Installation Guide | Publication date: 2024-04-15
Communication ports:
PORT USAGE
BACnet MS/TP and SG: Signal
1
EIA-485
Modbus RTU ground
KNX KNX bus
As a TCP/IP port:
BACnet/IP,
Modbus TCP, and
Home Automation
administrator and make sure traffic is allowed. When starting
Ethernet
As a console port: up the gateway for the first time, DHCP will be enabled for 30
Connection to a PC seconds. After that time, the default IP 192.168.100.246 will be
for configuration
purposes
AC-Port A
Panasonic P-Link /
No polarity
S-Link
to observe
AC-Port B
AC-Port C
Connection to a PC
USB for configuration
purposes
Digital Dry contact for
C: Common
Inputs input devices
1
Standard EIA-485 bus requirements: maximum distance of 1200 meters (0.75
miles); up to 32 devices connected; a 120 Ω resistor at each end of the bus is
needed (configure the bus biasing and termination resistor for Port EIA-485 with
the DIP switch SWA. See the Technical Specifications table).
Scan here for further configuration details
Dimensions
• Net dimensions (DxWxH)
Millimeters: 90 x 106 x 58 mm
Inches: 3.5 x 4.2 x 2.3"
Leave enough clear space to wire the gateway easily and for the subsequent
manipulation of elements such as connectors, DIP switches, etc.
WIRING
B- A+
+ -
Ethernet cable (CAT5 or higher)
When using the building LAN, contact the network
set.
A1: U1 A2: U2
Not used
Not used
USB Mini-B type
I1: Input 1 I2: Input 2
© HMS Industrial Networks SLU | www.hms-networks.com
Technical Specifications
Plastic, type PC (UL 94 V-0). Color: Light Grey. RAL 7035
Housing
Net dimensions (dxwxh): Millimeters: 90 x 106 x 58 mm / Inches: 3.5 x 4.2 x
2.3"
Wall: M3 25 mm (1") length screws. Secure mounting: below 2 meters (6 feet)
Mounting
DIN rail (recommended mounting) EN60715 TH35
Per terminal: solid wires or stranded wires (twisted or with ferrule)
Wire cross-section/gauge:
Wires (for power
One core: 0.2 .. 2.5 mm
supply and low-
Two cores: 0.2 .. 1.5 mm
voltage signals)
Three cores: Not permitted
For distances longer than 3.05 meters (10 feet), use class 2 cables
1 x Green pluggable terminal block (3 poles)
12 .. 36 VDC +/-10%, Max.: 250 mA
Power
24 VAC +/-10% 50-60 Hz, Max.: 127 mA
Recommended: 24 VDC
Ethernet 1 x Ethernet 10/100 Mbps RJ45
1 x Green pluggable terminal block (3 poles)
Port EIA 485
SGND (Reference ground or shield)
I3:Input3
1500VDC isolation from other ports
Port KNX 1 x Orange pluggable terminal block (2 poles): +, -
AC-Port A (serial, 2 poles): Panasonic bus connection (P-Link / S-Link)
AC Ports AC-Port B (serial, 3 poles): Not used
AC-Port C: (serial, 3 poles): Not used
2 x Run (Power/Error)
2 x Port EIA-485 TX/RX
LEDs
2 x Port KNX TX/TR
1 x Button indicator
1 x Green pluggable terminal block (4 poles)
Binary inputs
I1, I2, I3, and Common
1500 VDC isolation from other ports
USB Mini-B type 2.0 compliant
Console port
1500 VDC isolation
2 x DIP switch blocks for EIA-485 serial port configuration:
Position 1:
DIP switches
SW A
Position 2 and 3:
SW B
1 x Push button
Factory reset
Push button
I-Am message (for BACnet only)
Normal mode/programming mode switch (for KNX only)
Celsius: 0 .. 60°C
Operational
temperature
Fahrenheit: 32 .. 140°F
Operational
5 to 95%. No condensation
humidity
Protection IP20 (IEC60529)
Disposal and Recycling
This product contains electronic components and must be properly disposed of
according to local laws and regulations. For further information, refer to:
www.intesis.com/weee-regulation
For further information on the installation, connection, and configuration of this gateway, refer to
the User manual.
2
(24 .. 14 AWG)
2
(24 .. 16 AWG)
2 x Ethernet Link/Speed
2 x AC-Port A TX/RX
2 x AC-Port B TX/RX
2 x AC-Port C TX/RX
On: 120 Ω termination active
Off: 120 Ω termination inactive
On: Polarization active
Off: Polarization inactive
