F&F PF-431-LED TRMS Instruction Manual page 5

3 power supply input – L1 phase
4 power supply input – L2 phase
5 power supply input – L3 phase
6 power supply input – neutral N-wire
9-11 power supply output
Technical data
input voltage
output voltage
maximum load current (AC-1)*
minimum voltage value L1, L2, L3
maximum voltage value L1, L2, L3
return hysteresis
voltage measurement error
switching time
output voltage indication
power consumption
terminal
tightening torque
working temperature
dimensions
mounting
ingress protection
* The actual permissible load depends on the nature of the receivers. In
the case of powering large appliances, heating or a large number of, for
example, LED lamps, it is recommended to use the PF-441 switch with
additional contactors.
** The value depends on the nature of the load. More information in the
power table on the next page.
16 A (120 A/20 ms)**
4.0 mm² screw terminals (cord)
2.5 mm² screw terminals (wire)
3 modules (52.5 mm)
- 5 -
3×400 V+N
230 V AC
190 V
280 V
1.0÷1.5 s
3×LED
1.6 W
0.5 Nm
-25÷40°C
on TH-35 mm rail
10 V
±1%
IP20
