GENERAL BEST PRACTICES FOR ASSEMBLY: *Please read the assembly instructions prior to assembling this product. *Determine you have adequate space for assembly. *Assembly by two adults is recommended. *Assemble on soft surfaces to prevent damage to product finish. *Keep children away during assembly. This item contains small parts which can be swallowed by children. -
Page 3: Part List
PART LIST BACK TABLE LEG LEFT FRONT TABLE LEG TABLE TOP x 1 PC x 2 PCS x 1 PC RIGHT FRONT TABLE LEG LONG STRETCHER SHORT STRETCHER x 1 PC x 1 PC x 2 PCS HARDWARE LIST ALLEN BOLT x 8 pcs SPRING WASHER x 8 pcs FLAT WASHER x 8 pcs 5/16"... - Page 4 STEP 1 HARDWARE NEEDED BOTTOM Note: The front legs are divided into left and right, and the back legs are the same. ASSEMBLED VIEW With assistance, carefully place the Table Top (A) upside down on a soft smooth surface to prevent damage to the surface finish. Align Table Leg (B) with the holes in the corner of the Table Top (A) as shown in the diagram.
- Page 5 STEP 3 HARDWARE NEEDED BOTTOM Note: The front legs are divided into left and right, and the back legs are the same. ASSEMBLED VIEW Insert Stretcher (F) into the holes in beween Table Legs (C), align Table Leg (C) with the holes in the corner of the Table Top (A) as shown in the diagram.
- Page 6 STEP 5 HARDWARE NEEDED ASSEMBLED VIEW Secure Stretchers (E) and (F) to the Legs (B), (C), (D) with Screws (5). Using Screwdriver (Not Included). Fully tighten all Bolts and all Screws. STEP 6 BOTTOM With assistance, carefully turn the assembled Table upright. Place the Table in the desired location.
