830-629-2900 / 800-729-3839 / Fax 800-653-3839 / Text photos only: 830-481-6433 / INTERNET: www.detex.com
INSTALLATION INSTRUCTIONS FOR ADVANTEX MORTISE LOCK 30 & F30 SERIES DEVICE
Drawing #: 103200 (SS)
104695 (AL)
Table of Contents
Device Parts Breakdown View...............................................................
Device parts breakdown list with part numbers....................................
Hardware List with part numbers & tools required................................
Door prep & OKC installation (if required)............................................
Install Mortise Lock, Backplate, Strike And Device..................................
Check For Device Clearance, Level Device..............................................
Troubleshooting & optional accessories...............................................
Should you have a Qustion/Problem with your Detex device please call Detex Technical Support
from the job site at 1-800-729-3839 and choose option 2 on our menu. Please do not return the
product to the distributor.
For WARRANTY information,
scan code below or
go to www.detex.com/warranty
Detex Corporation, 302 Detex Drive, New Braunfels, Texas 78130-3045
& "W" (Weatherized) MODELS
R
Owner's Copy
104883 Page 1
104883 March 18, 2020
Page
2
3
4
5
6
7
7
For device installation videos,
scan code below or
go to www.detex.com/vidoes
B
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Detex ADVANTEX 30 Series
Summary of Contents for Detex ADVANTEX 30 Series
- Page 1 104883 March 18, 2020 Detex Corporation, 302 Detex Drive, New Braunfels, Texas 78130-3045 830-629-2900 / 800-729-3839 / Fax 800-653-3839 / Text photos only: 830-481-6433 / INTERNET: www.detex.com INSTALLATION INSTRUCTIONS FOR ADVANTEX MORTISE LOCK 30 & F30 SERIES DEVICE & "W" (Weatherized) MODELS...
- Page 2 2KIT 1KIT 104883 Page 2...
- Page 3 Strike Kit, Double door, long open back (includes hardware) Front plate 103203-X Mortise lock, standard 103320-1 Mortise lock, EE 103303-2 Latchbolt block 103273 Your particular part or configuration may not be shown: Contact Detex technical support at 800-729-3839 (option 2) 104883 Pg 3...
- Page 4 Hardware Table for BASIC device mounting. Additional hardware is provided per the device configuration Fastener Part No Drill Bit P/N: 100980 #7 or 13/64" 1/4-20 x 1" PPH P/N: 100954 #7 or 13/64" 1/4-20 x 1-1/2" PPH P/N: 101621-5 #7 or 13/64" 1/4-20 x 1/4"...
- Page 5 STEP 1: DOOR PREP (Note: LHR installation shown) Use plastic template to mark and drill mortise lock and backplate holes Door prepared to Plastic template P/Ns: ANSI A115.13 103283 (LHR) See T2000 (metal) and 103284 (RHR) T2001 (wood) templates Mark backplate holes Door Mark mortise access holes...
- Page 6 STEP 3: INSTALL MORTISE LOCK Install mortise lock To change lock HANDING: Remove block and rotate latchbolt Install plate with (2) screws Install lock with (2) screws Reposition block after handing STEP 4: INSTALL BACKPLATE STEP 5: INSTALL STRIKE Install Strike Install backplate &...
- Page 7 CHECKING FOR DEVICE CLEARANCE Slide endcap assembly onto extrusion (Cut-Off procedure if required) Secure with tape Cut fillerplate and extrusion before cutting STRAIGHT & SQUARE to Minimum desired length and deburr Fillerplate Length Type Length (L) 2-1/2" HD/CD 3" CAUTION: Check for device and door frame clearance.
