Spike 78-1800 Installation Instructions

READ AND UNDERSTAND THESE INSTRUCTIONS COMPLETELY BEFORE INSTALLATION TO
AVOID INJURY TO YOURSELF, DAMAGE TO THE VEHICLE OR ACCESSORY.
• Torque specifications must be followed when tightening bolts. Over-tightening any and/or all screws will
cause cracks around mounting holes which is not covered by any warranty.
• As specified on carton label, once protective film on shields is removed, product cannot be returned.
• As specified on carton label, damage caused by packaging staples is not covered by warranty. All staples must
• Failure to follow these installation instructions completely may void any warrantable components and result in
• Do not use Loctite or any other similar fastener adhesive. These types of products react to plastics and cause
• Our windshields are made from the highest quality material providing optimum transparency and clarity.
Blurriness and/or extrusion marks may or may not appear when looking through windshield from a wide,
• The application of improper cleaners, abrasive and/or dirty cleaning towels can severely damage the product.
Failure to follow cleaning recommendation (provided herewith) may void any warrantable components.
These instructions contain important information for future reference and must be given to the customer at time of
ITEM
A
B
C
INSTRUCTION BAG D
1. Installation
a) Find a clean flat area where you can safely lay down the
windshield (Item A). Partially remove the protective film
on both sides and apply the co-extruded bulb seal (Item C)
using manual pressure to ensure good adhesion and cut
any excess.
78-1800 - Instructions HONDA PIONEER 1000 Dual Vents Full Windshield - rev00
IMPORTANT NOTICES
• For proper installation, TWO people are required .
be removed prior to removing product from carton.
product damage or personal injury.
cracking. Not covered by any warranty.
side-angle. This is normal for all extruded clear plastic materials.
purchase or upon completion of installation.
Parts List
(parts available with kit only and not available separately)
PART NAME
Windshield
Vent assembly
Co-extruded bulb seal (¼")
Flop clamp set
Co-extruded bulb seal
¼" (+/- 51 ½")
INSTALLATION INSTRUCTIONS
HONDA PIONEER 1000
FULL WINDSHIELD - DUAL VENTS
PART # 78-1800
DEALER
CNC windshield cut-out made of ¼" thick GE MR10 polycarbonate or equivalent
Includes: 1 vent cover, 1 vent flap assembly, 1 rubber vent seal and 7 vent mounting screws
Includes: 54" Co-extruded bulb seal (¼") / #77-95BS [end user to cut to exact length]
Includes: 2 flop clamps, 2 knobs M6 x 16 and 4 injected rubber pad spacers (1 ¾")
DESCRIPTION
www.spikepowersports.com / 888-769-2295
QTY
1
2
1
3
1
