JPTCW-200 control guide
Electrical connections
1. External PIN 24 connector
SIGNAL
PIN
NAME
1
Interlock Ch1A
2
Interlock Ch2A
3
Interlock Ch2B
4
Interlock Ch1B
5
RS232 Tx
6
RS232 Rx
7
RS232 Com
8
Remote Key Switch
9
10
Remote Start
Button
11
Analog Input to
12
Control Current
Analog Output
13
Power Monitor
Isolated Analog
14
Com
Table 1 Pin out of the 24-PIN connector
SIGNAL
TYPE
Contact Closure
input
Return
Contact Closure
input
Contact Closure
input
Analog input
Analog output
Return
JPTCW-200-SM-K
SIGNAL
DESCRIPTION
LEVEL
The 24VDC signal will
24VDC
be isolated from the
laser system
Transmit Data output
Receive Data input
RS-232 Return
Provides AC power to
24VDC
the laser in REMOTE
mode
Activates the internal
24VDC
main power supply in
REMOTE mode
Analog Input 1-10 VDC
1-10VDC
= 0 – 100% Setpoint
Analog Output 0-4 VDC
0-5VDC
= 0 – Pnom
Return for signals on
pins 12, 13
1
