- Page 1 USER MANUAL...
- Page 2 Thank you! We hope you'll love your new AUTOLIFT3000. If you have any additional questions, or need product support: > please visit www.autoliftproduction.com > or write us to info@autoliftproduction.com...
- Page 3 Read these instructions carefully before assembling and using the product. The manufacturer is not responsible for Always keep the instruction manual any injury or damage caused by improper nearby. You can find it also online at assembly or usage of this product. Follow www.autoliftproduction.com.
-
Page 4: Technical Parameters
Technical Parameters Capacity 3,000 kg / 6,614 lbs Dimensions 1635 x 1300 x 115 mm 64.5 x 51.25 x 4.50 inch Net Weight 45 kg / 99 lbs Max. Height 60 cm / 23,50 inch Lifting Speed 25 - 30 s Platform Width 1300 mm - 1650 mm 51.18 - 64.96 inch... -
Page 5: Contents Of The Package
Contents of the Package Standard version > AUTOLIFT3000 (lifting frame) > Box A - set of platforms > Box B > set of axis bolts (2x axis bolt, 4x washer A21, 4x bushing, 4x lock nut M20) > set of red caster wheels and fasteners (3x red caster wheel, 12x screw M5x16, 12x lock nut M5) >... -
Page 6: Product Assembly
Product Assembly Unpack box A and prepare the platforms. The needed tools: > 8 mm metric combination wrench > phillips screwdriver > 2x 30 mm combination wrench for the lock nuts M20 > hammer > combination pliers > snapp-off knife or scissors First things first >... - Page 7 Unpack the box B and prepare the set of axis bolts. Lift both arms of the frame to the same height and insert the axis bolt through both holes of the frame. Slide the A21 washers onto both sides of the axis bolt.
- Page 8 Slide the platform onto the axis bolt, first from the Slide the bushings onto the axis bolt from both sides. outside, then from the inside.
- Page 9 Screw the nut onto both sides of the axis bolt and Apply the same technique for installing the platform on tighten securely with a 30 mm wrench. the other side of the lifting device.
- Page 10 Prepare the red caster wheels (box B). Install the caster wheels on the frame, spacing washers included. Especially, if you have the Premium version and will be using the "Rails for uneven surface".
- Page 11 Prepare the drill adaptors and the safety pin (box B). Insert one of the adapters into the drill. The rest of the adapters should be carefully saved. We recommend to attach the safety pin to the drill by the chain (this avoids forgetting the safety pin in the safety system when lowering the lifting device).
- Page 12 Lower the lifting device to the starting position. After the first few uses, excess lubricant may appear on the moving system of the lifting device. This lubricant does not indicate any malfunction! Lower the lift to the starting position with the drill. Observe the direction of rotation of the drill and the arrows on the gearboxes of the lift.
- Page 13 Operating the AUTOLIFT3000 Positioning of the lifting device for tilting the vehicle To tilt the vehicle, it is necessary to lift it TIP for fast finding car's point of gravity: Positioning of the lifting device at its centre of gravity. For front-engined Place the lifting device about 10 cm from vehicles, position the lifting device so that the wheels of the engine axle.
- Page 14 Lowering Safety instructions Before lowering the lifting device, make Always make sure that the drill head Do not exceed the allowed capacity. Only Secure the lifting device with a safety pin. sure that you removed the car stand rotates in the desired direction. Lower the lift vehicles with unibody construction! Do It is forbidden to work under the vehicle support.
- Page 15 Setting Up and Usage of Accessories Beam pads must always be lying with the entire surface on the platform. Beam pads (box D) Beam pads are designed for lifting vehicles with uneven or fragile undercarriage parts, where the pad fills the gap between the platform and the solid part of the undercarriage.
- Page 16 Rails for uneven surface (box C) - Premium Turn the lift so that the platforms lie on a flat and clean surface. First assemble that side, where the safety system is installed. Open box C Using combination pliers, remove the cotter pin from the pin, remove the spacer and flat washer and slide out the safety system tube.
- Page 17 Place one of the rails for uneven surfaces on the lift, ensuring that the holes are Insert the pin included in the Rails for uneven surfaces accessory through both holes accessible from both sides (do not be afraid to push the rail with force). and slide the spacer onto it.
- Page 18 Slide the safety system tube back onto the pin, add the flat washer and re-secure it Rails for uneven surface are recommended for all uneven floors, outdoor uneven with the cotter pin. terrain, indoor polished floors or painting booths. Apply the same procedure on the other side of the lifting device. There is no safety system on the other side, so just attach the second rail for uneven surface to the lifting device and secure with a cotter pin.
- Page 19 Car stand support (box E) - Premium Open box E Unfold the car stand support to a stable position, adjust its height and secure it with the safety pin.
- Page 20 Set of wall hangers (box B) - Premium Use the car stand support to secure the lifted vehicle in the tilted position. Unpack the set of wall hangers (box B). Always place the car stand support against the strong points of the undercarriage. Find a suitable free space on the wall.
-
Page 21: Warranty
Warranty Exceeding the maximum permitted upper lift, marked with red tape with the STOP! Risk of damage to the lifting gear drive. The warranty period of the lifting device is The manufacturer is not liable for any 3 years from the date of sale. defect, loss, injury or damage caused by The warranty period of the accessories is violation or failure to follow the... -
Page 22: Warranty Conditions
AUTOLIFT the user. PRODUCTION s.r.o., except for the cost of transportation to/from AUTOLIFT Always keep the proof of purchase. -
Page 23: Safety Instructions
Secure the environment so that this situation > Never exceed the maximum load capacity of the lifting device (3000 kg/6614 lbs). cannot change. Also ensure that no persons or animals are in the vehicle. -
Page 24: Maintenance And Repairs
Maintenance and repairs > It is forbidden to perform any repairs or modifications to the lifting device. > Make sure that the stainless steel shaft connecting the gearboxes of the product is not bent (e.g. by running over the lifting device, not respecting the lower stop limit etc.). >... - Page 26 AUTOLIFT PRODUCTION s.r.o. Prikop 838/6, 602 00 Brno Czech Republic, Europe info@autoliftproduction.com www.autoliftproductio.com © AUTOLIFT PRODUCTION All Rights Reserved. AUTOLift3000® was designed in 1991 and is the only original tilting car lift. AUTOLift3000 is registered trademark of AUTOLIFT PRODUCTION.
