WB Manufacturing Cafe Table Round Top w/Tubular X-Base Assembly Instructions

Before you begin, please make sure all parts and proper quantities are included. (See Part Identifier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Step 1:
•
Place table top face down on protected flat surface so
threaded inserts are facing up.
Step 2:
•
Align base with threaded inserts
•
Using a 4mm Allen wrench or 4mm hex bit, secure top
with joint connector bolts. (See Part Identifier Key for
type of bolt to go with the base.)
Before you begin, please make sure all parts and proper quantities are included. (See Part Identifier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Step 1:
•
Place table top face down on protected surface so
threaded inserts are facing up.
Step 2:
•
Remove all the parts for the Flip table from the box.
•
Open flip mechanism up. (See image to the right.)
•
Place the mechanism on the table top making sure
you align the holes with with threaded inserts in the
table top.
•
Using a 4mm Allen wrench or 4mm hex bit and
screw gun, secure mechanism to table top with joint
connector bolts. (See part identifier key for type of
bolt needed for the base type.)
Tools Required
• Screw gun
• 4mm Allen wrench OR
• 4mm hex bit
wibenchmfg.com
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
Assembly Instructions
Steps 1-2
Assembly Instructions
Handle Flip Mechanism
Mounts to
table top
Steps 1-2
507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Café Tables
Café Tables
w/ Flip Top
Mounts to base plate of
the column
V063021 Version subject to change
