(1/2)Power Left Side Reclining 2- Seater with Power Headrest
NOTE: Do not use power tools for assembly. Power tools increase the risk of over tightening which leads to splitting or cracking
the wood.
COMPONENT LIST
NO.
A
B
C
HARDWARE LIST
NO.
1
2
3
4
5
6
7
8
Assembly Instruction
ITEM NO.: 9414-LPWH
DRAWING
DRAWING
QTY
DESCRIPTION
1 PC
LSF 2-SEATER
1 PC
LSF BACKREST
CENTER
1 PC
BACKREST
QTY
DESCRIPTION
METAL LEG
2 PCS
PLASTIC SUPPORT
1 PC
LEG (126MM)
4 PCS
BOLT (8x30MM)
4 PCS
LOCK WASHER (16MM)
1 PC
ALLEN KEY (30MM)
8 PCS
SCREW (35MM)
1 PC
ADAPTOR
1 PC
PLUG WITH WIRE
QP-AI-P022-000-0
(127MM)
1/4
Advertisement
Related Manuals for Homelegance 9414-LPWH
Summary of Contents for Homelegance 9414-LPWH
- Page 1 QP-AI-P022-000-0 Assembly Instruction (1/2)Power Left Side Reclining 2- Seater with Power Headrest ITEM NO.: 9414-LPWH NOTE: Do not use power tools for assembly. Power tools increase the risk of over tightening which leads to splitting or cracking the wood. COMPONENT LIST...
- Page 2 QP-AI-P022-000-0 STEP#1 Unpack the hardware from underneath of LSF 2-seater (A). STEP#2 Align and attach legs (1) to chair, insert bolts (3) and washers (4) and tighten with Allen key (5). Insert screw (6) and tighten with screw driver. Attach and rotate clockwise to tighten the plastic supported leg (2). STEP#3 Connecting the wire from back rest to seat for power headrest.
- Page 3 QP-AI-P022-000-0 STEP#4 Align the male connecting brackets of LSF 2-seater onto the female brackets of RSF chaise, push to the end and make sure it is fixed in position securely. STEP#5 Carefully align and connect the plug with wire (8) to the slot at the adapter (7). Align and attach the cord of adapter (8) to the slot of chair and make sure it is connected with securely.
- Page 4 QP-AI-P022-000-0 CARE INSTRUCTION FOR POLYESTER: In order to maintain the original appearance of your polyester furniture, please follow below simple care procedure : Avoid exposing furniture directly to sunlight or heating and air conditioning outlets. Exposure to sunlight or heating and air conditioning outlets will fade/damage polyester.
- Page 5 QP-AI-P022-000-0 Assembly Instruction (2/2)Right Side Chaise with Adjustable Headrest ITEM NO.: 9414-RC NOTE: Do not use power tools for assembly. Power tools increase the risk of over tightening which leads to splitting or cracking the wood. COMPONENT LIST DRAWING DESCRIPTION 1 PC RSF CHAISE HARDWARE LIST...
- Page 6 QP-AI-P022-000-0 STEP#1 Cut off the rope that tight to the hardware package on the box. Unpack the hardware. STEP#2 Align and attach legs (1) to chair, insert bolts (4) and washers (5) and tighten with Allen key (6). Insert screw (7) and tighten with screw driver.
