Fig. 1: Product Overview
2.2

Description of control panel

1
3
2
4
Fig. 2: Control panel
8
10 9 8 7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
15
6 5 4
Refill opening cap
Extension card
Fuse (12.5 A)
Input/Output cable entry
Main switch
Drainage screw plug
Venting screw
Diaphragm expansion tank closure
Discharge / suction port holder
Discharge / suction port handle grip
Pedestal (oscillation dampening)
Suction port
Mains cable
Discharge port
Control panel
LEDs: "Operating status"
• Pressure setting display
• Operation
• Fault or alarm
Operating buttons: "+" and "-"
Operating button: "On/Off"
LED: "System status" (green and red)
