Summary of Contents for CyberPower CPS3000PIE
- Page 1 CPS3000PIE USER MANUAL K01-0000010-00...
-
Page 2: Table Of Contents
CPS3000PIE TABLE OF CONTENTS SAFETY AND EMC INSTRUCTIONS………….……………………………………….………1 INSTALLING YOUR EPS………………………….………………………………….……3 BASIC OPERATION…………………………………………...4 REPLACING THE BATTERY…………………….……………………………………….…...….6 DEFINITIONS FOR ILLUMINATED LCD………….……………………………………7 EPS STATUS INQUIRY AND FUNCTIONS SETUP…….……………………………………8 FAULT WARNING DISPLAY AND ALARM……………………………………….………10 TROUBLESHOOTING……………………………………………………...11 TECHNICAL SPECIFICATIONS…………………………………………………….………..…12... -
Page 3: Safety And Emc Instructions
CAUTION! Do not disconnect the mains cable on the EPS or the building wiring socket outlet (shockproof socket outlet) during operations since this would remove the protective ground of the EPS and of all connected loads. CPS3000PIE K01-0000010-00... - Page 4 CPS3000PIE DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT! DO NOT use in any circumstance that would affect operation or safety of any life support equipment or with any medical applications or patient care. DO NOT USE WITH OR NEAR AQUARIUMS! To reduce the risk of fire or electric shock, do not use with or near an aquarium.
-
Page 5: Installing Your Eps
6. To maintain optimal battery charge, leave the EPS plugged into an AC outlet at all times. UPS will not function if the Bypass For Charge Only switch is enabled. Enabling the switch provides the bypass for charge only. INSTALLING YOUR EPS CPS3000PIE... -
Page 6: Basic Operation
Max. output of 1a is 20A; Max. output of 1b is 15A; Max. output wattage of (1a+1b) is 2250W Note：Maximum cord length is 10 meters and the cable O.D. must be 12AWG or greater. CPS3000PIE... -
Page 7: Installation Guide
4. Connect the AC power source to AC INPUT (Make sure AC power is off first). (Step3) 5. Connect the batteries to the BATTERY INPUT. (Step4) WIRING FAULT LED will illuminate to indicate the wiring polarity is reversed. Step 1 Step 2 CPS3000PIE Step 3 Step 4... -
Page 8: Replacing The Battery
Follow all local ordinances regarding proper disposal of batteries. Most retailers that sell lead-acid batteries collect used batteries for recycling. CAUTION! Do not open or mutilate the batteries. Released electrolyte is harmful to skin and eyes and may be toxic. Step 5 CPS3000PIE Step 6... -
Page 9: Definitions For Illuminated Lcd
5. AVR (Automatic Voltage Regulator) Icon: This icon will illuminate whenever your EPS is automatically correcting high or low AC line voltage. This is a normal, automatic operation of your EPS, and no action is required on your part. external battery CPS3000PIE... -
Page 10: Eps Status Inquiry And Functions Setup
8. FAULT MODE Icon: This icon illuminates if there is a problem with the EPS. Please contact CyberPower Systems for further help and support. 9. BATTERY CAPACITY Meter: This meter displays the approximate charge level (in 20% increments) of the EPS's external battery. - Page 11 Battery Shutdown Voltage: This function adjusts the UPS shutdown point according to the battery voltage. The settable items are sorted by unit as in the following table： Items Delay Time Battery AH Nominal Output Voltage Static Frequency Tolerance Slew Rate Battery Shutdown Voltage Unit CPS3000PIE...
-
Page 12: Fault Warning Display And Alarm
Over Load Icon. Long Beep Fault Icon Condition Alarm High Temperature Output-Off Over 70℃ Over Load Output-Off - Load exceed the rating of EPS. CPS3000PIE Solution Check fans function and air vent clearances. Check total load to confirm the rating of EPS. -
Page 13: Troubleshooting
EPS on. Turn the EPS off. Wait 10 seconds and then turn the EPS on. Contact Cyberpower Systems via phone at +31 (0) 40 2348170 or visit our website at www.cyberpowersystems.com CPS3000PIE... -
Page 14: Technical Specifications
Operating Temperature Operating Relative Humidity Physical Dimensions (L*W*H)( mm ) Weight (Kg) Agency Certificated CPS3000PIE 3000VA 2250W AVR ( Single Boost & Single Buck ) 140Vac – 300Vac 50/60 Hz +/- 3 Hz (auto sensing) Single Phase Pure Sine Wave at 220Vac +/- 10%...
