • Page 61: The Different Types Of Digital Filter

    Sefram CHAPITRE 5. ADVANCED FEATURES The different types of digital filter The user can choose between 4 different types of digital filters: 5.3.1 Low-pass filter The low-pass filter is a device that exhibits a relatively constant frequency response (fixed gain) at low frequencies and a decreasing gain at frequencies above the cut-off frequency.
  • Page 62: Bandpass

    Sefram CHAPITRE 5. ADVANCED FEATURES 5.3.3 Bandpass The bandpass filter is a device that demonstrates a relatively constant gain in the passband (band of frequencies between a low cutoff frequency and a high cutoff frequency), increasing gain at frequencies below the low cutoff frequency (40 dB / decade) and decreasing gain at frequencies above the high cutoff frequency (40 dB / decade).
  • Page 63: Filter Prototype

    Sefram CHAPITRE 5. ADVANCED FEATURES 5.3.5 Filter prototype The filtering performed is infinite impulse response. An infinite impulse response filter (IIR filter) is a type of electronic filter characterized by a response based on the values of the input signal and previous values of the same response.
  • Page 64: Butterwork Low-Pass Filter: Bode Diagram

    Sefram CHAPITRE 5. ADVANCED FEATURES Butterworth The Butterworth characteristic is probably the most commonly used for signal filtering. This characteristic is said to be "the flattest in frequency". The parameters of this type of filter are arranged so as to achieve the most constant gain possible in the passband and -3 dB attenuation at the cutoff frequency, whatever the filter order.
  • Page 65: Butterwork Low-Pass Filter: Impulse Response

    Sefram CHAPITRE 5. ADVANCED FEATURES Figure 5.8: Butterwork low-pass filter: Impulse response Chebyshev In contrast to the Butterworth characteristic, the Chebyshev characteristic presents a ripple in the passband. How- ever, it offers better attenuation around the cut-off frequency. The passband ripple is fixed at 0.1 dB. This filter is widely used when ripple is not a problem.
  • Page 66: Chebyshev Low-Pass Filter: Index Response

    Sefram CHAPITRE 5. ADVANCED FEATURES Figure 5.10: Chebyshev low-pass filter: Index response Figure 5.11: Chebyshev low-pass filter: Impulse response User manual...
  • Page 67: Bessel Low-Pass Filter: Bode Diagram

    Sefram CHAPITRE 5. ADVANCED FEATURES Bessel The Bessel filter, also known as the Thompson filter, is a filter whose main characteristic is to offer a constant bandwidth delay. In concrete terms, this means that all pure, in-band frequencies pass through it in exactly the same time.
  • Page 68: Bessel Low-Pass Filter: Impulse Response

    Sefram CHAPITRE 5. ADVANCED FEATURES Figure 5.14: Bessel low-pass filter: Impulse response Comparison of the 3 filter types Butterworth / Chebyshev / Bessel Figure 5.15: Filter comparison: Bode diagram User manual...
  • Page 69: Filter Comparison: Index Response

    Sefram CHAPITRE 5. ADVANCED FEATURES Figure 5.16: Filter comparison: Index response Figure 5.17: Filter comparison: Impulse response User manual...
  • Page 70 Sefram CHAPITRE 5. ADVANCED FEATURES Cheybyshev inversé The Chebyshev type 2 filter, also known as inverse Chebyshev, has monotonic passband attenuation, like the Butterworth filter, and ripples in the stopband. This filter has a better group delay, which means less distortion of complex signals.
  • Page 71: Cold Welding Compensation

