- Page 1 INSTRUCTION MANUAL ® BEAMEX PRESSURE/VACUUM PUMP MODEL PGC...
- Page 3 We reserve rights to make modifications to this manual without any further notice. For more detailed technical data about the Instruction manual for PGC Calibration Pressure Pump, please contact the manufacturer. © 2016 BEAMEX OY AB Ristisuonraitti 10...
-
Page 4: Table Of Contents
CONTENTS DESCRIPTION ..................... 1 Standard Accessories ..................1 Optional Accessories ..................1 USING THE PUMP ..................3 Preparation......................3 Operation (Pressure) ................... 4 Operation (Vacuum) .................... 5 When Calibration is Done..................5 TROUBLESHOOTING/MAINTENANCE ............. 6 Seal Replacement ....................6 SPECIFICATIONS ..................8 The Pump Unit .................... -
Page 5: Description
DESCRIPTION ® Beamex PGC calibration pressure pump is designed to manually generate be- tween -0.95 to 35 bar (approx. -13.7 to 510 psi) of vacuum and pressure for quick and accurate calibration of pressure gauges, transducers and other pressure meas- urement instruments. - Page 6 Presenting PGC. Device Under Test (DUT) Reference meas- urement Connection diagram when calibrating...
-
Page 7: Using The Pump
Note. It is not recommended to use the plugged connection on top of PGC. Further information in warnings, presented on page 9. Normally: Check that the thumb nut of the stroke length setting is approx. 1 centime- ters from the lowermost position. -
Page 8: Operation (Pressure)
Operation (Pressure) Turn the fine adjustment valve counterclockwise until it is fully open. Approximately halfway, if you do not need to use the full pressure range of the pump. Pump to raise the pressure close to the next calibration point. Use the fine adjustment to raise the pressure to the calibration point. -
Page 9: Operation (Vacuum)
Operation (Vacuum) Turn the fine adjustment valve clockwise until it is fully closed. Pump to lower the pressure close to the next calibration point. Use the fine adjust- ment to lower the pressure to the calibration point. Notes. After decreasing the pressure, the reading may slightly change for about 30 seconds. -
Page 10: Troubleshooting/Maintenance
TROUBLESHOOTING/MAINTENANCE If the pump assembly fails to indicate a pressure increase/decrease after considera- ble pumping action of the handle, check the following things: Assure that the connections between the pump, the hose end and the at- tached instrument(s) are tight and retry pumping. ... -
Page 12: Specifications
SPECIFICATIONS The Pump Unit Weight 820 g 1.81 lb Dimensions Height 220 mm approx. 8.7" Width 120 mm approx. 4.7" Depth 65 mm approx. 2.6" Pressure range -0.95 to 35 bar -13.7 to 510 psi Pressure media Output connector G 1/8’’... -
Page 13: Warnings
Use only the connector provided with the pump. Impurities from wrong mate- rials may plug the pump. It is not recommended to use the plugged connection on top of PGC. PGC's body is made of Aluminium and the thread may be damaged when using too much force to open/close the connection. - Page 16 BEAMEX OY AB Phone +358 - 10 5505000 Ristisuonraitti 10 +358 - 10 5505404 FIN-68600 PIETARSAARI E-mail sales@beamex.com FINLAND service@beamex.com Internet http://www.beamex.com Beamex Inc Beamex Limited 2152 NW Parkway Newtown Grange Farm Business Park Suite A Desford Road Marietta, GA 30067 NEWTOWN UNTHANK U.S.A.
