SmartSensor Advance
The power converter shall comform to safety standards UL 60950 and EN 60950.
The power converter shall conform to EMC standards EN 55022 Class B and EN 61000-3-2, 3.
In brown-out conditions (i.e. < 85 VAC input), the output voltage of the power converter shall be less than 1 VDC.
2.7 Input file cards. The Click 112, Click 114 or an equivalent that meets the following specifications shall be used when using a preas-
sembled backplate or Click 600:
The input file cards shall be compatible with 170, 2070, NEMA TS 1, and NEMA TS 2-style input racks.
The input file card shall translate data packets from the CTAD into contact closure outputs.
The input file card shall support presence detection.
The input file card shall receive data packets over an RS-485 bus at a baud rate of 9600 bps.
The input file card shall autobaud and auto-detect an CTAD over wired and wireless communication channels that have a maximum
latency of 500 ms.
The input file card shall comply with the NEMA TS 2-1998 Traffic Controller Assemblies with NTCIP Requirements (Section 2.8 specification).
