- Page 1 ONGA PANTERA RP CARTRIDGE FILTERS Installation and Operation Manual PCFRP-100 PCFRP-150 PCFRP-200 L300356_Pantera RP_Owners Manual_12pp_A5_0524.indd 1 L300356_Pantera RP_Owners Manual_12pp_A5_0524.indd 1 5/3/2024 10:11:56 AM 5/3/2024 10:11:56 AM...
- Page 2 PANTERA RP CARTRIDGE FILTER Pantera RP cartridge filters have been specifically designed for the filtration of spa and swimming pool water. They should not be used for any other purpose without first consulting your Pentair dealer. Pantera RP cartridge filters provide economy, high performance and convenience in a well- designed pressure filter.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS ............... 1 THE SPARKLING CLEAR WATER DIFFERENCE . -
Page 4: The Sparkling Clear Water Difference
THE SPARKLING CLEAR WATER DIFFERENCE Cartridge filtration is an effective trouble-free proven method of filtration. Pool water enters the filter and passes through a polyester single element cartridge. Suspended particles are trapped and the water is returned to the pool. As the build-up of dirt in the element increases, so the water pressure rises and the flow decreases. -
Page 5: Before Starting The Pump
3. STARTING THE PUMP AND FILTER SYSTEM 3.1 BEFORE STARTING THE PUMP 3.1 BEFORE STARTING THE PUMP 1. Use ONLY ICF system components: Lock Ring unit doing assembly, metal-reinforced seal. Non-tig 3.1 BEFORE STARTING THE PUMP ring component may fail in use and cause explosive component separation. Verify that upper and lo 1. -
Page 6: Filter Maintenance
FILTER MAINTENANCE WHEN TO REPLACE FILTER CARTRIDGE ELEMENT You should replace the filter cartridge element with new, when: 1. After cleaning the filter element, the pressure is 25 kPa higher than the initial start reading. 2. When the filter element is broken, or the layer peers off. 3. -
Page 7: Body And Lock Ring Re-Assembly
FILTER MAINTENANCE BODY AND LOCK RING RE-ASSEMBLY 1. Place the sealing O-ring on the bottom body. Place the upper body on the O-ring and the bottom body. Upper body 2. Use the PANTERA RP lock ring system only, tighten the lock ring (clockwise) until the latch is locked on position. -
Page 8: Troubleshooting
TROUBLESHOOTING SYMPTOM CAUSE REMEDY Pool water level too low. Fill pool to correct level. No Water Discharge Check and tighten all Air leaks in inlet fittings to connections. Teflon tape pump. fittings. Clean filter cartridge. Filter Dirty. Replace filter cartridge. DON’T RUN FILTER WITH LIVE ALGAE IN POOL. -
Page 9: Replacement Parts
REPLACEMENT PARTS KeyNo. Part No. Description 190058 Pressure gauge 对外清单 811101 Lid Pantera RP CF 100 811102 Lid Pantera RP CF 150 811103 Lid Pantera RP CF 200 811104 Nut 22x15mm 811105 Locking Ring Pantera RP CF 811106 Latch Pantera RP CF 811107 O-Ring 306x7.5mm 811114... - Page 10 NOTES L300356_Pantera RP_Owners Manual_12pp_A5_0524.indd 8 L300356_Pantera RP_Owners Manual_12pp_A5_0524.indd 8 5/3/2024 10:11:57 AM 5/3/2024 10:11:57 AM...
- Page 11 NOTES L300356_Pantera RP_Owners Manual_12pp_A5_0524.indd 9 L300356_Pantera RP_Owners Manual_12pp_A5_0524.indd 9 5/3/2024 10:11:57 AM 5/3/2024 10:11:57 AM...
- Page 12 IMPORTANT Please attach your sales invoice/docket here as proof of purchase should warranty service be required. Please do not return Warranty Form to Pentair Australia. Retain for your records. PURCHASED FROM: PURCHASE DATE: SERIAL NO: MODEL NO: 1-21 Monash Drive | Dandenong South, VIC 3175 | Australia | 1300 137 344 | pentairpool.com.au Information contained here-in remains the property of Pentair under Australian copyright law.
