Connected Home Presence Sensor
SCH010ZB
A6V13959459_en--_a
2023-07-11
Presence detection
●
Stays on top of activity in your home at all hours
●
No power connection required; battery operation gives you the flexibility to install
the sensor nearly anywhere
●
Easy to install
●
Visual alerts and monitoring records update you when there's presence in a
chosen area
●
Communicates with Connected Home Hub via Zigbee network
Smart Infrastructure
Advertisement
Related Manuals for Siemens SCH010ZB
Summary of Contents for Siemens SCH010ZB
- Page 1 Connected Home Presence Sensor SCH010ZB Presence detection ● Stays on top of activity in your home at all hours ● No power connection required; battery operation gives you the flexibility to install the sensor nearly anywhere ● Easy to install ●...
- Page 2 Press and hold it down for 3 s to join Zigbee network (initiated from the mobile application). ● Press and hold it down for 10 s to perform factory reset. ● See LED indication [▶ 3] for more information. Siemens A6V13959459_en--_a Smart Infrastructure 2023-07-11...
- Page 3 For example, if there is a Zigbee network failure when battery level is low, the LED flashes red fast rather than slowly. 2. Check if the hub is powered on and try to reduce distance between the sensor and the hub. 3. Try network reconnection. Siemens A6V13959459_en--_a Smart Infrastructure 2023-07-11...
- Page 4 Type summary Type Stock number Description SCH010ZB S55772-T115 Connected Home Presence Sensor Ordering When ordering, indicate product number, stock number and description.
- Page 5 Related documents such as the environmental declarations, declarations of conformity, etc., can be downloaded from the following Internet address: www.siemens.com/bt/download Notes Safety CAUTION National safety regulations Failure to comply with national safety regulations may result in personal injury and property damage.
- Page 6 For additional details, refer to Siemens information on disposal. Warranty Technical data on specific applications are valid only together with Siemens products listed under "Equipment combinations". Siemens rejects any and all warranties in the event that third-party products are used. Siemens...
- Page 7 Pairing method with GTW100ZB Global Link Key *) The range depends largely on building structure and indoor environment. PIR lens sensitive area Installation height 2.1 m Detection angle 90° Range 14 m x 10 m Siemens A6V13959459_en--_a Smart Infrastructure 2023-07-11...
- Page 8 General Dimensions See "Dimensions [▶ 9]" Color RAL9016 Sensor PIR sensor Firmware upgrade Via the mobile application Weight (net) 100.5 g Weight (with box, user document and 161.5 g accessory) Siemens A6V13959459_en--_a Smart Infrastructure 2023-07-11...
- Page 9 Dimensions Siemens A6V13959459_en--_a Smart Infrastructure 2023-07-11...
- Page 10 Issued by © Siemens 2023 Siemens Switzerland Ltd Technical specifications and availability subject to change without notice. Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug +41 58 724 2424 www.siemens.com/buildingtechnologies Document ID A6V13959459_en--_a Edition 2023-07-11...
