4-Channel Fiber-Coupled Laser Source
AC Power Cord Connector
Remote Interlock Input
(See Chapter 6 for details).
Fuse Tray
See section 4.1 for
replacement details.
Rev. P, March 5, 2024
USB Input Connector
Allows full operation through a PC interface.
Figure 2
Rear Panel of Laser Source
Chapter 1: Introduction
Cooling Vent – Do Not Block
The temperature control system moves air from
vent holes on the bottom. Periodically remove
dust buildup from vents for best operation.
Modulation Input - 0 to 5 V Max
Accepts complex waveforms.
See section 5.6 for details.
