Summary of Contents for Sunricher SR-2309Pro-5C
- Page 1 2 YEAR WARRANTY Features of the: Multi colour DALI2 SR-2309Pro-5C DT8 LED Constant DC Input/Output Voltage PWM Range: 12-36 VDC Output DC converter with DALI 2 PushDimming DT8(XY/ (VAC) PWM output Colour control: • Single • RGBCW(5 Ch) • CCT...
-
Page 2: Mechanical Specification
Specification Model SR-2309Pro-5C DC voltage 12-36V PWM (equal to input voltage) 5 x 5A Rated current Output Rated power 5 x (60-180)W PWM refresh rate 3kHz Input Voltage range 12-36VDC Working TEMP. -20 - +50°C Environment Waterproof Grade IP20 0.22kg Net. -
Page 3: Push Button Control
Wiring Diagrams & Instructions DALI Control DALI Control multi-addresses Tc (DT8) • This mode is designed to control two separate groups of tunable white LEDs, each with its own Tunable White DALI address. strip • The DALI Master will discover two separate Tc devices, if compatible. - Page 4 Wiring Diagrams & Instructions multi-addresses RGB + Tc DALI Control DALI Control (DT8) • This mode is designed to manage two separate devices RGB and TC(Tunable white). • The DALI Master will discover two separate RGB Strip devices RGB and Tc, if compatible. Tunable White •...
- Page 5 Wiring Diagrams & Instructions single-address XY (DT8) DALI Control DALI Control • This mode is designed to manage a single address device XY(RGB). RGB Strip • The DALI Master will discover one XY device. • Push button control : • Click the AC push switch to switch ON/OFF •...
- Page 6 Wiring Diagrams & Instructions single-address RGBWAF DALI Control DALI Control (DT8) • This mode is designed to manage a single address device RGBWAF (RGBW Amber and Free colour). RGB Strip • The DALI Master will discover one single RGBWAF device , if compatible. Tunable White •...
