Summary of Contents for Chefman ExacTemp RJ38-AFG-7TP-UK
- Page 1 ExacTemp 7.4-Quart air Fryer + Grill USER GUIDE • Safety instructions • Features • Operating instructions • Cooking charts • Cooking tips • Troubleshooting • Cleaning and maintenance • Notes • Terms and conditions • Warranty registration RJ38-AFG-7TP-UK...
- Page 2 COOKING FORWARD™ Welcome! Whether this is your first Chefman appliance or you’re already part of our family, ® we’re happy to be cooking with you! With your new ExacTemp 7.4-Quart Air Fryer + Grill, you can grill, air fry, roast, bake or broil all in one virtually smokeless unit.
-
Page 3: Table Of Contents
CONTENTS Safety instructions Features Operating instructions Cooking charts Cooking tips Troubleshooting Cleaning and maintenance Notes Terms and conditions Warranty registration... -
Page 4: Safety Instructions
5. Unplug from the socket when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning appliance. 6. Do not operate any appliance with a damaged cable or plug, or after the appliance malfunctions or has been damaged in any manner. Contact Chefman Customer ®... - Page 5 SAFETY INSTRUCTIONS IMPORTANT SAFEGUARDS 8. Do not use outdoors. 9. Do not let cable hang over edge of the table or counter or touch hot surfaces. 10. Do not place on or near a hot gas or electric hob or in a heated oven. 11.
- Page 6 SAFETY INSTRUCTIONS IMPORTANT SAFEGUARDS WARNING: Please ensure that the electrical socket can accommodate the plug supplied with the product. Do not attempt to alter the plug in any way. SHORT CABLE INSTRUCTIONS A short power-supply cable is provided to reduce the risk of entanglement or tripping over a longer cable.
- Page 7 To insert the plug, hold it firmly and guide it into socket. To disconnect the plug, hold the plug and remove it from socket. Never use the product if the power cable shows signs of abrasion or excessive wear. Contact Chefman Customer Support for additional guidance and support. ®...
-
Page 8: Features
FEATURES circulate around food Lid: contains heat source and fan 6. Grill plate: heavy-duty die-cast 2. Removable mesh splatter shield: inserts aluminium for great grill marks into lid to help keep heating element clean and prevent smoking 7. Non-stick cooking pan: large capacity for family-sized meals 3. - Page 9 FEATURES Time + and – buttons Operating lights Temperature Adjust cooking time in + and – buttons Light up when 1-minute increments, Cooking unit is actively Adjust unit cooking or when cooking with Temperature function cooking. Low/ temperature in 5˚ probe, adjust target display buttons...
- Page 10 FEATURES COOKING FUNCTIONS AT A GLANCE All five functions require the cooking pan to be inserted and can all be used with the probe. They differ in their temperature range, inserts used and whether they include a Flip/Stir reminder. (Note: You can ignore or amend the reminder as desired.) Function Pan/Insert(s) used Temperature...
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS BEFORE FIRST USE For best results, follow these steps before using your air fryer for the first time. Remove all packaging materials, such as plastic bags and foam inserts. Check to ensure that all parts and accessories are included. Read and remove any stickers on the unit except for the rating label on the bottom, which should remain on the unit. - Page 12 OPERATING INSTRUCTIONS HOW TO COOK USING THE PROBE THERMOMETER Unlike an instant-read thermometer, the probe thermometer stays in your food through the entire cooking cycle, constantly monitoring the temperature until it reaches the target. You can use the probe thermometer with any of the five cooking functions. If using the probe, see the chart on p.10 for details on cooking pans and temperature ranges, but follow the instructions here to program the unit.
- Page 13 Plug the other end of the thermometer into the thermometer jack on the unit. Select your desired cooking function on the control panel (that button will light up in blue when pressed). Press PROBE COOK. Choose your desired cooking temperature. Use the + and – on the TEMP button to adjust in increments of 5˚...
- Page 14 OPERATING INSTRUCTIONS When preheated (the time varies depending on the set temperature), the unit will beep and ADD FOOD will display on the panel. Place food in the unit and close the lid. NOTE: The lid can close firmly over the thermometer probe cord without damaging it, but be sure Step 9 not to close the lid on the actual probe.
- Page 15 OPERATING INSTRUCTIONS If you are using the Grill, Air Fry or Roast modes, you will get a reminder to flip or stir your food about halfway through cooking. The unit will beep, and FLIP or STIR will display on the panel. Flip or stir food as needed.
- Page 16 OPERATING INSTRUCTIONS HOW TO AIR FRY The perforated air fryer basket allows air to circulate around food for even cooking and crisping, and lets excess fat drip down and away from food for healthier eating. The directions below are for cooking without the probe; if you would rather air fry to a specific internal temperature, see How to Cook Using the Probe Thermometer on p.12.
