A SIGNATURE CUT, TRUSTED FOR OVER 100 YEARS
SAFETY, OPERATION
& MAINTENANCE MANUAL
Jacobsen GP400™ Ride on Greens Mower
CAT
® - C0.7 Diesel
GP400 Diesel (CAT® - C0.7)
Series: DDE / Product code:USAD004E
WARNING: If incorrectly used this machine can cause severe injury. Those who use and maintain this machine must
be trained in its proper use, warned of its dangers and must read the entire manual before attempting to set up,
operate, adjust or service the machine.
GB
United
Kingdom
WARNING
RJL AGCD
10015205-A
