Mounting and connection

Magnetic field!
WARNING
● Ensure that there is at least 30 cm spacing between the implants
and the products.
MiniCODER
► Ensure the measuring surface does not come into contact with other objects.
► Only touch connector pins and wires if you are suitably earthed, for example
using an ESD wrist strap, to prevent damage to the electronic components due
to electrostatic discharge.
► Only remove the MiniCODER from the original packaging immediately prior to
mounting.
Target wheel
► Check the target wheel for damage to the teeth and contamination. Replace a
damaged target wheel.
Measuring system
► Check the module of the MiniCODER and target wheel match.
► After mounting the MiniCODER ensure the air gap between the measuring sur-
face and measuring scale is within the range allowed to ensure correct func-
tion.
6.1

Preparing mounting

To ensure the correct function of the measuring system, MiniCODER and tar-
get wheel must be exactly aligned and the tolerances met.
