STAR Water Systems 5STH Quick Start Manual

QUICK START GUIDE. SEE INSTRUCTION
MANUAL FOR COMPLETE DETAILS.
2. Connect the 2-in
NPT x 2-in barbed
adapter to the pump
and to the discharge
line.
Do not overtighten.*
* If using plastic pipe,
use the included
2-in NPT fi tting
in place of the
adapter.
4. Pump has an air
valve to prevent air-
locking. Air-locking
will keep pump
from pumping
water. A small
spray of water from
the air valve is
normal and does
not represent a
defective pump.
6. DO NOT RUN
DRY. Running
pump when it is
not submerged
in water will
damage the seal
and impeller,
and void the
warranty.
Toll Free Help Line: 1-800-742-5044
SUBMERSIBLE
UTILITY PUMP
MODEL #5STH
Discharge
Line
Adapter
Air valve
Do not
run dry
1. Set pump on
hard surface in
water before
starting.
3. Connect pump
power supply
to a GFCI
protected
receptacle.
5. When the water
level at bottom
of pump drops
to approximately
1 in., pump will
continue to run but
will stop moving
water. Unplug
pump when water
stops fl owing from
the discharge.
WARNING:
FOR YOUR PROTECTION, ALWAYS
DISCONNECT PUMP FROM POWER
SOURCE BEFORE HANDLING.
NOT DESIGNED FOR CONTINUOUS,
ONGOING OPERATION.
Hard
Surface
GFCI Outlet
RESET
TEST
Unplug
Pump
Low Water
025294 A