    Sefram CHAPITRE 5. ADVANCED FEATURES Papoulis The Papoulis filter provides a compromise between the Butterworth filter, which is monotonic but has slower atten- uation, and the Chebyshev filter, which has faster attenuation but has ripple in the passband or stopband. Cold welding compensation When two wires composed of different metals are connected at their ends and one of them is heated, direct current flows through the circuit.
  • Page 72 Sefram CHAPITRE 5. ADVANCED FEATURES The resulting voltage measured by the voltmeter is equal to V1-V2, that is, it is proportional to the temperature difference between J1 and J2. J2 junction is called reference junction or cold weld. By measuring the temperature of the reference junction using a temperature sensor, it is possible to deduce the temperature of the hot weld.
  • Page 73 Sefram CHAPITRE 5. ADVANCED FEATURES No correction No cold welding correction is applied. The temperature returned to the user is the temperature of the thermocouple table associated with the measured voltage. This option can be used if the user wants to measure the temperature difference obtained by two different thermocouples via the use of scripts (calculations between channels).
  • Page 74: Adjusting The Zero

    Sefram CHAPITRE 5. ADVANCED FEATURES Adjusting the Zero The adjustment of the zero of the universal boards and the cold welding of the thermocouples are managed from a database accessible from Configuration > Channels > Adjustment Figure 5.18: Zero adjustment 1.
  • Page 75: Alarms Setting (Available In A Later Version)

    Sefram CHAPITRE 5. ADVANCED FEATURES Alarms setting (available in a later version) 5.6.1 4 logic output (Alarms) Alarms A, B, C and D send a TTL voltage signal when the set event occurs. 5.19 : Sorties alarmes IGURE When activating a logic output, you must first define the alarm type (1) : •...
  • Page 76: Remote Control

    Sefram CHAPITRE 5. ADVANCED FEATURES Remote control To use the remote control functions, the device must be connected to a network. Please refer to the "Network settings" chapter for further information on configuration. 5.7.1 Web server The system incorporates a web server function, enabling a connection to be established via the Internet from a web browser.
  • Page 77: Vnc Configuration

    Sefram CHAPITRE 5. ADVANCED FEATURES 5.21 : VNC Configuration IGURE Download the VNC viewer® application, launch the utility and go to File > New connection (1). Enter the device IP address in the VNC server field (2). 5.22 : New VNC viewer® connection IGURE The new connection appears in the list, click to connect : You can secure your connection with a password.
  • Page 78: Connection

    Sefram CHAPITRE 5. ADVANCED FEATURES 5.23 : Connection IGURE You can then operate the device with full access to all functions : 5.24 : VNC viewer® control IGURE User manual...
  • Page 79: Scpi Protocol

    Sefram CHAPITRE 5. ADVANCED FEATURES SCPI protocol SCPI (Standard Commands for Programmable Instruments) is a universal programming language for electronic test and measurement instruments, based on the IEEE 488.1 and IEEE 488.2 standards. Commands are ASCII textual strings which are sent to the instrument over the physical layer. Commands are a series of one or more keywords, many of which take parameters.
  • Page 80: Mdf4 File Format

    Sefram CHAPTER 6. MDF4 FILE FORMAT Chapter 6 MDF4 file format Measurement Data Format version 4 (MDF4) is an ASAM file standard for storing measurement data in a binary file format. For more information about the MDF4 file format, please visit https://www.asam.net/standards/detail/mdf/wiki/. Format The MDF contains both raw measurement data and the metadata needed to interpret the raw data.
  • Page 81: Example

    Sefram CHAPTER 6. MDF4 FILE FORMAT Example Here’s an example of a Python implementation using the Asammdf library to open an MDF4 record Listing 6.1: Example of using the MDF4 library in Python from asammdf i m p o r t mdf = MDF( ’...
  • Page 82: System

    Sefram CHAPITRE 7. SYSTEM Chapitre 7 System Ergonomic settings To set the general system settings, go to Configuration > System 7.1 : Access to system settings IGURE You’ll then be able to adjust : • Screen : brightness, screen saver •...
  • Page 83: Path To Update Access

    Sefram CHAPITRE 7. SYSTEM 7.2 : Path to update access IGURE To launch the update, you only have to click on the button « Load from WEB». The update is launched automatically. 7.3 : WEB update option selection IGURE If the update fails : Check that the device is connected to the network (Ethernet cable). User manual...
  • Page 84: Usb Key Option Selection

