Electric Pressure Pump and Controller
Dear user,
We have made every effort to ensure the accuracy of the contents of this
manual. Should any errors be detected, we would greatly appreciate to receive
suggestions to improve the quality of the contents of this manual.
For more detailed technical data about Beamex ePG Electric Pressure Pump
and Controller, please contact the manufacturer.
ePG
© Beamex 2024
Beamex Oy Ab
Ristisuonraitti 10
FIN-68600 Pietarsaari
Finland
Tel:
E-mail:
Website:
8805000 / ePGuEng / Version 3.0
+358-10-5505000
sales@beamex.com
service@beamex.com
https://www.beamex.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BEAMEX ePG
Summary of Contents for BEAMEX ePG
- Page 1 Should any errors be detected, we would greatly appreciate to receive suggestions to improve the quality of the contents of this manual. For more detailed technical data about Beamex ePG Electric Pressure Pump and Controller, please contact the manufacturer.
-
Page 2: Table Of Contents
Battery Pack..................... 14 Operating instructions..............16 Setting Up....................16 User Interface and Functionality.............. 17 Using the ePG as a pressure controller together with an MC6 family calibrator....................20 Enabling communication between an MC6 family calibrator and the ePG.......................21 Working with an MC6 family calibrator and the ePG....... 22 Settings/Controller Presets: Shut off vs. - Page 3 Enable the firmware update mode......... 48 Power-down................48 Get the battery info..............48 Get the usage data..............49 Trying out the ePG communication protocol in Windows....49 Troubleshooting................52 Maintenance................... 55 Regular inspections.................. 56 Cleaning or changing the Mesh Filter..........56 Checking the amount of condensation and removing it....
-
Page 4: Prologue
Unpacking and Inspection At the factory, each new ePG passes a careful inspection. It should be free of scrapes and scratches and in proper operating condition upon receipt. The receiver should, however, inspect the unit for any damage that may have occurred during transportation. -
Page 5: Feedback
Service and transportation instructions). Include a detailed description of the reason for the return. The standard delivery includes: • ePG Electric Pressure Pump and Controller, with hand and shoulder straps installed • Battery pack, Li-ion, installed • USB Type-C charger with a country-specific mains plug •... -
Page 6: Safety
Warning: Only personnel with good experience and knowledge of pressure media, pressure instruments and connections are allowed to work with ePG. Incorrect use may result in damage to the device, the instrument connected to it and/or personal injury. Warning: Only use the device for purposes and only in environments... - Page 7 Therefore, it is extremely important to vent the external systems (and flush them if needed) before connecting them to the ePG. Beamex Vent valve for 40 bar / 580 psi pressure hoses can be used to vent the system.
-
Page 8: General Warnings Concerning Pressure Measurement
Warning: Never exceed the maximum pressure of the connected devices. The maximum pressure of Beamex modules is stated on the module's sticker. Warning: Never block a hose opening with your hands or put hands in front of a gas spray coming from a leakage. -
Page 9: Specifications
Weight ~ 2.3 kg / ~ 5 lb Pressure Connection The ePG output connection consist of a pressure port with a standard G1/8" (ISO228/1) female thread and a pre-installed Bx G1/8" male fitting for Beamex 40 bar (580 psi) hoses... - Page 10 0 to 40 °C / 32 to 104 °F from 40 °C to 50 °C / 104 to 122 °F ≤ 50 %RH ePG will work at higher humidity, but its performance may drop All specifications are subject to change without notice. For the updated technical information, please check Beamex website.
- Page 11 Specifications - 11 Figure 1: Technical drawing...
-
Page 12: About Epg
About ePG - 12 About ePG General description Figure 2: Overview presents a general view of the ePG, its parts and its buttons' functionality. Figure 2: Overview Legend: Pressure Output Connection Lithium-ion Battery Pack... -
Page 13: Top View
Vent/Mode button Shoulder Strap hook Operation buttons for pressure/vacuum generation Top view Figure 3: ePG, top view Legend: USB-C port, for charging the Battery Pack and for firmware updates Locking mechanism, when locked, prevents the Battery Pack from falling When pressed, the number of LEDs in the Battery indicator shows the... -
Page 14: Battery Pack
About ePG - 14 Battery Pack The battery provides a long operation time and can be quickly charged. You can also charge a spare battery separately, and replace in the field when needed Figure 4: Battery Pack locked When the slot is in a vertical position the Battery Pack is locked. - Page 15 When the temperature is under or over the limits (other than 0 °C to 45 °C / 32 °F to 113 °F) the Battery Pack cannot be charged. Additionally, if the internal temperature is over 60 °C / 140 °F, the ePG stops working automatically as a precaution until the temperature is within the limits again.
