User Manual
Remote Control IK1 Transmitter
Technical description

IK1 Detailed description

IK1 Model code creation

©
8 | Danfoss | March 2024
Description
Stop Function (2.4 GHz)
Ingress Protection rating
Anti-condensation system
Frequency band - ERP
Range Line of sight (guaranteed)
Main mechanisms (maximum
number)
Auxiliary mechanisms
Side Buttons
Trigger (with Pistol Grip)
Removable EEPROM
Battery model
Battery life
Response Time
Operating temperature range
Storage Temperature Range (24h)
Storage Temperature Range (long
periods)
Relative Humidity
Weight (with battery)
Dimensions LxWxH mm
Harness
Available Options
Display
LED Panel
Tether connector
Range limiter
Associated receivers (2.4GHz)
The model code generation is based on a model code:
1. Family: IK1
2. Variant: G Pistol Grip, B Console Box
3. Power Supply: 1: Alkaline Batteries, 2: NiMH Rechargeable Batteries, 3: Li-Ion Rechargeable Batteries
4. Charging Type: N: No Charger, D: Docking Station, C: Battery Charge
Example:
IK1 - G1N ( with Pistol Grip, alkaline batteries and no charger)
IK1 - G3C (with Pistol Grip, Li-Ion battery and BC70 charger)
IK1 - G3D (with Pistol Grip, Li-Ion battery and Docking station)
IK1 – B1N (console Box Style, alkaline batteries and no charger)
Value
Cat3 - PLe
IP65/NEMA4
Goretex Film
2405MHz to 2475MHz ; ERP 20dBm/100mW
100m
Thumb Joysticks (2)
up to 9 toggle switches
up to 6 buttons
Proportional Trigger
External
Alkaline Battery Pack (4xAA Batteries) BT11K
15 - 24 hours
100ms
-20 °C to 70 °C (-4 °F to 158 °F)
-25ºC to 75ºC (-13ºF to 167ºF)
-25ºC to 55ºC (-13ºF to 131ºF)
max. 95% without condensation
800 grams
268.3 x 125 x 123.4
magnets on grip to stick on metallic surfaces
128x64 Graphic LCD
na
Yes (M12 Connector)
na
MP08, MPCAN, MP20, R11, R13F
7 - 11 hours
BC483463529151en-000101