    Sefram CHAPITRE 7. SYSTEM Load from USB key (2) Retrieve the DAS1800 software update folder from the SEFRAM website (https ://www.sefram.com/mises-a-jour-logicielles.html). Do a save-sub and select the USB key. Use a blank USB key formatted in FAT32. Safely remove the USB key from the PC or device using the "Eject USB key" option. Plug the USB key into one of the device’s available ports To access the software update page, follow the steps below : 1.
  • Page 85: Update From File Menu

    Sefram CHAPITRE 7. SYSTEM Load from local file (3) If the other 2 semi-automatic update methods have not worked, use this one Follow the procedure below : 1. Go to « Files Manager » menu 2. Go to the « USB » submenu 3.
  • Page 86: Update Progress Pop-Up

    Sefram CHAPITRE 7. SYSTEM Update progress Once the update is launched, a pop-up window will appear to track the progress of the update. 7.6 : Update progress Pop-up IGURE Do not switch off the device during software update. If using a battery, check that the device has sufficient autonomy.
  • Page 87: Time Setting

    Sefram CHAPITRE 7. SYSTEM Once the device has started up, an information pop-up will open to confirm that the device has been updated to the new version. 7.7 : Pop-up user info IGURE Time setting 7.3.1 Manual Select the system time manually. This parameter is used if the system is isolated (without network) and loses its internal clock.
  • Page 88: Network Settings

    Sefram CHAPITRE 7. SYSTEM Network settings 7.4.1 Ethernet To connect your device to a network, go to Configuration > System > Network : 7.8 : Network configuration page IGURE It is possible to configure 2 different Ethernet networks on the device simultaneously (1). Give your network a name (3) .
  • Page 89: Enp2S0 Interface

    Sefram CHAPITRE 7. SYSTEM 7.9 : Enp2s0 Interface IGURE If your network is directly connected to a DHCP server via a router, you need to check DHCP mode (1). Your network will automatically assign an available network address to your device, thus avoiding address conflicts. In some cases, if the user does not have access to the corporate network, a point-to-point connection is requi- red.
  • Page 90: Fixed Ip Address Setting

    Sefram CHAPITRE 7. SYSTEM 7.10 : Fixed IP address setting IGURE The device is connected to the PC via ethernet cable, and the configurations are as follows : 7.11 : Manual IP configuration of PC and the recorder IGURE The configuration shown below is an example. If you have any doubts about your settings, please contact your IT department.
  • Page 91: User Level

    Sefram CHAPITRE 7. SYSTEM In a point-to-point connection, you can send SCPI commands using the supplied programming manual. This means you can edit and run your own script over an isolated connection. User level Several user levels can be defined, giving access to more or less advanced functions and information. The aim is to simplify the user interface as required: Figure 7.12: User level Viewer level:...
  • Page 92: Bug Report

    Sefram CHAPITRE 7. SYSTEM Bug report If you notice a malfunction while using the device, a dedicated bug report menu is available: Configuration > System > Bug report Figure 7.13: Créer un rapport de bogue Fill in the various fields, providing as much detail as possible. If you suspect a software problem, please check the boxes to include the system and configuration files in the report (1).
  • Page 93: Technical Specifications

    Sefram CHAPTER 8. TECHNICAL SPECIFICATIONS Chapter 8 Technical specifications User manual...
  • Page 97: Metrology

    Sefram CHAPTER 9. METROLOGY Chapter 9 Metrology Calibration You are in possession of a measuring instrument for which the metrological conditions of measurement are de- fined in the specifications of this manual. Climatic and environmental conditions limit the specifications of your instrument.
  • Page 98: Servicing

    Sefram CHAPTER 10. SERVICING Chapter 10 Servicing 10.1 For users not based in America 10.1.1 Warranty Your instrument is guaranteed for three years (36 months) parts and labor against any manufacturing defect or operating hazard. This warranty begins on the date of delivery and ends 1095 calendar days later. If the device is covered by a warranty contract, the latter supersedes or replaces the warranty conditions listed above.
  • Page 99: After-Sales Contact

