- Page 1 Lift “F900” Installation Manual Volkswagen T5 www.autoliftsrl.com...
- Page 2 Lift “F900” 1-VEHICLE Remove Plastic cover of vehicle bottom 2-REMOVE ORIGINAL TANK Remove original tank – drill the tank supports and remove them. Remove the fuel pump. Cut the filling tube from the tank and remove the non-return valve. Cut the filling tube in this area...
-
Page 3: Fuel Pump
Lift “F900” 3- FUEL PUMP Put the pump on flat surface. It is necessary to adapt the level indicator to the new tank : bend the float in order to make it 5cm higher Float modification: make it 2.5 cm higher... - Page 4 Lift “F900” 3- SPECIAL TANK Put the valve in to the from the inside and fix with a support or special bush so that it won’t fall in the tank. Place the shorten filling tube in the new tank using the rubber tube and clamps.
- Page 5 Lift “F900” Place the original Fuel pump and please check the pump orientation (30° angle) 30° Angle Fix the new tank to the vehicle: M8 screws in to the original fixing points Special support 1x M8 Screws at both sides...
- Page 6 Lift “F900” More pictures of special tank fixation Special support Special support Special support M8 Screw in original Special support fixing point Tank seen from the bottom M8 Screw in original fixing point...
-
Page 7: Exhaust System
Lift “F900” 5. EXHAUST SYSTEM Dismount the original exhaust from the vehicle Cut the original pipes of the central exhaust Weld the new pipe Connect the welded pipe to the back exhaust part View from the rear Front tube... -
Page 8: Lift Installation
Lift “F900” 6. LIFT INSTALLATION Fix the lift to the vehicle with the special supports Lift under the Tank Exhaust is between lift and vehicle bottom... -
Page 9: Lifting Height
Lift “F900” 7. HYDRAULIK AND ELECTRIC BOX The hydraulic power pack is build in protection box. Just disconnect the quick coupling and place the power pack in the vehicle in the preferred position . Electric box Hydr. Power pack box Hand Control Switch 8. - Page 10 Installation Manual For a correct installation and safe use of the lift please read carefully this installation manual www.autoliftsrl.com...