- Page 17 OPERATING INSTRUCTIONS Press START/STOP. This unit will automatically begin to preheat. When preheated, the unit will beep, and ADD FOOD will display on the panel. Add food to the air fryer basket and close the lid. The timer will begin counting down. Step 5 When half the time has passed (or every 15 minutes for cycles lasting more than...
- Page 18 OPERATING INSTRUCTIONS HOW TO GRILL The heavy-duty grill plate is excellent at absorbing and retaining heat, so it gives your food the same gorgeous grill marks you’d get on an outdoor grill, while the closed environment cooks it to juicy perfection. The directions below are for cooking without the probe; if you would rather grill to a specific internal temperature, see How to Cook Using the Probe Thermometer on p.12.
- Page 19 OPERATING INSTRUCTIONS HOW TO ROAST Roasting surrounds your foods with even, high heat to cook a large cut of meat, such as a whole chicken or a large fillet of fish. The directions below are for cooking without the probe; if you would rather roast to a specific internal temperature, see How to Cook Using the Probe Thermometer on p.12.
- Page 20 OPERATING INSTRUCTIONS HOW TO BAKE As with roasting, baking surrounds your foods with even, high heat to cook tarts, small cakes, cookies and breads. The directions below are for cooking without the probe; if you would rather bake to a specific internal temperature, see How to Cook Using the Probe Thermometer on p.12.
- Page 21 OPERATING INSTRUCTIONS HOW TO BROIL (GRILL FROM ABOVE) Choose broiling when you want to quickly give meat a deeply browned exterior, melt cheese over a baked pasta dish or brown the crust of a gratin. The directions below are for cooking without the probe;...
-
Page 22: Cooking Charts
COOKING CHARTS GRILLING Times do not include automatic preheat, which will add a few minutes. Check foods are well cooked according to current safety guidelines before serving. Ingredient Amount/Prep Temperature Time (mins) Stir/Flip? ˚C (˚F) 260 ˚C Asparagus 1 bunch, ends trimmed, tossed with a little oil 6–8 500 ˚F Corn on... - Page 23 COOKING CHARTS AIR FRYING Times do not include automatic preheat. Check foods are well cooked according to current safety guidelines. Ingredient Amount/Prep Toss/Brush Time Temperature Stir/Flip? with oil? (mins) ˚C (˚F) 190 ˚C Broccoli 230 g florets 7–9 Yes stir once 375 ˚F 200 ˚C Cauliflower...
-
Page 24: Cooking Tips
COOKING TIPS It is essential to preheat not only the unit, but also the grill plate, cooking pan, and/or air fryer basket. This produces good grill marks, crisp air-fried foods and nicely browned surfaces. Ensure that the cooking pan, grill plate and/or cooking basket is already in place before you begin preheating. -
Page 25: Troubleshooting
If your air fryer displays E01 or E02 on its control panel, it means there is a loose wire contact or a short circuit, and the unit will not function. If this is the case, please contact Chefman Customer Support for a replacement. An error code E03 indicates the unit is ®... -
Page 26: Cleaning And Maintenance
CLEANING AND MAINTENANCE Almost all parts of the air fryer are top-rack dishwasher safe, except for the main unit housing and probe thermometer, making cleanup quick and easy. Unplug the unit, and let it cool completely before cleaning. (For faster cooling, leave the lid up.) 2. -
Page 27: Notes
NOTES... -
Page 28: Terms And Conditions
Chefman . Any changes to the Terms and Conditions of this Warranty must be in writing, ® signed by a representative of Chefman . No other party has the right or ability to alter or ® change the Terms and Conditions of this Warranty. - Page 29 ® and workmanship, under normal household use, for a period of 2 years from the date of purchase when used in accordance with the directions listed in the Chefman User ® Guide. If your product does not work as it should, please contact Customer Support at support@chefman.co.uk so that we may assist you.
- Page 30 AC ONLY/ AC SEULEMENT NOTE: Label depicted here is an example. How do I register my product? All you need to do is fill in a simple Chefman registration form. You can easily ® access the form in one of the two ways listed below: Visit Chefman.com/register.
- Page 31 ® W ARRANTY REGISTRATION For product information, visit Chefman.com. EXCEPT WHERE SUCH LIABILITY IS REQUIRED BY LAW, THIS WARRANTY DOES NOT COVER AND CHEFMAN IS NOT LIABLE FOR: ® INCIDENTAL, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION, DAMAGE TO OR LOSS OF USE OF THE PRODUCT, OR LOSS OF SALES OR PROFITS OR DELAY OR FAILURE TO PERFORM THIS WARRANTY OBLIGATION.
- Page 32 ©CHEFMAN 2023 RJ38-AFG-7TP-UK_UG_FINAL_OTP_051823...
