Sunricher SR-2102RJ45-DIN Manual

DIN Rail RDM Enabled DMX512 Decoder
Important: Read All Instructions Prior to Installation
Function introduction
RJ45 terminal
DMX512 input & output
Pin1:Data+ / Pin2:Data- /
Pin7:GND / Pin8:GND
8 7 6 5 4 3 2 1
DMX512 Decoder
CH 4 output(-)
CH 3 output(-)
CH 2 output(-)
CH 1 output(-)
Common Anode Output(+)
Product Data
Input Output Output
No. Remarks
Voltage Current Power
4x5A Constant voltage
1 12-36VDC 4x(60-180)W
2 4x350mA Constant current
12-36VDC 4x(4.2-12.6)W
3 4x700mA 4x(8.4-25.2)W
12-36VDC Constant current
• Standard DMX512 compliant control interface.
• Supports RDM function.
• 4 PWM output channels.
• DMX address manually settable.
• DMX channel quantity from 1CH~4CH settable.
• Output PWM frequency 2KHz.
• Output dimming curve gamma value from 0.1 ~ 9.9 settable.
• DIN rail installation.
• Waterproof grade:IP20.
Safety & Warnings
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.
DC Power input
Pin1:Data+
V+ V-
Pin2:Data-
Pin7:GND
DC INPUT
Pin8:GND
Digital display
A B C
Manual set button
LED OUTPUT DC INPUT
W- B- G- R- + V+ V-
DC Power input
Size(LxWxH)
110x53x65mm
110x53x65mm
110x53x65mm
Wiring Diagram
70060008
1) When total load of each receiver is not over 10A
DMX512
Master
Pin1:Data+
Pin2:Data- V+ V-
Pin7:GND
DC INPUT
Pin8:GND
DMX512 Decoder
A B C
LED OUTPUT DC INPUT
+
W- B- G- R- V+ V-
W- B- G- R- V+
W- B- G- R- V+
If connect With
RGBW color lighting
L
V+
12V/24V/36V
N
CV PSU
V-
G
Pin1:Data+
Pin2:Data- V+ V-
Pin7:GND
DC INPUT
Pin8:GND
DMX512 Decoder DMX512 Decoder
A B C
LED OUTPUT DC INPUT
+
W- B- G- R- V+ V-
CW- WW- V+
V- V+
CW- WW- V+
V- V+
If connect With If connect With
single color lighting dual color lighting
AC Power
50/60Hz
Pin1:Data+
Pin2:Data- V+ V-
Pin7:GND
DC INPUT
Pin8:GND
A B C
LED OUTPUT DC INPUT
+
W- B- G- R- V+ V-
