- Page 1 STAINLESS STEEL HI PRESSURE FILTERS INSTALLATION, SERVICE AND MAINTENANCE MANUAL AND SAFETY INSTRUCTIONS INSTRUCTIONS INSTRUCTIONS FZH012 FZH012 FZH012 PASSION PERFORM...
- Page 2 Stainless steel high pressure filters...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Page Description General warnings Tools Handling Dimensional drawings Installation Commissioning Standard maintenance Filter element replacement Special maintenance Clogging indicator (or plug) replacement Seals replacement Instructions for use in explosive atmospheres Regulations Spare parts list Ordering code 13.1 Filter / Housing / Bowl 13.2 Filter element... -
Page 4: Description
- Connect the filter with an anti-loosening system and regularly check the condition of the connection - The declared performances and the safety of the product are only guaranteed when MP Filtri original spare parts are used - Warranty is only effective if MP Filtri original spare parts are used. -
Page 5: Handling
FZH012 Handling - The unit is shipped in a cardboard box with dimensions depending on the order - The handling must be carried out in accordance with the laws in force in the country of use of the product - Handle the product with care, avoid impacts - Store in a dry and frost-free room - The unit should be stored in a suitable location away from the production area when not in use. -
Page 6: Installation
Parts identification Parts identification FZH012 Installation Item Description Clogging indicator connection Clogging indicator connection - Check that the system working pressure does not exceed the maximum working pressure of the filter. The maximum working pressure of the filter is shown on the laser marking on the head... -
Page 7: Standard Maintenance
FZH012 Standard maintenance FILTER ELEMENT REPLACEMENT The clogging indicator monitors the conditions of the filter element in the working section of the filter. The alarm signal shown by the differential indicator during the normal working conditions (pressure, temperatures …) means that the filter element needs to be replaced. -
Page 8: Special Maintenance
Special maintenance CLOGGING INDICATOR (OR PLUG) REPLACEMENT - Check the availability of the right spare parts by comparing the part numbers shown on them with that shown on the filter name plate or spare parts list - For the disassembly and the assembly of the parts, please refer to the tools table in paragraph 3 - Switch off the system - (Fig. - Page 9 FZH012 Smontaggio montaggio Svuotamento Smontaggio Montaggio Montaggio Smontaggio corpo indicatore ntenitore contenitore elemento elemento contenitore connettore Smontaggio Smontaggio Svuotamento Smontaggio Montaggio Montaggio Smontaggio corpo indicatore contenitore contenitore elemento elemento contenitore connettore Montaggio Filtro Smontaggio Montaggio Svuotamento Sost. guarnizioni Smontaggio Sost. guarnizioni...
-
Page 10: Instructions For Use In Explosive Atmospheres
MP FILTRI has carried out a voluntary certification of a part of the product range in compliance with directive 2014/34/EU, in order to guarantee an appropriate degree of safety in these particular conditions. -
Page 11: Spare Parts List
Spare parts list FZH012 FZH012 12. Spare parts list Item Quantity Description Designation / Ordering code Complete filter Housing See “Ordering Code” table Bowl assembly Filter element Clogging indicator Item Description Q.ty Designation / ordering code EPDM Seals kit Complete filter... -
Page 12: Ordering Code
Inorganic microfiber 3 µm Valves Inorganic microfiber 6 µm Element ∆p Execution 20 bar • • MP Filtri standard Inorganic microfiber 10 µm 210 bar Customized Inorganic microfiber 16 µm • • 210 bar, stainless steel filter element Inorganic microfiber 25 µm... -
Page 13: Filter Element
16 µm Inorganic microfiber Inorganic microfiber 25 µm Seals EPDM Element ∆p 20 bar 210 bar Execution 210 bar, stainless steel filter element MP Filtri standard Customized CLOGGING INDICATORS Electrical differential indicator Visual differential indicator Plug Stainless steel high pressure filters... -
Page 14: Troubleshooting
14. Troubleshooting 14.1 MISUSE OF THE PRODUCT This product should be connected to a hydraulic line; this must not exceed upper pressure limit of the product. his product should follow all standard operating procedures previously set at the operating location as well as the procedures required by the manufacturer. - Page 15 All data, details and words contained in this publication are provided for use by technically qualifi ed personnel at their discretion, without warranty of any kind. MP Filtri reserves the right to make modifi cations to the models and versions of the described products at any time for both technical and/or commercial reasons.
