- Page 1 Portable Air Conditioner Owner’s Manual GPC06AP-A6NNA1A IMPORTANT : Please read this manual carefully before running this unit, and save it for future reference. © Copyright, GREE Canada, 2023 01012023...
-
Page 3: Table Of Contents
Thank you for your purchase ! This manual is the universal version for this product manu- factured by GREE Canada. The appearance of the unit that you have purchased may differ from the one shown in this manual, however it does not change the basic guidelines on how to properly operate this appliance. -
Page 4: Safety Guidelines
SAFETY GUIDELINES SAFETY SYMBOLS DESCRIPTION The following symbols are used throughout this manual to indicate immediate or potential hazards. It is the owner’s responsibility to read and follow all safety information and instructions accompanying these sym- bols. Failure to heed safety information increases the risk of serious injury or death, property damage and/ or product damage. -
Page 5: Refrigerant Specifications
SAFETY GUIDELINES REFRIGERANT SPECIFICATIONS A special refrigerant circulates in the system to achieve the air conditioning operation. The refrigerant used is fluoride R32, which is particularly environmentally friendly. The refrigerant is flammable and odorless. In addition, it can lead to an explosion under certain conditions, but the flammability of the refrigerant is very low. -
Page 6: Operation And Maintenance Safety Instructions
SAFETY GUIDELINES OPERATION AND MAINTENANCE SAFETY INSTRUCTIONS WARNING : ▪ This appliance is not intended for use by persons thinners, etc. (including children) with reduced physical, sen- ▪ Ventilate the room before operating the air condi- sory or mental capabilities or lack of experience tioner if there is a gas leak from another appliance. -
Page 7: Component Summary
COMPONENT SUMMARY UNIT COMPONENTS Control panel Pocket handle Airflow deflectors Castors Air filter access Heat exhaust port Continuous drain port Power cord & plug Cord winding hooks 10 Manual drain port INCLUDED ACCESSORIES Panel A Panel B Exhaust Panel C cover Exhaust fitting Window fitting... -
Page 8: Installation Guide
INSTALLATION GUIDE PRE-INSTALLATION INFORMATION locations as it may be dangerous and may cause ELECTRICAL CONNECTION REQUIREMENTS malfunctions : ▪ Comply with electrical safety regulations when 1) Areas with strong heat sources, vapours, flam- installing the appliance. mable or explosive gases, sulphate gases or ▪... -
Page 9: Installation Instructions
INSTALLATION GUIDE INSTALLATION INSTRUCTIONS WARNING : ▪ Observe all electrical codes and ordinances. ▪ Do not use damaged or non-standard power cords. ▪ Use caution during installation. ▪ Proper installation is the responsibility of the installer. Incorrect installation will void the warranty. ▪... - Page 10 INSTALLATION GUIDE 2. Attach the insect guard to the back of the main 4. Slide the exhaust cover into the grooves of the window panel (panel A). Push it in to make sure main window panel (panel A). it fits properly. If you do not want to install the rain guard, proceed to Step 4.
- Page 11 INSTALLATION GUIDE a. Locate panel B (the one with grooves on each side lengthwise), a fixing clip and plastic bolt. PANEL A (cut if necessary) b. Insert the fixing clip into the middle groove of 12.7 cm panel B. (5 in) 71.9 cm (28.3 in) PANEL B Panel B...
- Page 12 MANDATORY for this portable air conditioner. This dow frame and close the window sash against the panels. is because this GREE air conditioner (like all other air conditioners) must produce heat as a by-product of generating cooled air. If you do not connect the exhaust hose, your unit will vent this hot air into the room you are trying to cool.
- Page 13 INSTALLATION GUIDE 3. Insert the end with the exhaust fitting onto the The user can adjust the installation method of the grooves on the bottom of the exhaust port on the exhaust hose according to his needs. However, in- back of the unit, then push until the fitting snaps stallation methods similar to those illustrated below into place on the clasp on the top.
-
Page 14: Operation Guide
OPERATION GUIDE CONTROL PANEL OVERVIEW Indicates that the air conditioner is oper- Allows to select a fan speedsetting. ating in Low mode. Indicates that the air conditioner is oper- Activates or deactivates the Sleep ating in Med mode. Sleep function. Indicates that the air conditioner is oper- High ating in High mode. -
Page 15: Remote Controller Overview
OPERATION GUIDE REMOTE CONTROL OVERVIEW Turns the air conditioner on or off. T-ON T-OFF Decreases the set temperature by 1° with each press. LOCK SPEED Allows to select a fan speed setting. Activates or desactivates the Sleep function. Allows to select an operation mode. Increases the set temperature by 1°... - Page 16 OPERATION GUIDE OPERATION RECOMMENDATIONS WARNING : ▪ Operating Temperature Range : ▪ Do not operate the unit in a humid environment. Max. Cooling : DB/WB 35 °C (95 °F) / 24 °C (75 °F) ▪ Keep the air inlet and outlet clear of obstructions. The operating temperature in cooling mode is ▪...
