Purchased product may differ from image. Este manual está disponible en español en la página de Eaton: Eaton.com/support Ce manuel est disponible en français sur le site Web de Eaton : Eaton.com/support PRODUCT REGISTRATION Register your product today for a...
1. Important Safety Instructions SAVE THESE INSTRUCTIONS All sections of this manual contain instructions and warnings that should be followed during the installation and use of the SmartRack Modular Data Center described in this manual. Read all instructions and warnings thoroughly before attempting to move, install or use the SmartRack Modular Data Center equipment as described in this manual.
Page 4
1. Important Safety Instructions WARNING Hazard from moving parts: • Keep hands, clothing and jewelry away from moving parts. Check the equipment for foreign objects before closing the doors and starting the equipment. CAUTION Hazard to equipment or personnel: • All work must be performed only by qualified personnel. •...
Page 5
1. Important Safety Instructions • Install the cabinet securely to the building structure using the shipping brackets as illustrated in section 3.4 Leveling the POD Unit section of this manual. • Do not push the enclosures from the side panels to move it. Pushing from the side panels will cause a tipping hazard.
2. Overview SmartRack Modular Data Centers are composed of IT rack, cooling and service enclosures that together form a ® performance optimized data center, or POD. This reduces deployment time, lowers cost and simplifies the process of launching a new data center. Easy Configuration and Scalability •...
3. Configuration 3.1 Unpacking the IT Enclosure / Service Enclosure / Bayed IT and Cooling Enclosures / Bayed Service and Cooling Enclosure Confirm the shipping container is upright and stable, then use a utility blade to cut the shrink-wrap securing the corner protectors. Apply the utility blade directly over the corner protectors to prevent the utility blade from...
Page 8
Examine the enclosure for any damage or loose parts. Confirm all parts are present. If anything is missing or damaged, contact Eaton for assistance. Do not attempt to use the enclosure if it has been damaged. Use a 13 mm open-end wrench to remove the shipping brackets.
Page 9
3. Configuration Position at least one person at the front of the enclosure and one person at the rear of the enclosure. Slowly push the enclosure toward the back of the shipping pallet until all four casters go over the edge of the pallet and touch the floor.
Page 10
3. Configuration 3.2 Placement IMPORTANT! Cooling units are top-heavy and can present a tipping hazard if handled incorrectly. Please refer 1.2 Cooling Enclosure Warnings before proceeding with the SRPOD configuration. Use the casters to move all combined or individual enclosures for a short distance over a level, smooth, stable surface by pushing it from the front or rear (not the side panels).
Page 11
3. Configuration • 1 pallet: Contains one medium service enclosure. • 2 pallets: Each pallet contains one outdoor condenser unit. After unpacking the pallets noted above, then proceed with the configuration assembly and follow these steps, starting from the right side of the final configuration. Enclosure SET 3 Enclosure SET 2 Enclosure SET 1...
Page 12
3. Configuration The final configured and assembled sample model SRP-2R-2C12-M should appear like the illustration below. Cooling System with Enclosure and Outdoor Condenser (Not Shown) 7” Touchscreen Cooling Display Refrigerant Tubes Entry (Top or Bottom Entry) IT Rack Enclosure with Clear Acrylic Window Adjustable Cable Service Hood with 4 Cable Entry Hole...
Page 13
3. Configuration 3.4 Leveling the POD Unit WARNING: Level the enclosure before attempting to install equipment. The casters are not designed to provide long-term support for the enclosure. Use the levelers to provide long-term support. Install the POD unit in a structurally sound area with a level floor that can bear the weight of the enclosures, all equipment that will be installed in the enclosures and any other enclosures and/or equipment that will be installed nearby.
Page 14
Use a 13 mm open-end wrench to connect the brackets to each enclosure’s outer bracket mounting points. Then attach the brackets to secure mounting points in the floor with user- supplied hardware or Eaton’s SmartRack Bolt-Down Kit (Model: SRBOLTDOWN).
4. Installation 4.1 Cooling Unit Installation For complete installation, startup and commissioning instructions for the Cooling Enclosure, refer to the SRCOOLDRXW12/SRCOOLDRXW25 Installation Manual. 4.2 IT Enclosure Installation 4.2.1 IT Enclosure Roof Panel The IT Enclosure’s roof panel is adjustable. Determine the cable routing hole(s) where the cable hood(s) will be positioned .
