Connected Home Window Sensor
SCH020ZB
A6V13959555_en--_a
2023-07-11
Detects open/close status of doors and windows.
●
Easy to install practically anywhere: doors, windows, drawers, cupboards, jewelry
boxes and more
●
No power connection required; battery operation gives you the flexibility to install
the sensor nearly anywhere
●
Monitoring records notify you when something opens
●
Communicates with Connected Home Hub via Zigbee network
Smart Infrastructure
Advertisement
Related Manuals for Siemens SCH020ZB
Summary of Contents for Siemens SCH020ZB
- Page 1 Connected Home Window Sensor SCH020ZB Detects open/close status of doors and windows. ● Easy to install practically anywhere: doors, windows, drawers, cupboards, jewelry boxes and more ● No power connection required; battery operation gives you the flexibility to install the sensor nearly anywhere ●...
- Page 2 Press and hold it down for 3 s to join Zigbee network (initiated from the mobile application). ● Press and hold it down for 10 s to perform factory reset. ● See LED indication [▶ 3] for more information. Siemens A6V13959555_en--_a Smart Infrastructure 2023-07-11...
- Page 3 For example, if there is a Zigbee network failure when battery level is low, the LED flashes red fast rather than slowly. 2. Check if the hub is powered on and try to reduce distance between the sensor and the hub. 3. Try network reconnection. Siemens A6V13959555_en--_a Smart Infrastructure 2023-07-11...
- Page 4 Type summary Type Stock number Description SCH020ZB S55772-T116 Connected Home Window Sensor Ordering When ordering, indicate product number, stock number and description.
- Page 5 The sensor is designed for maintenance-free operation. Open Source Software (OSS) Software license overview The device uses Open Source Software (OSS). All Open Source Software components used in the product (including copyrights and licensing agreement) are available at http://siemens.com/bt/download. Siemens A6V13959555_en--_a Smart Infrastructure 2023-07-11...
- Page 6 For additional details, refer to Siemens information on disposal. Warranty Technical data on specific applications are valid only together with Siemens products listed under "Equipment combinations". Siemens rejects any and all warranties in the event that third-party products are used. Siemens...
- Page 7 Operation (in dry locations having no temperature or humidity control) Ambient humidity: 5...95 % r.h. (Non condensing) Temperature: -25...+70 ℃ Transport and storage (in packaging) Ambient humidity: 5...95 % r.h. (Non condensing) Operation altitude Max. 3,000 m above sea level Siemens A6V13959555_en--_a Smart Infrastructure 2023-07-11...
- Page 8 General Dimensions See "Dimensions [▶ 8]" Color RAL9016 Sensor Digital magnet sensor Firmware upgrade Via the mobile application Weight (net) 55 g Weight (with box, user document and 94.5 g accessory) Dimensions Siemens A6V13959555_en--_a Smart Infrastructure 2023-07-11...
- Page 10 Issued by © Siemens 2023 Siemens Switzerland Ltd Technical specifications and availability subject to change without notice. Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug +41 58 724 2424 www.siemens.com/buildingtechnologies Document ID A6V13959555_en--_a Edition 2023-07-11...
