Overview
1
(1)Front panel
(2)Touch button
(6)Heat sink
(7)DC switch
(11)USB port
(12)AC terminal
Note：
1.This document is for quick installation guidance only, please refer to User Manual for more details
2.Growatt shall not be liable for any damage resulting from unproper installation
2
Installation
.
System overview
2.2
Wall mounting
1 54
Note:
1.When drilling holes in the wall, avoid water and electricity pipes, otherwise it may cause danger.
unit:mm
2 3 4
(3)OLED screen
(8)PV terminal
2.1
Installation requirements
≥300mm
unit:mm
MIN 7000-10000TL-X2 Quick Guide
5
6
(4)LED indicator
(9)COM port
.
≥300mm
≥300mm
≥500mm
7
8
9 10 11
12
(5)Mounting bracket
(10)Vent valve
.
425.2mm
180mm
172mm
93mm
