Hardware and legs stored in the box ,please take out of assembly .
It is recommended to install protective pads under all legs and supports to avoid damage or scratches when placing
furniture on a wood floor or other hard surface, and to limit indentation and prevent discoloration if placing on carpet.
PARTS LIST
NO.
A
B
C
D
E
F
G
STEP 1:
B
B
A
MADE IN VIETNAM
ASSEMBLING INSTRUCTIONS
9435SV-3WD
ITEM NO:
ELEGANT LOUNGER
DRAWING
G
D
E
F
QTY
1 PC
4 PCS
1 PC
16 PCS
16 PCS
16 PCS
1 PC
B
B
B
DESCRIPTION
SEAT
WOODEN LEG
SUPPORT LEG
BOLT
Ø1/4"*32mm
SPRING WASHER
Ø1/4"
FLAT WASHER
Ø1/4"*19mm
ALLEN KEY
4mm*60mm
Page: 1/2