-
Page 17: Function Descriptions And Setting
OPERATION GUIDE FUNCTION DESCRIPTION AND SETTING Note : Functions are the same when using the remote control and control panel, unless otherwise stated. POWER ON/OFF FAN SPEED SETTING Allows the user to power the unit on or off. Allows the user to select a fan speed in accordance with their needs. - Page 18 OPERATION GUIDE cause the hours to scroll up or down more quickly. When TEMPERATURE UNIT CHANGEOVER done, press the TIMER ( ) button to confirm the timer setting. The symbols “T-OFF” and “H” will stop blinking on Allows the user to select between Celsius or Fahr- the display screen of the remote control.
-
Page 19: Maintenance
MAINTENANCE WARNING : ▪ Turn off the air conditioner and unplug the power cord from the outlet before cleaning to avoid electric shock. ▪ Do NOT wash the air conditioner with water to avoid electric shock. ▪ Do NOT use harsh detergents to clean the air conditioner. ▪... - Page 20 MAINTENANCE Continuous Drainage : WATER DRAINAGE 1. Remove the drain cap by turning it counterclock- This GREE portable air conditioner comes with an wise, then remove the rubber stopper from the auto-evaporation system. The unit automatically spout. evaporates the condensation. There is no need to empty the water except in humid conditions.
- Page 21 MAINTENANCE APPLIANCE DISPOSAL WARNING : ● Many packing materials are recyclable materials. When using the continuous drain option from Please dispose them in appropriate recycling unit. the center port, place the unit on a flat sur- face and make sure the hose is unobstructed ●...
-
Page 22: Troubleshooting
TROUBLESHOOTING COMMON ISSUES If your appliance appears defective, please check the possible explanations for your situation in the table below, it may be that a simple solution can help solve the problem. If the problem persists, please call our Service Center at 1 800 686-2175 for assistance. SITUATION POSSIBLE CAUSES SOLUTIONS... -
Page 23: Malfunction Codes
TROUBLESHOOTING The batteries are depleted. Replace with new batteries. The desired temperature exceeds the tem- The temperature range is 16 – 30 °C (61 – 86 °F). perature range. There is an There is a person smoking a cigarette Odours can be caught by the appliance and spread with unpleasant smell close by, or a garbage bin has been left the airflow. -
Page 24: Service Guide
SERVICE GUIDE SPECIAL SAFETY PRECAUTIONS FOR FLAMMABLE REFRIGERANTS WORK PROCEDURE Aptitude requirement for service technician (repairs should be done only be specialists). ▪ Work shall be undertaken under a controlled pro- a. Any person who is involved with working on or cedure so as to minimise the risk of a flammable breaking into a refrigerant circuit should hold a gas or vapour being present while the work is... - Page 25 SERVICE GUIDE or conducting any hot work. wiring are exposed while charging, recovering or purging the system ; ▪ A degree of ventilation shall continue during the period that the work is carried out. – That there is continuity of earth bonding. ▪...
- Page 26 SERVICE GUIDE ▪ The check shall also take into account the effects – Purge the circuit with inert gas ; of aging or continual vibration from sources such – Evacuate ; as compressors or fans. – Purge again with inert gas ; –...
- Page 27 SERVICE GUIDE DECOMMISSIONING REFRIGERANT RECOVERY ▪ Before carrying out this procedure, it is essential ▪ When removing refrigerant from a system, either that the technician is completely familiar with the for servicing or decommissioning, it is recom- equipment and all its detail. mended good practice that all refrigerants are re- moved safely.
-
Page 28: Electric Diagram
SERVICE GUIDE ELECTRIC DIAGRAM Electrical diagrams are subject to change without notice. Please refer to the one on the unit. -
Page 29: Warranty
Canada. During the warranty period, if the appliance fails under normal use, GREE Canada will, at its option, either repair the unit or replace it, free of charge, within a reasonable period of time after the product is returned. - Page 30 AFTER-SALES SERVICE If the unit you purchased has a quality problem or if you have any questions, please contact customer ser- vice by phone at 1 800 686-2175 or by email at service@gree.ca. THE WARRANTY MUST MEET THE FOLLOWING REQUIREMENTS : 1.
