- Page 1 Extension pair of L brackets for Home2 and CineTension2 series User Guide ZHOMELB11-4 and ZHOMELB12-8 Rev. 1/5/2015 EA www.elitescreens.com info@elitescreens.com...
- Page 2 Dimensions Chart and Drawings Part Number Dimensions 50mm (1.96”) W x 200mm (7.87”) H x ZHomeLB12-8 300mm (11.81”) L x 2.5mm T Part Number Dimensions 44.5mm (1.75”) W x 100mm (3.93”) H HomeLB11-4 x 273.5mm (10.76”) L x 2.5mm T Rev.
- Page 3 1. Combination examples Maximum and Minimum extension dimensions Example A. (dimensions in mm, 10 mm = 0.3937 inch) LB11-4 Max. Extension LB12-8 Example B. (dimensions in mm, 10mm=0.3937 inch) LB11-4 Min. Extension LB12-8 2. Combination examples with Home2/CineTension2 Example C. Home2/CineTension2 Series standard bracket Rev.
- Page 4 Example D. Home2/CineTension2 Series standard bracket Example E. Note: LB11-4 bracket installs same as example Home2/CineTension2 Series standard bracket...
- Page 5 “L” bracket Installation: Drill a Hole (use a 2/5 inch drill) in the desired location. Insert anchor into the drilled wall. Insert the wood screw thru the screw hole on the “L” bracket and into the anchor. Screw in the wood screw to secure the installation Note: Do not install the L brackets on dry-wall.