Page 16
4. Installation 4.2.2 Cable Management and Routing This section will provide steps and options to route power, ethernet and fiber cables. There are three cable routing options. Option 1: Routing cables directly into each IT Rack enclosure from the top. Route the cable(s) from the IT Enclosure through the brush strips into the cable plenums on the top of the enclosure and out through the cable hood.
Page 17
4. Installation Option 3: Routing cables from the service compartment and across the cable plenum at the top of all IT and cooling enclosures. Remove the top horizontal beams of the enclosures you wish to run wire through. Run the cable(s) through the brush strips and across to the neighboring racks (Optional) Depending on the cable management strategy, run the cable(s) out to the PDU(s) housed in the service enclosure and through the roof panel’s cable hood.
Page 18
4. Installation 4.2.3 Adjusting Mounting Rails and Cable Management Rails WARNING: Do not attempt to adjust rails without assistance. Do not attempt to adjust rails while equipment is installed in the enclosure. Do not attempt to use rails without screws installed (6 per rail). The 4 mounting rails are pre-installed to accommodate equipment with a mounting depth of 30 inches (762 mm).
Page 19
4. Installation 4.2.4 Equipment Installation WARNING: Do not install equipment until you have stabilized the enclosure. Install heavier equipment first and install it toward the bottom of the enclosure. Install equipment starting from the bottom of the enclosure and proceeding toward the top of the enclosure - never the reverse. If using sliding equipment rails, be careful when extending the rails.
Page 20
4. Installation After installing the required cage nuts, use the included mounting screws and cup washers to secure your equipment to the rack rail. Place the cup washers between the screws and the equipment mounting brackets. Note: Your equipment may also include mounting hardware. Read the mounting instructions that came with your equipment before installing your equipment.
Page 28
TrippLite.Eaton.com/ModularDataCenter Dimensions: INCHES [mm] Eaton 1000 Eaton Boulevard No part of this document may be Cleveland, OH 44122 reproduced in any way without the United States express written approval of Eaton. Eaton.com Follow us on social media to get the...
Page 29
BACK VIEW Dimensions: INCHES [mm] Learn more at TrippLite.Eaton.com/ModularDataCenter Dimensions: INCHES [mm] Eaton 1000 Eaton Boulevard No part of this document may be Cleveland, OH 44122 reproduced in any way without the United States express written approval of Eaton. Eaton.com...
Page 32
No part of this document may be Cleveland, OH 44122 reproduced in any way without the United States express written approval of Eaton. Eaton.com Follow us on social media to get the Eaton reserves the right to change latest product and support information.
Page 36
SIDE VIEW Dimensions: INCHES [mm] Learn more at TrippLite.Eaton.com/ModularDataCenter Dimensions: INCHES [mm] Eaton 1000 Eaton Boulevard No part of this document may be Cleveland, OH 44122 reproduced in any way without the United States express written approval of Eaton. Eaton.com...
Appendix MODELS: SRCOOLDXRW12, SRCOOLDXRW25 SmartRack® In-Row Precision Air Conditioning Units FRONT VIEW Touchscreen Side Air Discharge PIPING CONNECTIONS Main Electrical Input Outdoor Unit Electrical Input Signal Wiring Input Gas Pipe Liquid Pipe Accessory and Network Cable Access Port Water Drainpipe FRONT VIEW TOP VIEW BOTTOM VIEW...
Page 38
Appendix Specifications Models SRCOOLDXRW12 SRCOOLDXRW25 Model Includes In-Row Cooler + External Condenser In-Row Cooler + External Condenser Rated Cooling Capacity 12.8 kW (43,686 BTU/hr) 25.8 kW (88,033 BTU) Input Power 208V, 3-Phase 208V, 3-Phase Min. Circuit Ampacity (MCA) Max. Overcurrent Protection (MOP) Frequency 60 Hz 60 Hz...
