Step 4—Configure the Digital Process Controller
WARNING
D Select wiring and/or cable glands that are rated for the environment of use (such as hazardous area, ingress protection
and temperature). Failure to use properly rated wiring and/or cable glands can result in personal injury or property
damage from fire or explosion.
D Wiring connections must be in accordance with local, regional, and national codes for any given hazardous area
approval. Failure to follow the local, regional, and national codes could result in personal injury or property damage
from fire or explosion.
D To avoid personal injury resulting from electrical shock, do not exceed maximum input voltage specified on the product
nameplate. If the input voltage specified differs, do not exceed the lowest specified maximum input voltage.
D Personal injury or property damage caused by fire or explosion may occur if electrical connections are attempted in a
potentially explosive atmosphere or in an area that has been classified as hazardous. Confirm that area classification
and atmosphere conditions permit the safe removal of the terminal box cap before proceeding.
D The valve may move in an unexpected direction when power is applied to the digital process controller. To avoid
personal injury and property damage caused by moving parts, keep hands, tools, and other objects away from the
valve/actuator assembly when applying power to the instrument.
D While configuring the digital process controller the valve may move, causing process fluid or pressure to be released. To
avoid personal injury and property damage caused by the release of process fluid or pressure, isolate the valve from the
process and equalize pressure on both sides of the valve or bleed off the process fluid.
D Changes to the instrument setup may cause changes in the output pressure or valve travel. Depending on the
application, these changes may upset process control, which may result in personal injury or property damage.
Note
Before proceeding, check that all pressure connections, fasteners, and plugs are installed and tightened.
Note
The Write Protect Switch, shown in Figure 17, must be disabled in order to setup and configure the DPC2K.
Note
LoopConnect software is required to communicate with and configure the DPC2K digital process controller. The Local User
Interface allows for operational changes only. LoopConnect software is provided with the instrument, however, if a copy of this
software is needed contact your
34
Emerson sales office.