    Sefram CHAPTER 10. SERVICING The warranty period for after-sales service outside the appliance warranty period is 3 months. All spare parts become the property of the user, and replaced parts become the property of SEFRAM. In the event of insurance coverage, the product becomes the property of the insurance company at its exclusive request.
  • Page 100: For Users Based In America

    Sefram CHAPTER 10. SERVICING Figure 10.1: Display areas Acceptance criteria: • Zone A (central zone): fewer than 5 defective pixels in total and fewer than 3 contiguous pixels. • Zone B (total screen area): less than 9 defective pixels over the entire screen area, with Zone A conditions met.
  • Page 101: Packaging

    Sefram CHAPTER 10. SERVICING B&K Precision Corp. : 22820 Savi Ranch Parkway Yorba Linda,CA 92887 bkprecision.com 714-921-9095 The device must be accompanied by a detailed description of the fault, and must be returned with all standard accessories (cords, plugs, etc.). Consumables (batteries, etc.) and optional accessories (case, bag, etc.) are guaranteed for 3 months against manufacturing defects.
  • Page 102: Display Areas

    Sefram CHAPTER 10. SERVICING surface. SEFRAM’s quality department has made installation of your instrument’s display conditional on compli- ance with the manufacturers’ acceptance conditions. Figure 10.2: Display areas Acceptance criteria: • Zone A (central zone): fewer than 5 defective pixels in total and fewer than 3 contiguous pixels. •...
  • Page 103: Annexes

    Chapitre 11 Annexes 11.1 Revisions Version and date Firmware version associated Modified chapters Modification type 1.0 - 10/2023 1.0.x Document creation 3.6.2 Added clarification on the choice of recording frequencies Added reset function 4.1.1 Added synchronized F(t) mode 1.1 - 01/2024 1.1.x 4.4.2 Adding FTP login credentials...
  • Page 104: Scpi Protocol

    Sefram CHAPITRE 11. ANNEXES 11.2 SCPI Protocol 11.2.1 Physical layer SCPI is based over the LAN interface that can be connected via a commercial RJ-45 cable to a network with TCP/IP protocol. The TCP port used is 23 (Telnet port) or 5025 (both are enabled on the device). 11.2.2 Command syntax SCPI commands to an instrument may either perform : •...
  • Page 105: Exemples

    Sefram CHAPITRE 11. ANNEXES 11.2.3 Exemples >> Send : *IDN? << Rcv : DAS1800 V0.0.4 (N0012) >> Send : VALID? << Rcv : Ch_B1 ;Ch_B2 ;Ch_B3 ; >> Send : *OPT? << Rcv : No options >> Send : DAT? <<...
  • Page 106: Programming Dictionary

    11.2.4 Programming dictionary Requests list HEADER DESCRIPTION RESPONSE EXEMPLE *IDN ? Identification request SEFRAM, SEFRAM 8460 Version 4.7.2 Product Name, (N :00010) Serial Numer, VersionMajor.VersionMinor *OPT ? Idendtification of options Number of acquition boards :DATe ? Return the current date Day,Month,Year 30,12,2022 :HOUrs ?
  • Page 107 Command list HEADER DESCRIPTION PARAMETERS EXEMPLE *REM Start remote control *REM *LOC Stop remote control *LOC :MEMSpeed Set recording frequency Frequency (Hz) :MEMSpeed 10000 Start or stop recording on the device REC ON TRIG (useful if the device is in state « Waiting for trigger »...
  • Page 108: Exemple

    Sefram CHAPITRE 11. ANNEXES 11.2.5 Exemple Bellow an exmple of Python implementation Listing 11.1 : SCPI python implemntation exemple i m p o r t t i m e i m p o r t t e l n e t l i b TIMEOUT = 0 .
  • Page 109 EU DECLARATION OF CONFORMITY DECLARATION DE CONFORMITE UE Manufacturer’s Name: SEFRAM INSTRUMENTS SAS Nom du fabricant : 32, rue Edouard MARTEL Manufacturer’s Address: 42009 SAINT-ETIENNE Cedex 2 (FRANCE) Adresse du fabricant : declares under sole responsibility that the below mentioned product(s) déclare sous sa seule responsabilité...
