- Page 1 Quick Start Guide Access Point ion4xi...
- Page 2 ANYWHERE EVERYWHERE...
-
Page 3: Packaging Content
Introduction Thank you for purchasing our ion4xi, a cutting-edge centrally managed Access Point. This device is Wi-Fi 6 certified, featuring a 2x2:2 MU-MIMO setup that sets new standards for wireless performance and efficiency. Packaging Content ion4xi Adaptor (Qty:1) Mounting Access Point (Qty:1) (Varies by Region) Bracket (Qty:1) Mounting Screws (Qty:4) -
Page 4: Product Specifications
Product Specifications Peak Data Rate (aggregate) Upto 1.78 Gbps (1202 Mbps for 5 GHz and 574 Mbps for 2.4 GHz) Wi-Fi Standard Support 802.11a/b/g/n/ac/ac Wave 2/ax Interface 1 X 10/100/1000 BASE-T Ethernet 1 X 2500 Base X Optical Ethernet SFP DC Power Jack Radio Mode 2x2 MU-MIMO with 2 spatial streams... -
Page 5: Product Overview
Product Overview LAN + PoE Port (Power up the device using PoE Adaptor and a regular Ethernet Cable) SFP Port (Connects fiber cable Vent with maximum data (Transfers the transfer rate capability heat in ambient) of 2.5 Gbps) DC Jack (Power up Hooks using 12V Adaptor) Kensington Lock... - Page 6 Mounting of Access Point Place the mounting bracket which came with the package on a wall or ceiling and mark holes with a marker where you will insert the screws. Drill holes in the marked points and insert the plastic wall anchors. Use supplied screws and attach mounting bracket on the wall.
- Page 7 Align the mounting slots of Access Point with the hooks of the mounting bracket, ensure that it is properly hinged. Mounting Slots Kensington Lock (Securely align the hooks of Access Point with the mounting slots of mounting bracket)
- Page 8 Slide the hooks of Access Point out from mounting slots Locked positions Slide the hooks of of the Access Access Point out Point hooks from mounting slots WARNING: HFCL cannot be held liable for any damages incurred during the process.
- Page 9 Getting the Access Point Online The Access point can be powered up using DC adaptor (12V) or PoE adaptor (48V) as shown below: Step 1: Power up In order to power on the device, connect the DC Adaptor* to the Access Point.
- Page 10 IP 192.168.1.X and a subnet mask of 255.255.255.0 (X is from 2 to 255) Open the web browser and enter the Access Point static IP address in the address bar: 192.168.1.1 A login screen will appear Enter the default login credential details: User- root, Password- hfcl!@ion...
- Page 11 Follow the steps mentioned to connect Access Point to a network: Connect the AP to DHCP network and Internet Login to HFCL io cloud controller (cNMS) iocloud.hfcl.com with credentials provided To get cNMS login credential, please send request email to iosupport@hfcl.com with below details...
- Page 12 Step 3: Check the LED status Status LED Power LED STATUS LED COLOR Green color notifies that the device Power LED Green in powered ON Solid green color notifies the user that the Status LED Green 2.4GHz radio is active and blinks while data is being transmitted on 2.4GHz radio Solid blue color notifies the user that the Status LED Blue...
-
Page 13: Safety Precautions
Safety Precautions Observe the following safety precautions to avoid damage to the Access Point: Do not subject the device to high temperatures Keep away from high voltage cables Disconnect the device before cleansing it Do not wipe the device with a damp cloth Do not open the enclosure of the Access Point Fasten the device tightly with the mount... - Page 14 | io.hfcl.com Contact Us: 8, Commercial Complex, Masjid Moth, Greater Kailash-II, New Delhi- 110048 HFCL Limited All Rights Reserved. HFCL and io by HFCL are trademarks or registered trademarks of HFCL Ltd. Specifications are subject to change without notice.