Page 44
Appendix Electrical Panel SRCOOLDXRW12 Modbus Modbus Condenser Condenser Main Power Main Power Power Condenser Condenser Main Signal Signal Webcard Webcard Heater Power Signal Heater Solenoid Solenoid Power for Power for Power for Power for Low Temp Low Temp Extension Extension Solenoid Pipe Solenoid...
Page 45
About Tripp Lite by Eaton Tripp Lite joined the Eaton family in March 2021. Eaton has long been a premier name in backup power and power management. The acquisition of Tripp Lite transforms Eaton’s distributed IT infrastructure and connectivity equipment capabilities. Combining our product strengths and expert personnel allows us to offer comprehensive and innovative solutions for critical power and digital infrastructure applications, backed by quality, service and support you can trust.
Appendix Bid Specifications SmartRack In-Row Precision ® Cooling – DX Split Models: SRCOOLDXRW12, SRCOOLDXRW25 Standard Features • EC fans • Inverter-driven compressor • Side and/or front air discharge • Color touchscreen user interface • Air filtration • R-410A refrigerant • Outdoor air-cooled condenser •...
Page 47
Appendix A. PERFORMANCE SRCOOLDXRW12 SRCOOLDXRW25 Working conditions Rated cooling capacity (see Section CC 12.8 kW (43 kBTU) 25.8 kW (88 kBTU) for additional detail) Rated indoor return air temperature and 98.6°F (37°C) 98.6°F (37°C) RH 24%.* Rated outdoor temperature 95°F (35°C) 95°F (35°C) Energy Efficiency Rating (EER) W/W Approx minimum cooling capacity...
Page 48
Appendix D. INVERTER AND COMPRESSOR 1. Modulates compressor speed between 30~100% a. SRCOOLDXRW12: 60~180 Hz b. SRCOOLDXRW25: 90~270 Hz 2. Conserves energy by operating the compressor at partial load 3. Fault indicator on the inverter for easy troubleshooting 4. Soft start (in-rush current less than full load) to downsize breaker size 5.
Page 49
Appendix F. CONDENSER 1. Remote condenser rejects all heat to the outdoors, no building HVAC or commercial cooling system required 2. Properly sized, comes standard with each In-Row (indoor) cooler 3. Powered via In-Row (indoor), no separate power source required 4.
Page 50
Appendix I. REFRIGERANT 1. Sight glass (included) a. Assists in checking refrigerant quality and charge level 2. Nominal charge: a. SRCOOLDXRW12: 12.1 lb. (5.0 kg) b. SRCOOLDXRW25: 17.4 lb. (8.0 kg) c. Actual charge depends on application (see installation manual) 3.
Page 51
Appendix K. STABILIZERS 1. Casters a. Qty. 4 all four corners b. Full swivel for each c. Allows cabinet to be maneuvered from room to room and into position without the need for special lifting equipment 2. Leveling feet a. Qty. 4 adjustable leveling feet all four corners b.
Page 52
Appendix O. MAINTENANCE MODE 1. Instantly switches the In-Row unit into max-cooling mode to help exhaust the hot aisle of hot air while technicians are working 2. No password required; no hassle of getting permissions to access the settings menu 3.
Page 53
Appendix R. GROUPING 1. Group (link) multiple In-Row coolers together for: a. Rotation b. Redundancy 2. Inter-compatibility between SRCOOLDXRW12 and SRCOOLDXRW25 3. Rotation a. Balance runtimes among all In-Row units in a group to ensure even wear and tear 4. Redundancy a.
Page 54
Appendix V. USER INTERFACE 1. 7 in. color touchscreen high resolution interface 2. Allows user and service personnel to adjust settings mentioned throughout this document a. User supply air temp setting range: 64~99°F (18~37°C) 3. Features home screen with status indicators 4.
Page 55
Appendix BB. DOCUMENTATION 1. Content: a. Installation Guide (shipped with product) b. Owner’s Manual (shipped with product) c. Submittal Drawing (website) d. Service Manual (for certified technicians) e. Bid Specifications (website) 2. Translations for manuals: a. English b. Spanish c. French CC.
Page 56
• Supply air temperature sensor failure • High water level (condensate overflow prevention) Eaton has a policy of continuous improvement. Product specifications are subject to change without notice. Photos and illustrations may differ slightly from actual products. Eaton 1000 Eaton Boulevard...
