Goodwe GW5KL-ET Quick Manual

Residential Smart Inverter Solutions Quick Guide (ET 5-10kW+Lynx Home F)
The information in this quick guide is subject to change due to product updates or other reasons. This guide cannot
replace the product labels or the safety precautions in the user manual unless otherwise specified. All descriptions in
the manual are for guidance only.
01 Networking
WARNING
Device Model
GW5KL-ET
V1.0-2024-04-30
GW6KL-ET
GW8KL-ET
GW10KL-ET
Inverter
GW5KN-ET
GW6.5KN-ET
GW8KN-ET
GW10KN-ET
Lynx Home F (G2)
LX F9.6-H-20
LX F12.8-H-20
Battery system LX F16.0-H-20
LX F19.2-H-20
LX F22.4-H-20
LX F25.6-H-20
Smart meter GM3000
Communicati- • Wi-Fi Kit
on module • 4G Kit-EC or 4G Kit-AU
02 Power On/Off
1
Description
GW5K-ET
GW6.5K-ET
GW8K-ET
GW10K-ET
-
Lynx Home F
,F Plus
LX F6.6-H
• A maximum of 8 battery systems can be clustered in a system.
LX F9.8-H
• Do not mix connect battery systems of different versions.
LX F13.1-H
LX F16.4-H
GM3000: GM3000 and the CT, which cannot be replaced, are
included in the inverter package. CT ratio: 120A/40mA.
-
Power on/off
1 2 3 4 5
③ : Install or not based on
local laws and regulations