-
Page 16: Operating Instructions
Operating instructions - 16 Operating instructions Setting Up Connect one of the three ends of the T-pressure hose to the ePG's output connection. Connect one of the remaining open ends to the calibrator's/pressure measuring device's input connection. Connect the last open end to DUT's* input connector. -
Page 17: User Interface And Functionality
You can operate the ePG by pressing the buttons on the device. Figure 7: Buttons on the device Figure 8: Power button The ePG is powered-on by pressing the Power button. This is indicated by Power button lighting up. When powered-on, the device goes automatically into the vent mode. This is indicated by green LED blinking. - Page 18 Operating instructions - 18 Figure 9: Vent/Mode button Vent/Mode button is used to vent the ePG or change the mode from pressure to vacuum and vice versa. When pressed, the ePG goes into the vent mode which is indicated by the green LED blinking.
- Page 19 The button can be either clicked or pressed and held. When it is clicked, the ePG decreases pressure in bigger steps (~ 100 to 200 mbar / 1.45 to 2.90 psi per step). When it is pressed and held, the output...
-
Page 20: Using The Epg As A Pressure Controller Together With An Mc6 Family Calibrator
Coarse Adjustment Down button lighting up. After locking you can lift your fingers off the buttons. Locking can be released by pressing any of the the arrow buttons. The ePG then holds the generated pressure and waits for further instructions. Please notice, that if the Power or Vent/Mode button is pressed to release the lock, the device either switches itself off or vents itself. -
Page 21: Enabling Communication Between An Mc6 Family Calibrator And The
The MC6 family calibrator does not automatically recognize your ePG. You need to configure the controller communication to pair the devices. Note: If you have more than one ePG, you can assign each ePG to a separate Controller Presets channel (maximum 4). -
Page 22: Working With An Mc6 Family Calibrator And The Epg
Examples: • With P6C, the ePG provides the lower setpoint limit (-0.85 bar / -12.4 psi) and the pressure module provides the upper limit (6 bar / 87 psi) •... -
Page 23: Settings/Controller Presets: Shut Off Vs. Continuous
Shut off Shut off means that once the setpoint is reached, pressure adjustment stops. The ePG will not try to adjust the pressure even in case of an overshoot and the hysteresis will be preserved. Continuous Continuous means that pressure adjustment continues even after the setpoint is reached. -
Page 24: Venting And Zeroing
There are two different ways to vent the ePG with MC6 family calibrator. The ePG vents when you enter value 0 in the Gauge pressure mode. If no other setpoint is given, Vent leaves the valves open for 1 minute. This gives the user some time to zero the reference pressure module. - Page 25 Operating instructions - 25 Figure 18: Vent button - Documenting Calibrator mode Figure 19: Vent menu - Documenting Calibrator mode...
- Page 26 Zeroing is performed as follows: • enter value 0 in the Gauge pressure mode to vent the ePG (the ePG keeps the valves open for 1 minute) • allow the pressure to stabilize •...
-
Page 27: Documenting Calibrator Mode
Operating instructions - 27 Documenting Calibrator mode In order for the references to be properly displayed on the calibration certificates, Documenting Calibrator mode settings have to be configured properly. When you create instruments in the MC6 family calibrator and plan to send the results to either CMX or LOGiCAL, create the instrument Input by following the example instruction below: Figure 21: Step 1: Select the Quantity for the instrument Input... - Page 28 Operating instructions - 28 Figure 23: Step 3: Select an INT or EXT pressure module as a Port/ Function Figure 24: Step 4: Select the controller via Automatic Control...
