USER'S MANUAL
DVUT 300 HB EC V.2
DVUT 300 HBE EC V.2
DVUT 300 HBE2 EC V.2
Single-room heat recovery air handling unit
DVUE 300 HB EC V.2
DVUE 300 HBE EC V.2
DVUE 300 HBE2 EC V.2
DVUT 500 HB EC V.2
DVUT 500 HBE EC V.2
DVUT 500 HBE2 EC V.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVUT 300 HB EC V.2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BLAUBERG DVUT 300 HB EC V.2

  • Page 1 USER’S MANUAL DVUT 300 HB EC V.2 DVUE 300 HB EC V.2 DVUT 500 HB EC V.2 DVUT 300 HBE EC V.2 DVUE 300 HBE EC V.2 DVUT 500 HBE EC V.2 DVUT 300 HBE2 EC V.2 DVUE 300 HBE2 EC V.2 DVUT 500 HBE2 EC V.2...
  • Page 2: Table Of Contents

    DVUT/DVUE HB(E/E2) EC V.2 CONTENTS Safety requirements ..................................2 Purpose ........................................ 4 Delivery set ......................................4 Designation key ....................................4 Technical data ....................................5 Design and operating principle ............................6 Mounting and set-up .................................. 8 Connection to power mains ..............................11 Technical maintenance ................................
  • Page 3 Connection to the mains must be made through a disconnecting device, which is integrated into the fixed wiring system in accordance with the wiring rules for design of electrical units, and has a contact separation in all poles that allows for full disconnection under overvoltage category III conditions.
  • Page 4: Purpose

    DVUT/DVUE HB(E/E2) EC V.2 PURPOSE The unit is designed to ensure continuous mechanical air exchange in houses, offices, hotels, cafes, conference halls, and other utility and public spaces as well as to recover the heat energy contained in the air extracted from the premises to warm up the filtered stream of intake air.
  • Page 5: Technical Data

    TECHNICAL DATA The unit is designed for indoor application with the ambient temperature ranging from +1 °C up to +40 °C and relative humidity up to 60 % without condensation. In cold, damp rooms, there is a possibility of freezing or condensation inside and outside the casing. In order to prevent condensation on the internal walls of the unit, it is necessary that the surface temperature of the casing is 2-3 °C above the dew point temperature of the transported air.
  • Page 6: Design And Operating Principle

    DVUT/DVUE HB(E/E2) EC V.2 UNIT OVERALL DIMENSIONS [mm] H +20* H2 +20* Model DVUT 300 HB EC V.2 DVUT 300 HBE EC V.2 DVUT 300 HBE2 EC V.2 1775 1485 DVUE 300 HB EC V.2 DVUE 300 HBE EC V.2 DVUE 300 HBE2 EC V.2...
  • Page 7 1 — control unit; 2 — reheater; 3 — extract filter; 4 — heat exchanger; 5 — bypass air damper actuator; 6 — supply fan; 7 — extract fan; 8 — preheater; 9 — supply filter; 10 — SETUP MODE button; 11 —...
  • Page 8: Mounting And Set-Up

    DVUT/DVUE HB(E/E2) EC V.2 MOUNTING AND SET-UP READ THE USER'S MANUAL BEFORE INSTALLING THE UNIT Sufficient service access to the unit for maintenance or repair operations must be provided. The recommended minimum distances from the unit to the walls are shown below. Make sure the unit has no foreign objects inside before starting it up.
  • Page 9 The levelling feet on the bottom of the unit ensure exact alignment of the unit during mounting. For alignment of the unit loosen the nuts and adjust position of the support disc manually using a wrench. Then tighten the upper and the lower nut.
  • Page 10 DVUT/DVUE HB(E/E2) EC V.2 INSTALLATION OF SENSORS (not included in the delivery set) The bracket for installing humidity, CO2, VOC sensors is located on the wall of the exhaust air duct upstream the heat exchanger. Secure the CO2-3 sensor circuit board on the bracket and connect the cable with the connector (installed by the manufacturer) Secure the HV2 humidity sensor on the bracket and connect the cable with the connector (installed by the manufacturer) To install the VOC sensor, disassemble the sensor according to the instructions provided in its delivery set.
  • Page 11: Connection To Power Mains

    CONNECTION TO POWER MAINS ANY TAMPERING WITH THE INTERNAL CONNECTIONS IS PROHIBITED AND WILL VOID THE WARRANTY. The unit without a drain pump is designed to be connected to power mains with parameters 1~230 V/50 (60) Hz, with a drain pump —...
  • Page 12 DVUT/DVUE HB(E/E2) EC V.2 EXTERNAL WIRING DIAGRAM Type of Designation Name Wire Note contact РК1* Contact from fire alarm panel 2 x 0,75 mm Remove the jumper CCU* Cooler control 2 x 0,75 mm 3 A, 30 DC Р1* External control panel 4 x 0,5 mm Boost* On/Off contacts for the Boost mode...
  • Page 13: Technical Maintenance

    TECHNICAL MAINTENANCE Maintenance operations of the unit are required 3-4 times per year. Maintenance includes general cleaning of the unit and the following operations: 1. Filter maintenance. Clogged filters increase air resistance in the system and reduce supply air volume. Clean the filters as required, but not less than 3-4 times per year.
  • Page 14 DVUT/DVUE HB(E/E2) EC V.2 2. Heat exchanger maintenance (once per year). Some dust may accumulate on the heat exchanger even in case of regular maintenance of the filters. Regular cleaning of the heat exchanger is required to maintain high heat recovery efficiency. To clean the heat exchanger, pull it out of the unit and clean it with compressed air or a vacuum cleaner.
  • Page 15: Troubleshooting

    TROUBLESHOOTING TROUBLE POSSIBLE REASONS Troubleshooting Make sure the power supply line is connected correct. No power supply. Otherwise troubleshoot a connection error. The fan(s) do(es) not get Turn the unit off. Troubleshoot the fan clogging. Clean started during activation of Motor or impeller clogging.
  • Page 16: Manufacturer's Warranty

    DVUT/DVUE HB(E/E2) EC V.2 MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 17 www.ventilation-system.com...
  • Page 18 DVUT/DVUE HB(E/E2) EC V.2 www.ventilation-system.com...
  • Page 19: Certificate Of Acceptance

    CERTIFICATE OF ACCEPTANCE Unit Type Single-room heat recovery air handling unit Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
  • Page 20 V142EN-08...
