- Page 1 Northstar Classic LE SRL Manual STANDARDS Class ANSI Z359.14-2021 Anchor above or OSHA 1910.140, 1910.66 below dorsal D-ring V3. 2023 Copyright Safewaze: 220-00080...
- Page 2 • The user must read, understand, and follow all safety and usage information contained within this manual. • The user must safely and effectively use the Northstar Classic LE SRL and all equipment used in conjunction with the SRL. • Failure to follow all safety and usage information can result in serious injury or death.
- Page 3 Women who are pregnant and individuals considered minors must not use any Safewaze equipment. • Do not alter or misuse equipment. Only Safewaze, or entities authorized in writing by Safewaze, may make repairs to Safewaze fall protection equipment. •...
-
Page 4: Table Of Contents
► Compatibility of Connectors ► ► 10.0 Making Connections ► ► 11.0 Installation / Operation of SRL ► ► 12.0 Inspection / Maintenance ► ► 13.0 Labels ► ► 14.0 Annual Inspection Form ► ► V3. 2023 Copyright Safewaze: 220-00080... -
Page 5: Introduction
OSHA or any applicable state agency. The Northstar Classic LE SRL is intended for use as part of a complete Personal Fall Arrest, Restraint, Work Positioning, or Rescue System. Safewaze SRLs are designed to safely arrest the user in a fall event, while minimizing forces on the body. -
Page 6: Intended Use
Safewaze. Use of this equipment in a manner outside the scope of those covered within this manual can result in serious injury or death. The equipment covered in this manual must only be used by trained personnel in workplace applications. -
Page 7: Worker Classifications
The rescue plan must be specific to the project. The rescue plan must allow for employees to rescue themselves or be promptly rescued by alternative means. V3. 2023 Copyright Safewaze: 220-00080... -
Page 8: Product Limitations
Minimize swing falls by working as directly below the anchorage point as possible. • Swing Fall Drop Distance: The additional clearance added from excess cable being paid out when working at a lateral offset from the anchorage. V3. 2023 Copyright Safewaze: 220-00080... -
Page 9: Product Specifications
Do not allow the lifeline to pass under arms or between the legs. • Sharp Edges: Safewaze Class 1 SRLs are NOT designed for use in Leading Edge Environments. Should a specific work area have an extremely sharp edge/ edges that may come into contact with the lifeline constituent of the SRL, a Class 2 SRL is required. -
Page 10: Fall Clearance
• Actual Arrest Distance (AD): Safewaze SRLs are tested in accordance with ANSI Z359.14-2021 conditioning test protocols. Table 2 reflects the Actual Arrest Distances of the Northstar Classic LE SRL when subjected to Ambient, Wet, Hot, and Cold testing. These Actual Arrest Distances are typically lower than the 42”... - Page 11 34" (86 cm) 33" (84 cm) 38" (97 cm) FS-FSP9030 30" (76 cm) 30" (76 cm) 35" (89 cm) 41" (104 cm) FS-FSP9050 37" (94 cm) 30" (76 cm) 41" (104 cm) 33" (84 cm) V3. 2023 Copyright Safewaze: 220-00080...
- Page 12 TABLE 5: MINIMUM REQUIRED FALL CLEARANCE (CLASS 2) Model Actual Arrest Distance Minimum Required Fall Clearance FS-FSP9020 97" (246 cm) 16' 6" (5.0 m) FS-FSP9030 96" (244 cm) 16' 6" (5.0 m) FS-FSP9050 93" (236 cm) 16' 3" (4.9 m) V3. 2023 Copyright Safewaze: 220-00080...
- Page 13 (5.2m) (5.7m) 15'10" 17'7" 19'4" 21'2" RESULT IN SERIOUS INJURY OR DEATH 15'10" 17'7" 19'4" 21'2" (4.8m) (5.4m) (5.9m) (6.5m) V3. 2023 Copyright Safewaze: 220-00080 DEATH (4.8m) (5.4m) (5.9m) (6.5m) 18'9" 20'8" 22'7" 24'7" 18'9" 20'8" 22'7" 24'7" (5.7m) (6.3m) (6.9m)
- Page 14 WORKING IN THIS AREA MAY (X.Xm) (8.7m) (9.3m) (9.9m) (3.7m) (4.3m) (4.9m) RESULT IN SERIOUS INJURY OR 12'0" 14'0" 16'0" WORKING IN THIS AREA MAY DEATH (3.7m) (4.3m) (4.9m) RESULT IN SERIOUS INJURY OR DEATH V3. 2023 Copyright Safewaze: 220-00080...