-
Page 29: Calibrating Analog Gauges
Operating instructions - 29 Figure 25: Step 5: Select the ePG Figure 26: Step 6: The pressure module selected for Port/Function is the reference. This pressure module will override and change the Reference Pressure selection in the Controller Presets Calibrating Analog gauges When calibrating pressure gauges (analog indicators), it can be challenging to interpret the readings between the marks on the pressure gauge. - Page 30 Operating instructions - 30 This means that you adjust the pressure so that the gauge dial is aligned with a cardinal point, which makes it easier for you to interpret the reading. You can do this in the Documenting Calibrator mode as shown in the example below: Figure 27: Cardinal point calibration If you want to fine-tune the setpoint, press the Pause button and change the...
-
Page 31: Opening An Instrument While The Epg Is Not Connected
Operating instructions - 31 Opening an instrument while the ePG is not connected If you open an instrument, where controller communication is needed and the controller is not available, the calibrator will prompt you about a missing controller. You are still able to access and edit the instrument and when you connect the pressure controller, calibration can start. -
Page 32: Working With The Calibration Management Software
Calibration Management Software configuration (CMX or LOGiCAL). Working with CMX Requirements There is no need to upgrade the CMX version in order to start using the ePG. The only requirement is that your MC6 family calibrator is able to communicate with your CMX version. - Page 33 Operating instructions - 33 If you want the calibrator to automatically accept the calibration points, make sure you have the following configurations in the procedure window: • Acceptance set to automatic; • Max Deviation sets a range around the setpoint (in % of span). When the Input is within the set range, the calibration point can be automatically accepted, even though the exact setpoint has not been reached;...
-
Page 34: Working With Logical
Calibration methods are associated with the instrument type and because of that they don't need to be specified for each instrument separately. Calibration method defines Beamex calibrator or application to be used for documenting the calibration, and how the input and... - Page 35 For instance, one method might involve using a hand pump to produce the required pressure, while another method might use the MC6 to control the ePG pressure generation. Using the MC6 to control the ePG pressure generation...
- Page 36 Operating instructions - 36 MC6 will control the ePG to generate the pressure and measure current from the transmitter. By activating the star ( ) next to the selection, you can set the selected row to be the preferred method. This calibration method will be selected by default when assigning the calibration tasks from LOGiCAL.
- Page 37 Operating instructions - 37 • Calibration Point Delay: defines the time (in seconds) the calibrator waits after the Input is stable before the readings are accepted; • Max Deviation: sets a range around the setpoint (in % of span). When the Input is within the set range, the calibration point can be automatically accepted, even though the exact setpoint has not been reached.
-
Page 38: Epg Communication Protocol
Communication Device Class (CDC) between the host device (an MC6 Family device or e.g., a Windows PC) and the ePG. USB CDC means that the ePG is seen as a virtual serial port by the host (virtual COM-port in Windows). -
Page 39: Decimal Values
<EOL> or <CR><LF>. Error codes An error code is returned by the ePG for each command. Valid error codes are presented in the table below: No error, command executed successfully... -
Page 40: Command, Error Code And Additional Response Data Sequence
Operating instructions - 40 Command, error code and additional response data sequence Sends one command to the ePG and waits for its response. All commands return an error code, see Error codes. Some commands return additional response data after the error code if the returned error code was e0 (No error). -
Page 41: Commands
Device type name: ePG DeviceType Integer value, ePG's serial number SerialNumber ePG firmware version in the format: Version X.YY ePG's mainboard hardware revision Revision letter: A, B, C, etc. Note: The ePG firmware versions 2.00 and older do not display the revision. -
Page 42: Set The Reference Pressure
Set the reference pressure The host device must send the reference pressure measurement readings to the ePG at the rate of about 3 readings per second using this command, at least when the ePG is actively regulating a setpoint (see Set the setpoint). -
Page 43: Get The Setpoint
Decimal value, pressure setpoint in Pressure Get the setpoint Gets the currently active setpoint. If the ePG is not actively regulating (it could be in Vent or Idle mode), error code e3 (command execution failed) is returned. Command: t/<EOL>... -
Page 44: Get The Internal Pressure
Absolute pressure depending on the current pressure type Integer value, the current state of State the ePG: 0 stands for Idle, 1 stands for Venting, 2 stands for the Manual control with keypad, 3 stands for Internal (e.g. sensor alignment), 4... -
