  • Page 1 Liquid level transmitter Type AKS 41 / 41U REFRIGERATION AND Technical leaflet AIR CONDITIONING DIVISION...

  • Page 2: Table Of Contents

    Technical leaflet Liquid level transmittter, type AKS 41 / 41U Contents Page Introduction..................3 Special features.

  • Page 3: Introduction

    Liquid level transmittter, type AKS 41 / 41U Introduction AKS 41 / 41U liquid level transmitters are used to The 4-0 mA signal from AKS 41 / 41U can be measure the liquid level in refrigerant vessels. used in conjunction with a controller to control the refrigerant liquid level.

  • Page 4: Design

    Technical leaflet Liquid level transmittter, type AKS 41 / 41U Design Electronic head and sensor tube can be Plug can be mounted in 4 different positions. separated without emptying the standpipe. Plug   Inner pipe Outer pipe DIN connection...

  • Page 5: Function And Factory Setting

    3. Activate the calibration pushbutton to the calibration pushbutton and keep it pressed select required refrigerant. while 24 V a.c. is connected and then release the Each activating will cause AKS 41 / 41U to pushbutton. step to next refrigerant according to below sequence: NOTE! This sequence must be observed.

  • Page 6: Signal Damping

    Default factory setting is: /min. calibration points have to be adjusted. 0% (AKS 41 / 41U free of liquid) output signal: 4 mA 100% (AKS 41 / 41U fully covered by liquid) output If the AKS 41 / 41U is used in a refrigerant, not signal: 0 mA already defined in AKS 41 / 41U.

  • Page 7: Reset To Factory Setting

    8. Output now corresponds to the value measured at the latest activation. measured at the latest activation. Reset to factory setting AKS 41 / 41U can always be reset to factory setting regardless of any revised calibration values. 1. Press the calibration pushbutton and keep it activated in min.

  • Page 8: Aks 41

    Technical leaflet Liquid level transmittter, type AKS 41 / 41U Ordering - AKS 41 Type Length Length Measuring Measuring AKS 41 AKS 41 range range without with Bargraph Bargraph Code no. Code no. AKS 41-3 11.0 084H4053 084H4153 084H4055 084H4155 AKS 41-5 19.69...

  • Page 9: Dimensions And Weights

    Technical leaflet Liquid level transmittter, type AKS 41 / 41U AKS 41 Type Insertion Weight Dimensions and weights length kg / lb AKS 41-3 80 mm (11.0”) 1.7 / 3.7 AKS 41-5 500 mm (19.69”) .0 / 4.4 AKS 41-8 800 mm (31.50”)
  • Page 10 Technical leaflet Liquid level transmittter, type AKS 41 / 41U RD8AA50 → DKRCI.PD.SC0.A1.0 / 50H009  Danfoss A/S, (AC-DSL / MWA), 04 - 006...
  • Page 11 Technical leaflet Liquid level transmittter, type AKS 41 / 41U RD8AA50 → DKRCI.PD.SC0.A1.0 / 50H009  Danfoss A/S, (AC-DSL / MWA), 04 - 006...
  • Page 12 Technical leaflet Liquid level transmittter, type AKS 41 / 41U RD8AA50 → DKRCI.PD.SC0.A1.0 / 50H009  Danfoss A/S, (AC-DSL / MWA), 04 - 006...