- Page 15 SRL anchor point. • The redirection angle of the lifeline at an edge over which a fall may occur shall be at least 90 degrees (Figure 1). FIGURE 1: ANCHOR POINT FOR SRL-LE ≥ 90˚ < 90˚ V3. 2023 Copyright Safewaze: 220-00080...
- Page 16 (3.4m) (3.4m) (3.9m) (3.9m) (4.4m) (4.4m) (4.9m) (4.9m) 1.2m) (1.4m) (1.7m) (2.0m) (2.3m) (2.7m) (3.0m) RESULT IN SERIOUS INJURY OR V3. 2023 Copyright Safewaze: 220-00080 4'3" 5'6" 6'11" 8'5" 10'0" 11'8" 13'4" 15'0" 16'9" 18'6" 4'3" 5'6" 6'11" 8'5" 10'0"...
-
Page 17: Compatibility Of Connectors
(4.9m) (4.9m) (5.4m) (5.4m) (6.0m) (6.0m) (6.6m) (6.6m) 1.5m) (1.8m) (2.2m) (2.6m) (3.0m) (3.4m) (3.8m) • Safewaze equipment is designed for, and tested with, associated Safewaze 8'0" 9'10" 11'9" 13'8" 15'7" 17'7" 19'6" 21'6" 23'5" 25'5" 8'0" 9'10" 11'9" 13'8"... -
Page 18: Making Connections
Ensure all connectors are fully closed and locked. Safewaze connectors (hooks, carabiners, and D-rings) are designed to be used only as specified in each product’s manual. See Figure 4 for examples of inappropriate connections. -
Page 19: Installation / Operation Of Srl
When used properly, the lifeline of the SRL will extend and retract freely, with no slack or hesitation, as the user moves at normal speeds. In the event of a fall, Safewaze SRLs are equipped with a speed-sensing braking system. The braking system will activate, stop the fall, and absorb much of the energy created by the fall. -
Page 20: Inspection / Maintenance
Construction, Utilities, Use, All Temperatures, Annually Warehouse Clean or Dusty Environments Harsh Storage Commercial Conditions, Prolonged Quarterly to Semi- Severe to Continuous Construction, Oil and or Continuous Outdoor Annually Gas, Mining Use, All Temperatures, Dirty Environment V3. 2023 Copyright Safewaze: 220-00080... - Page 21 Allow equipment to fully dry before being stored. • Storage: Prior to installation, store the Northstar Classic LE SRL in a cool, dry area where it will not be exposed to extreme light, extreme heat, excessive moisture, or possibly corrosive chemicals or materials.
- Page 22 CABLE UNITS INSPECTION Carabiner Swivel Top Housing Label Cable Lifeline Sew-in Labels Energy Absorber* LOAD INDICATOR *Deployed Energy Absorber: PASS FAIL If tear webbing from shock pack is deployed and visible. Immediately remove from service. V3. 2023 Copyright Safewaze: 220-00080...
-
Page 23: Labels
BACK SIDE INCLUDED WITH THIS EQUIPMENT. DO NOT REMOVE LABEL. DO NOT ATTEMPT TO SERVICE OR REPAIR THIS UNIT! CONTACT SAFEWAZE FOR SERVICE OR REPAIR INFORMATION. Device must be inspected prior to each use in accordance with the manufacturer’s instructions. Perform the Locking Function Test (sharp pull test) and retraction test. Inspect the device for label BACK SIDE legibility, any evidence of damage or defects, and missing components or parts. -
Page 24: Annual Inspection Form
INSPECTION LOG ANNUAL FORM Inspection Inspector: Pass/Fail: Comments/ Date: Corrective Action: Address: 225 Wilshire Ave SW, Concord, NC 28025 Phone: (800) 230-0319 Fax: 704-262-9051 Email: info@safewaze.com Website: safewaze.com V3. 2023 Copyright Safewaze: 220-00080...
