830-629-2900 / 800-729-3839 / Fax 800-653-3839 / Text photos only: 830-481-6433 / INTERNET: www.detex.com
DWG #: 100717
Device parts breakdown view & part numbers..................
Assemble Trim..................................................................
Door Prep - Interior Door Face..........................................
Mark Cylinder Tailpiece Length.........................................
Trim Cylinder Tailpiece.....................................................
Assemble Trim to Door.....................................................
For WARRANTY information,
scan code below or
go to www.detex.com/warranty
Detex Corporation, 302 Detex Drive, New Braunfels, Texas 78130-3045
INSTALLATION INSTRUCTIONS FOR 03W ADVANTEX TRIM
Table of Contents
(Always put on safety glasses prior to beginning installation of unit)
Screw Driver (Phillips Drive)
Owner's Copy
TOOLS AND SUPPLIES
Safety Glasses
Pencil
Center Punch
Hammer
Drill Motor
Drill Bits & Taps
Tape Measure
101260 Page 1
101260 June 7, 2021
Page
2
2
3
3
4
4
For device installation videos,
scan code below or
go to www.detex.com/videos
B
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Detex 03W ADVANTEX TRIM
Summary of Contents for Detex 03W ADVANTEX TRIM
- Page 1 101260 June 7, 2021 Detex Corporation, 302 Detex Drive, New Braunfels, Texas 78130-3045 830-629-2900 / 800-729-3839 / Fax 800-653-3839 / Text photos only: 830-481-6433 / INTERNET: www.detex.com INSTALLATION INSTRUCTIONS FOR 03W ADVANTEX TRIM DWG #: 100717 Table of Contents Page Device parts breakdown view &...
- Page 2 ITEM PART NO. DESCRIPTION 101620-9 TRIM PLATE, 03W, BRUSHED STAINLESS STEEL FINISH (630) ECL-445-X-X CYLINDER, RIM, 5 PIN IC7R-X CYLINDER, RIM, INTERCHANGEABLE, 7 PIN 100752-X CYLINDER COLLAR, TALL 100464-9 SEX NUT, 1/4-20 100301-1 CYLINDER BRACKET, 1" LONG Screws supplied with cylinder Sold separately ASSEMBLE THE TRIM: If not already assembled, assemble...
- Page 3 Mark backplate holes Door 4 places Face (backplate supplied with exit device) Detex recommended STRAIGHT and LEVEL Note: All holes MUST be drilled 40" Drill 3/8" holes thru door Drill 1-1/2" hole thru door (4 places)
- Page 4 Trim Cylinder Tailpiece Remove trim assembly from door and cut the tailpiece just inside of the mark. Caution: Tailpiece must not extend past the cam. Assemble Trim to Door Install sex nuts With the key out of the cylinder, assemble the trim and backplate to the door, making sure that cylinder tailpiece enters the backplate cam.
