Summary of Contents for IDEAL Halo Air

  • Page 1 For use with...
  • Page 2 USER GUIDE UIN: 234819 (RF), 234790 (Wi-Fi). Comprising of 234821 ( Halo Air Thermostat ) & 234825 ( Halo Air interface ) and 235327 (Halo Air bracket). Welcome to your new Ideal Halo control. This thermostat will help you to control both your heating temperature and the times that your heating and hot water is on.
  • Page 3 MAIN FEATURES HEATING MODE SELECTION You can choose to run your The current mode is Halo in Auto, Manual or Off displayed bottom right mode. Press the right hand Auto: runs your heating to button to change the pre-set scheduled times mode and temperatures.
  • Page 4 MAIN FEATURES HEATING PLUS HOURS If you are running a schedule with pre-set times (Auto mode) and you want Press and hold the to maintain the current dial to extend the temperature of your current heating heating instead of moving setting to the next setting simply press the dial.
  • Page 5 MAIN FEATURES HEATING OVERRIDE If you are running a schedule with pre-set times (Auto mode) and you want to adjust the temperature of your heating temporarily, simply turn the dial to your desired temperature. The new temperature will be active until the next scheduled change shown under the target temperature.
  • Page 6 MAIN FEATURES HEATING SCHEDULES Turn the dial to move CH Schedule between the different 06:00 comfort 21.0ºC Your Halo will come with 08:00 setback 18.0ºC days and view the 16:00 comfort 21.0ºC a pre-set schedule: 22:00 setback 18.0ºC schedule that is set. Press edit or the dial to modify the selected day To edit a day, push...
  • Page 7 MAIN FEATURES HEATING TEMPERATURE SETTINGS Alter the Temperature Temperature below will be applied to your temperatures by timed heating schedule Your Halo will come with scrolling and then Comfort Temperature 21.0ºC pre-set Comfort, Setback Setback Temperature 18.0ºC pushing the dial to Frost Temperature 08.0ºC and Frost temperatures:...
  • Page 8 MAIN FEATURES HOT WATER To access the hot water functions, when on the heating home screen, Hot water on simply press the dial. until 10:00pm Alternatively press the Push dial to alternate hot water auto menu mode menu button, scroll to Hot between Central Water Control and press Heating (CH) and...
  • Page 9: Mode Selection

    MAIN FEATURES HOT WATER MODE SELECTION You can choose to run your The current mode is Hot water on Hot Water in On, Off or displayed bottom right until 10:00pm Auto mode. hot water auto menu mode Press the right hand ON: Tops up your hot button to change the water cylinder throughout...
  • Page 10 MAIN FEATURES HOT WATER TIMED HOT WATER You can choose to activate Hot water o the timed hot water (Auto) until 12:00am function in the Advanced Settings menu accessed hot water auto menu mode through the hot water menu. Once activated the mode selection will now include Auto Auto: runs your hot water...
  • Page 11 MAIN FEATURES HOT WATER BOOST If you are running a Hot water on schedule with pre-set until 10:00pm times (Auto mode) and you want to boost your hot hot water auto menu mode water rather than wait for the next scheduled event Turn the dial simply turn the dial.
  • Page 12 MAIN FEATURES HOT WATER SCHEDULES Turn the dial to move HW Schedule between the different 00:00 Hot Water On If the timed hot water 06:00 Hot Water O days and view the 12:00 Hot Water On setting is activated the schedule that is set.
  • Page 13 HALO SMART INTERFACE The Halo smart interface will be installed The Halo Smart Interface has a Failsafe/ near to your heat pump control unit. Override feature which can be used to It will wirelessly communicate with switch your heat pump on if wireless your Halo control and, in the case of an communication between the Halo and internet connected Halo, your home...
  • Page 14: Additional Features

    ADDITIONAL FEATURES To temporarily turn your heating and hot water off whilst you are Holiday on holiday, select the holiday function in the menu and use the Mode dial and buttons to set the number of days. Support Provides information for your installer or technical expert about Page your Halo such as software version and wireless signal strength.
  • Page 15 PRT SYMBOL KEY SYMBOL NAME EXPLANATION Flame Indicates your heating is on. Indicates there is a fault with the control or Fault heat pump. Child lock Childlock is set so the Halo cannot be altered. Override Override or plus hours function is active. Optimised start Optimised start is active.
  • Page 16: Domestic Hot Water

    SYMBOL NAME EXPLANATION Room temperature is above 40°C. Room temperature is below 0°C. Target temp Temperature you want your heating to reach. Current temp Room temperature in the location of your Halo. Time Current time. Date Current date. Battery Battery status indication. Indicates that the Halo is communicating Zigbee with the Smart Interface.
  • Page 17 CHANGING THE BATTERIES IN YOUR HALO CONTROL A red, empty battery symbol means that your Halo batteries need to be replaced. Whether you have a desk or wall mounted unit you will see the below symbol on the base of the unit.
  • Page 18: Troubleshooting

    In the unlikely event that the Halo loses pairing you will see the following screen. Please note even without a signal To re-pair go to section F in the Halo Air between the Halo and the smart interface installation instructions. You can also...
  • Page 19: Warranty

    WARRANTY Your Ideal Halo comes complete with c. To any other costs or expenses caused by or a 2 year Ideal Guarantee, subject to the arising as a result of the breakdown of the following terms and conditions. controls. During the period of the guarantee we will d.
  • Page 20 E: enquiries@idealheating.com at the following internet address idealheating.com UIN: 235417 A04 RF frequency: 2405 – 2480MHz Max. RF output power: 10dBm Ideal Heating is a trading name of Ideal Boilers and associated Group Companies idealheating.com | welcome to our ideology...