Page 45: Get The Temperature
Vent the system Stops the motor, opens the valves and vents the system. At the end of the venting sequence, the ePG internal pressure sensors PM1, PM2 and PM3 are zeroed. After venting, the ePG enters the Idle mode. Note: The valves will be kept open for about 1 minute after... -
Page 46: Sensor Alignment
Detect loss of communication Enables detection of the communication loss with the host device. When enabled and the ePG has detected communication loss (no communication activity seen for the specified timeout), the ePG will automatically enter Idle mode (see Set Idle... -
Page 47: Local Lockout
Operating instructions - 47 Local lockout Selected physical keys can be locked to prevent the user interaction. Local lockout does not prevent simulating key-presses or -releases with the command Simulate key press or release. If a loss of communication is detected (see Detect loss of communication), all keys are automatically unlocked. -
Page 48: Enable The Firmware Update Mode
Command: f/<EOL> Power-down Performs a short vent and then powers-down the ePG. After the power-down, the ePG can be powered-on with the Power button or by disconnecting and reconnecting the USB cable. Command: p/<EOL> Get the battery info Gets the Battery Pack info. -
Page 49: Get The Usage Data
Value Trying out the ePG communication protocol in Windows When the ePG is powered-on and connected to a Windows PC with a USB cable, it is seen as a virtual COM-port in the Device Manager in “Ports (COM & LPT)” category. An application connecting to this ePG COM-port should have... - Page 50 Operating instructions - 50 It can be downloaded at http://www.putty.org. Details of the puTTY configuration can be seen in the following figures: Figure 32: puTTY configuration - Session tab Figure 33: puTTY configuration - Terminal tab...
- Page 51 Operating instructions - 51 Figure 34: puTTY configuration - Serial tab Figure 35: A sample manual communication...
-
Page 52: Troubleshooting
LED flashing alternatively. The green to change the pressure towards 0 LED is off. bar / 0 psi are available. Let the ePG temperature return to normal (only green LED lights up). 2. The yellow LED is blinking and the 2. - Page 53 Use the charger that came with the ePG or make sure your charger meets the minimum requirements (see Table Specifications) ePG does not start even when the battery is full. INDICATION SOLUTION ePG feels very warm. Let the ePG temperature return to normal.
- Page 54 Check that the Requirements Controller Presets. communicate with the ePG are fulfilled (see chapter Using the ePG as a pressure controller together with an MC6 family calibrator). I cannot generate 20 bar / 300 psi Make sure you have selected a pressure with MC6 family calibrator.
-
Page 55: Maintenance
Note: Please notice that the ePG must be in the Pressure mode during the dryout procedure. If any parts of the ePG require cleaning, use a cloth damped with a water-based or alcohol-based solvent. Alternatively, use low concentration of hydrogen peroxide or mild solution of mild soap water. -
Page 56: Regular Inspections
(8006160, 5 pcs). Check the condition of the Mesh Filter at least every 3 months. A Mesh Filter prevents impurities from getting into the ePG during venting. The Mesh Filter might require cleaning or changing from time to time. The Mesh Filter can be found under the output fitting. -
Page 57: Method A (Removing Condensation)
Maintenance - 57 Choose the correct method depending on the serial number of the device: • Method A (removing condensation) - valid for the devices with a serial number 20240054 and higher; • Method B (removing condensation) - valid for all devices with firmware version 2.20 or later, however method A is a preferred and reliable method of removing condensation for newer devices. - Page 58 Maintenance - 58 When the ePG is powered-on, press the Coarse Adjustment Up button and hold it for 1-2 minutes. During this time the possible condensation is pumped out from the Pressure Block. Warning: Be extra careful not to put your fingers between the Piston Assembly when the ePG is powered-on and it starts generating pressure (when the motor is running).
-
Page 59: Method B (Removing Condensation)
Power button . This activates the dryout mode, in which ePG will be pumping for about 2 minutes and after that it will stop automatically (this can be stopped by pressing the Vent/Mode button Power button Hold the device in each of the positions (see pictures below) for about 15s to remove the condensation throught the bottom holes. - Page 60 Maintenance - 60 Figure 39: Position 2 Figure 40: Position 3...
- Page 61 Maintenance - 61 Figure 41: Position 4 Figure 42: Position 5 Figure 43: Position 6...
-
Page 62: Cleaning The Out Valve
Maintenance - 62 Cleaning the Out Valve Unscrew all the screws from the Back Cover. Be aware of the one screw located in battery compartment (1). Figure 44: Step 1 Gently lift the Back Cover and make sure that the main PCB stays in its place in the Front Cover. - Page 63 Maintenance - 63 Unscrew the two screws (1) from the valve cover (2). Figure 46: Step 3 Remove the Valve Cover. Figure 47: Step 4...
