Concealed Vertical Rod Exit Device

62 / F62 / 63 / F63 Series

for Medium to Wide Stile

Hollow Metal door applications

Drawing No. 105260

For WARRANTY information,

scan code below or

go to www.detex.com/warranty

Should you have a Question/Problem with your Detex device please

call Detex Technical Support from the job site at 1-800-729-3839

and choose option 2 on our menu. Please do not return the product

to the distributor.

Detex Corporation, 302 Detex Drive, New Braunfels, Texas 78130-3045

Table of Contents

Device parts breakdown view................................................

Device parts breakdown list with part numbers.....................

Hardware List with part numbers & tools required.................

Step 1: Door/opening measurements....................................

Step 2: Door & frame prep ...................................................

Step 3: Top rod assembly and initial adjustment .................

Step 4: Bottom rod / latch assembly initial adjustment .........

Step 5: Visual alignment check ............................................

Step 6: Install top latch mounting bracket ............................

Step 7: Insert rod / latch / centerlift assembly into door .......

Step 8: Secure rod / latch / centerlift assembly to door .......

Step 9: Verify centerlift mechanism operation ...................

Step 10: Hang door / assemble device to door ....................

Check device for clearance ....................................

Install mortise cylinder ...........................................

Step 11: Install top strike.......................................................

Step 12: Install bottom strike.................................................

Step 13: Fine latch adjustment .............................................

Step 14: Install covers ..........................................................

Step 15: Install auxiliary bolt.................................................... 18

Optional accessories ............................................................

Owner's Copy

104885 Page 1

104885

March 18, 2020

Page

7 & 8

For device installation videos,

scan code below or

go to www.detex.com/videos

Need help?

Do you have a question about the ADVANTEX 62 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Detex ADVANTEX 62 Series

Page 1 104885 March 18, 2020 Detex Corporation, 302 Detex Drive, New Braunfels, Texas 78130-3045 830-629-2900 / 800-729-3839 / Fax 800-653-3839 / Text photos only: 830-481-6433 / INTERNET: www.detex.com Concealed Vertical Rod Exit Device 62 / F62 / 63 / F63 Series...
Page 2 Parts listed will vary according to product configuration. Mortise cylinder available as an option. Standard Yale type cam required. See Mortise cylinder installation page. Your particular part or configuration may not be shown: Contact Detex technical support at 800-729-3839 (option 2) 16 KIT 1KIT 104885 Page 2...
Page 3 Fillerplate Subassembly, S&R, Hex Dogging, HD, 630 104112-9 Centercase Cover, Stainless Steel, Narrow, CVR 630 102216-2 Hex Dogging Assembly 102216 Cylinder Dogging Assembly Your particular part or configuration may not be shown: Contact Detex technical support at 800-729-3839 (option 2) 104885 Page 3...
Page 4 Hardware Table for BASIC device mounting. Additional hardware is provided per the device configuration in kit form and is addressed on the appropriate pages as required. Device Mounting Hardware Used to install backplate & endcap bracket to door. #14 x 1" PPHS Drill Bit - 3/16 pilot hole x 1"...
Page 5 Unreinforced Doors: Use Sex Nuts and Bolts Minimum Stile Width: 3-1/2" Unreinforced Frames: Use Blind Rivet Nuts (see sketch). Fasteners for unreinforced openings are not supplied by Detex. Reinforced door or Reinforcement frame engages at least (3) screw threads.
Page 6 DOOR OPEN DIRECTION ALIGN TEMPLATE Top strike template WITH LATCH AND DEVICE VERTICAL Template #105299 CENTERLINE DEVICE VERTICAL *NOTE: FOR FURTHER DOOR CONSTRUCTION & FRAME PREP DETAILS, SEE TEMPLATE T2306, T2307, T2308 OR T2309 ON DETEX WEBSITE 104885 Page 6...
Page 7 For 6'-8" (80") to 8'-0" (96") Door STEP 3: TOP ROD ASSEMBLY & INITIAL ADJUSTMENT 3a. Align hole A in rod 104187 with hole in top latch as shown at right & tap the 13/16" long pin into latch hole. 3b.
Page 8 For 8'-1" (97") to 10' (120") Door STEP 3: TOP ROD ASSEMBLY & INITIAL ADJUSTMENT 3a. Align hole A in rod 105097 with hole in top latch as shown at right & tap the 13/16" long pin into latch hole. 3b.
Page 9 STEP 4: BOTTOM ROD / LATCH ASSEMBLY & ADJUSTMENT (Disregard if TRO device is being installed) Align rod holes with bottom latch (round DIM A to nearest value shown) 4a. Using DIM A as measured in step 1, use chart to determine DIM A Bottom Rod pinning location.
Page 10 3/8" from top of door STEP 5: to latch body VISUAL ALIGNMENT CHECK: Latch must be in RETRACTED position 5a. Lay internal latch components onto door for trial fit. Take care to protect door finish. 5b. Ensure top latch is in retracted position. Hold top rod in place and push top latch case towards device until latchbolt is...
Page 11 STEP 6: ATTACH TOP LATCH MOUNTING BRACKETS Attach top latch brackets as shown below. Three screws (10-24 x 5 /16" PFHUMS) required for each bracket. both sides for FIRE 104123-1 104123-1 104123-2 104123-2 this side this side for RHR for LHR STEP 7: INSERT ROD / LATCH / CENTERLIFT ASSEMBLY INTO DOOR 7a.
Page 12 104885 Page 12...
Page 13 104885 Page 13...
Page 14 STEP 10: HANG DOOR / ASSEMBLE DEVICE TO DOOR INSTALL DOOR ONTO FRAME PER MANUFACTURER'S SPECIFICATIONS setscrew if required Rehanding procedure LIFT PIN MUST BE ON BOTTOM liftpin Remove setscrew then liftpin which screws out of the back. MOVE LIFT PIN & SETSCREW TO BOTTOM POSITION ON CARRIAGE.
Page 15 CHECKING FOR DEVICE CLEARANCE (Cut-Off procedure if required) Slide endcap assembly onto extrusion Cut fillerplate and extrusion STRAIGHT & SQUARE to desired length and deburr Minimum Secure with tape Fillerplate before cutting Length Type Length (L) 2-1/2" CAUTION: HD/CD 3" Check for device and door frame clearance.
Page 16 STEP 11: TOP STRIKE INSTALLATION Door frame header Door stop Begin strike installation with Tilt strike pocket Top strike pocket notched side of pocket towards to fit into cutout inside door face. If additional adjustment is needed, rotate Top strike pocket Shim Strike insert Door stop side...
Page 17 STEP 13: FINE LATCH ADJUSTMENT 13a. Ensure that latches are fully retracted. Gently close door. Latches should extend when door is closed. 13b. Depress pushpad and open door. Top latch should clear top strike & bottom bolt should not drag. Latches should remain in retracted position with pushpad released.
Page 18 A door locking popper is required when a fire door utilizes a top latching mechanism only (TRO). The popper is designed to project a spring loaded bolt into the adjacent frame or door in the event of fire. Detex recommends installing the popper in the edge of the door 12" above the threshold or finished floor.
Page 19 Optional Accessories Sex Nut Kits: Catalog No. SN3 Catalog No: SN3 (uses screws in hardware kit) The #1/4-20 kits are available in 3 finishes: Brushed Brass BHMA 606: p/n 105274-2 Stainless Steel BHMA 630: p/n 105274-9 Oil Rubbed Bronze BHMA 613: p/n 105274-25 Tamper Kit (Security Kit) Catalog # &...
