Technical specifications

Measured quantities
˿ Per-vehicle range, speed
˿ Dynamic stop-bar ETA tracking, adjusted as vehicles change
speeds
˿ Dynamic density (a measure of instantaneous roadway efficiency)
˿ Number of simultaneous vehicle detections: 25
˿ Logic filters for zone output
˿ Combinational logic applied to zone outputs for alert output
˿ Channel output from multiple alerts
˿ Latched channel output controlled by alerts and timer
˿ Delay and extend settings used for channel outputs
˿ Number of channels: 8
˿ Detection data available via serial communications
˿ Pulse channel outputs for intersection arrival-time information
Detectable area
˿ Maximum mounting distance from center of lanes: 50 ft. (15.2 m)
˿ Maximum mounting height: 40 ft. (12.2 m)
˿ Detection area: 50 to 600 ft. (15.2 m to 182.8 m)
˿ Percentage of vehicles detected before 400 ft. (121.9 m): large
vehicles 95%; all motor vehicles 90%
Performance
˿ Detection accuracy: large vehicles 98%; all motor vehicles 95%
˿ Range accuracy: ±10 ft. (3 m) for 90% of measurements
˿ Speed accuracy: ±5 mph (8 kph) for 90% of measurements
˿ ETA accuracy: ±1 sec. for 85% of measurements
Performance maintenance
˿ No cleaning or adjustment necessary
˿ No battery replacement necessary
˿ Mean time between failures: 10 years (estimated based on
manufacturing techniques
Physical properties
˿ Weight: 3.8 lbs. (1.7 kg)
˿ Physical dimensions: 13.2 in. × 10.6 in. × 3.8 in. (33.5 cm x
26.9 cm x 9.7 cm)
˿ Resistant to corrosion, fungus, moisture deterioration and
ultraviolet rays
˿ Enclosure: Lexan polycarbonate
˿ Outdoor weatherable: UL 746C
˿ Watertight by NEMA 250 standard
˿ NEMA 250 compliant for:
̀ External icing (clause 5.6)
̀ Hose down (clause 5.7)
̀ 4X corrosion protection (clause 5.10)
̀ Gasket (clause 5.14)
SmartSensor Advance

Ordering information

SmartSensor Advance
SS-200V
Retrofitted SmartSensor Advance
SS-200-001
Accessories
102-0416/102-0451 – Click 650/656 cabinet inter-
face device
CLK-112/114 – Click 112/114 rack cards
SS-704-xxx/705 – SmartSensor 6-conductor cable
SS-708-xxx/707 – SmartSensor 8-conductor cable
(for retrofitted sensor)
SS-611 – SmartSensor mount
SS-B01-0003/0005/0008 – Intersection preassem-
bled backplate – AC
SS-B01-0004/0006 – Intersection preassembled
backplate – DC
SS-B02-0002/0003 – Intersection preassembled
19-inch rack
SS-710 – Sensor cable junction box
Contact us
801.734.7200
sales@wavetronix.com
www.wavetronix.com
˿ Withstands 5-ft. (1.5-m) drop
˿ Connector: MIL-C-26482
˿ Rotational backplate for 360º of roll
Electrical
˿ Power consumption: 3.2 W @ 12 VDC
˿ Supply voltage: 10–28 VDC
˿ Onboard surge protection
Communication ports
˿ Two half-duplex RS-485 COM ports support:
̀ Dedicated detection communications
̀ Configuration, verification, or traffic display without disrupt-
ing detection communications
˿ Firmware upgradability over any COM port
