AMV 120 NL-1
ENGLISH
Safety Notes
To avoid personal injury and damage to
the device or other property, it is
necessary to read and follow these
instructions carefully.
Assembly, start-up, and maintenance work
must be performed by qualified and authorized
personnel.
Comply with the instructions of the system
manufacturer or system operator.
Do not remove the cover before the
power supply is switched off.
Mounting Position ❶
The actuator should be mounted with the valve
stem in either a horizontal position or pointing
upwards.
Wiring ❷
AC 24 V
Connect via Class 2 (North America)
or Safety Extra-Low Voltage (SELV)
(Europe). Failure to comply can lead to
equipment damage or personal injury.
Switch off power before wiring the
actuator!
1. Make all wiring connections in accordance
with local, national, or regional regulations.
2. For applications requiring conduit, a field
supplied 1/2" trade size electrician's fitting
and lock nut can be mounted in the actuator
enclosure. Use flexible metallic tubing or its
equivalent with the field supplied fitting.
3. Insert wiring material through the removable
plug or conduit fitting, and connect to the
terminal block using the applicable wiring
diagram ❷.
4. Optionally, end position feedback is
available on terminal 4 (stem down) and
terminal 5 (stem up). Both contacts are
normally open.
Installation ❸
1. Check the valve neck. The actuator should
be in the full up position ① (factory setting).
If it is not, refer to the manual override
instructions and reposition the actuator to
its full up position ❸①.
2. The actuator is fixed to the valve body by
means of a ribbed nut which requires no
tools for mounting. The ribbed nut should
be hand tightened only.
Manual override ❹
(for service purposes only)
Do not use the manual override if
power is connected!
AQ315258770192en-010302
- Remove cover ①
- Press and hold the button (on the bottom
side of the actuator) ② during manual
override ③
- Replace cover ④
Install actuator on valve ⑤
-
Remark:
A 'click' sound after energizing the actuator
indicates that the gear wheel has jumped into
normal position.
Don't dismount the actuator from
the valve when it is in a stem down
position!
If dismounted in a stem down position, there is a
high risk that the actuator gets stuck.
The following information is provided on the
device or on the instruction manual or
datasheet:
A) Purpose of control: Electrical Actuator
B) Construction of control: Independently
Mounted Control
C) Method of mounting control
D) Type 1 Action
E) Pollution Degree 3
F) Impulse Voltage: 500V
G) Software Class A
H) Mechanical and thermal ratings (ref to
Ratings section for more details)
I) "Use ½ inch flexible metal conduit for
connection"
J) "Use Listed Flexible Metal Conduit Fitting
DWTT/7"
K) "Use 60°C/75°C copper (CU) conductor and
wire size range (#) AWG, stranded or solid".
"The terminal tightening torque of (#) Lb per In."
L) Torque value for Cover screw: 0,6 +/-0,1 Nm.
Note (#): Values depend by field wiring ratings of terminal
block employed on the device construction.