-
Page 64: Changing The Non-Return Valves
Piston Assembly in up position (piston as near the Non-return Valve package as possible) to prevent the In Valve from sliding inside the cylinder. Figure 48: Step 5 Changing the Non-return Valves ePG Non-return valve kit (8006145). Remove the Back Cover (see steps 1-2 in chapter Cleaning the Out Valve). - Page 65 Maintenance - 65 Unscrew the following two screws (1) from the pump mechanism and lift the whole mechanism slightly up. Figure 50: Step 3 Unscrew the four screws holding the cylinder ends together. When reassembling, tighten the screws with 2.5 Nm of torque. Figure 51: Step 4...
- Page 66 Maintenance - 66 When the screws are unscrewed, lift the Cylinder Guiding End and the Cylinder (1). Before lifting the cylinder, push it slightly backwards and turn it a bit to the right so it can be easily lifted up. Be careful not to slide the cylinder downwards in a way that the Piston Seal comes visible from the top of the cylinder.
-
Page 67: Changing The Piston Seals
Cleaning the Out Valve. Assemble the device in the opposite order. Changing the Piston Seals ePG Piston Seal Service kit is available (8006130). Remove the Back Cover (see instructions in chapter Cleaning the Out Valve). Follow the steps 2 - 5 described in chapter Changing the Non-return Valves. - Page 68 Maintenance - 68 Remove the Guiding End and the Cylinder. Figure 55: Step 3 Unscrew the M3x6 screw (1), remove the Piston Top, Piston Seal (2) and Guiding Ring (3). Open up or break the Guiding Ring for example with a screwdriver so that the Guiding Ring can be changed.
- Page 69 Maintenance - 69 Push and slide the new Guiding Ring (1) over the replacement tool (2). The Guiding Ring is tight and because of that you need to use a tool to get it in place. Figure 58: Step 6 Push the Guiding Ring and the replacement tool against the piston.
-
Page 70: Changing The Adhesive Vent
Set of Adhesive Vents (8006165, 3 pcs). Adhesive Vent should be replaced when it has become loose or dirty. Adhesive Vents equalize pressure inside sealed enclosures. ePG's Adhesive Vent can be found on the bottom of the battery compartment. Remove the Back Cover (see steps 1-2 in chapter... -
Page 71: Firmware Update Instructions
To update the firmware version follow the instructions below. Note: It is not recommended to use the ePG update application with a Windows version older than Windows 10. If Beamex ePG Electric Pressure Pump and Controller firmware is updated from a PC for the first time, correct Windows driver needs to be installed: Connect the USB cable between the ePG and PC. - Page 72 This will stop firmware update mode by doing a forced power down of the ePG. Alternatively, disconnect the ePG's battery to power down the ePG. III. After powering down, the ePG will no longer be in firmware update mode and will start normally after pressing Power button again.
-
Page 73: Updating The Usb Driver
Maintenance - 73 Updating the USB driver To manually update the driver: Open the Windows Device Manager. You can use the Search tool found on the Windows taskbar. Right-click the STM Device in DFU Mode (found under Universal Serial Bus controllers) and select Update driver. - Page 74 Maintenance - 74 Select Browse my computer for drivers. Browse for the correct location (ePG_Update\Driver folder found in the installation package) and press Next.
- Page 75 Maintenance - 75 Driver will be installed. Newly updated driver is now visible in the Windows Device Manager.
-
Page 76: Disposal Of Waste Electrical And Electronic Equipment
Disposal of Waste Electrical and Electronic Equipment Beamex and WEEE Beamex is an environmentally conscious company developing products with a view to ensure that they are easy to recycle and do not introduce hazardous materials into the environment. In the European Union (EU) and other countries with separate collection systems, waste from electrical and electronic equipment (WEEE) is subject to regulations. -
Page 77: Service And Transportation Instructions
You can perform basic maintenance (e.g. changing the seals and non-return valves) by yourself. More complex maintenance and repairs must only be performed by Beamex's service team or an authorized representative. When sending the ePG for service, place it in its original package, as received upon the delivery from Beamex.
