Ordering a PaxLock Pro

Overview

When ordering a PaxLock Pro there are a few key

factors to be aware of to ensure you get the right

PaxLock Pro and accessories for your installation.

This application note covers the key areas to be

aware of before ordering.

Internal or External

The PaxLock Pro is available in either an internal or an IP 55 rated external variant. Depending on the

installation you may want a mix of both variants to suit the environment.

When choosing the external version, it is important to note that only the external side of the lockset is IP

rated, meaning the PaxLock Pro should never be installed externally where the whole unit is exposed to

the elements.

Black or White

You have a choice of either black or white, both are finished in a scratch resistant hard coating.

PaxLock

APN-1182-AE

Need help?

Do you have a question about the PaxLock Pro and is the answer not in the manual?

Page 1 Internal or External The PaxLock Pro is available in either an internal or an IP 55 rated external variant. Depending on the installation you may want a mix of both variants to suit the environment. When choosing the external version, it is important to note that only the external side of the lockset is IP rated, meaning the PaxLock Pro should never be installed externally where the whole unit is exposed to the elements.
Page 2 Cover plates When replacing a previous door handle where the holes are outside of the footprint of the PaxLock Pro there may often be existing holes drilled into the door that will be exposed. A cover plate can be purchased that will fit around the PaxLock Pro to hide any holes or marks left on the door.
Page 3 Door installation jig To help you with your installation of the PaxLock Pro we have created a PaxLock Pro - DIN Door Check Tool, the tool is designed to help you prepare the door prior to installation of the PaxLock Pro. The adjustable tool works with all door thicknesses from 35mm-62mm, and it can be used to accurately mark out and drill the through door holes you will need when installing the PaxLock Pro.
